Поз.
Артикул
Описание
5
CLUTCH PRESSURE PLATEVALEO, COMPONENT PARTS NOT AVAILABLE PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
CLUTCH PRESSURE PLATEFICHTEL&SACHS,K 017132 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
CLUTCH PRESSURE PLATE ,K 017131, Replaced By: A0052508304, +001A0012508615
11
PRESSURE PLATETO 004 250 88 04
14
FLANGETO 002 250 81 04
17
SPRING SUSPENDED BELOW LEAF SPRING
20
SPRING SUSPENDED BELOW LEAF SPRING
23
RELEASE LEVER CLUTCH ACTUATION
26
ROLLER FOR BEDDING THE LEVERS IN BRACKETS
29
SPINDLE RELEASE LEVER,CLUTCH PRESSURE PLATE
32
BRACKET FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
35
SPINDLE FOR BRACKETS
38
LOCK PLATE RELEASE LEVER TO SHAFT
41
LEAF SPRING THIGH SPRING SUSPENDED BELOW LEAF SPRING
44
NUT FOR BRACKETS
47
LOCK FOR BRACKETS
50
SCREW RELEASE LEVER,BRACKET
53
SLEEVE CLUTCH PRESSURE PLATE
56
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.5 MM
56
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.75 MM
68
CLUTCH DISC ASBESTOS-FREE LINING, COMPONENT PARTS NOT AVAILABLE
68
CLUTCH DISC , Replaced By: A0112500403
68
CLUTCH DISC
68
CLUTCH DISC
68
CLUTCH DISC ASBESTOS-FREE LINING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
71
CLUTCH LINING , Replaced By: A0012528410
74
LEAF SPRING ,5 563495
77
RIVET LEAF SPRING TO CLUTCH DISC
80
RIVET , Replaced By: A0002524875
83
SCREW CLUTCH TO FLYWHEEL
999
ROLLER RELEASE LEVER,K 281332
999
PIN RELEASE LEVER,K 281331
