Поз.
Артикул
Описание
5
BATTERY
5
BATTERY
5
BATTERY , Replaced By: A0025413701
8
BOOT POS. POLE
8
BOOT , Replaced By: A0005464635
8
BOOT , Replaced By: A0005464635
10
BRACKET BATTERY CABLE TO CLUTCH BELL
11
BRACKET BATTERY CABLE TO TRANSMISSION
14
BRACKET BATTERY CABLE TO TRANSMISSION
17
CLAMP , Replaced By: A0005462675
17
CLAMPING PIECE BATTERY CABLE MOUNTING
20
SCREW , Replaced By: N304017006026
20
SCREW , Replaced By: N304017006026
23
NUT OIL TANK TO BRACKET
26
CONNECTOR BATTERY CABLE
29
SCREW SHIFT CASE TO SLOTTED GATE
32
SPRING WASHER LICENSE PLATE TO BRACKET
35
BOOT NEG. CABLE
38
LOCK WASHER CONNECTOR
41
NUT BRACKET TO SUPPORT AND TO END PIECE
44
BRACKET FUSE BOX
47
NUT OIL TANK TO BRACKET
47
NUT , Replaced By: N913002006009
50
FUSE BOXF2,243
50
FUSE BOX ,070378
51
FUSE BOX
51
DIODE BOX'A61'
53
FUSEC 7 - 2
56
SCREW LINE MOUNTING
59
RELAY (BATTERY MASTER SWITCH)
59
RELAY (BATTERY MASTER SWITCH)
62
RELAY (TIME RELAY) 90 SEK
65
DIODE ,K 182153
68
SWITCH ELECTRICAL COMPARTMENT,074035
71
SWITCH DOOR OPERATION, OUTSIDE
74
TAPPING SCREW BATTERY MASTER SWITCH, NOT USED
74
SCREW COVER PLATE TO BRACKET
77
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
CABLE HARNESS , WHEN ORDERING CABLE HARNESSES STATE THE FOLLOWING: VEHICLE, IDENT. NO., INSTALLATION LOCATION/FUNCTION,AND/OR THE HARNESS NUMB ER ON THE HARNESS OR THE PART NUMBER
