Поз.
Артикул
Описание
14
CLUTCH PRESSURE PLATE CLUTCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
14
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
21
SPRING SUSPENDED BELOW LEAF SPRING
21
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
28
SPRING SUSPENDED BELOW LEAF SPRING
28
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
35
PRESSURE PLATE CLUTCH PRESSURE PLATE
35
PRESSURE PLATE
42
RELEASE LEVER CLUTCH ACTUATION
49
SPINDLE FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
49
SPINDLE RELEASE LEVER,CLUTCH PRESSURE PLATE
56
SPINDLE FOR BEDDING THE LEVERS IN BRACKETS
63
ROLLER FOR BEDDING THE LEVERS IN BRACKETS
70
BRACKET RELEASE LEVER
77
LOCK PLATE RELEASE LEVER TO SHAFT
84
SLEEVE CLUTCH PRESSURE PLATE
91
FLANGE
91
FLANGE CLUTCH PRESSURE PLATE
91
FLANGE , Replaced By: A0002521245
98
PRESSURE SPRING SPRING STEEL WIRE DIA., 4.00 MM
105
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.75 MM
105
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.5 MM
112
LEAF SPRING THIGH SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
112
LEAF SPRING THIGH SPRING SUSPENDED BELOW LEAF SPRING
119
NUT FOR BRACKETS
126
LOCK FOR BRACKETS
133
SCREW RELEASE LEVER,BRACKET
147
SCREW CLUTCH TO FLYWHEEL
147
SCREW , Replaced By: N304017010055
147
SCREW , Replaced By: N304017010050
168
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
182
CLUTCH DISC
182
CLUTCH DISC ASBESTOS-FREE LINING
182
CLUTCH DISC
182
CLUTCH DISC ,5 234954
182
CLUTCH DISC ASBESTOS-FREE LINING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
182
CLUTCH DISC ASBESTOS-FREE LINING
182
CLUTCH DISC ASBESTOS-FREE LINING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
187
LEAF SPRING
187
LEAF SPRING
187
LEAF SPRING , REBORE HOLE IN SUPPORTING PLATE FROM 5.2MM TO 6.2MM, Replaced By: A0002523919, +002A0002523975
187
LEAF SPRING , REBORE HOLE IN SUPPORTING PLATE FROM 5.2MM TO 6.2MM, Replaced By: A0002523819, +002A0002523975
192
RIVET LEAF SPRING TO CLUTCH DISC
192
RIVET LEAF SPRING TO CLUTCH DISC 5X6 MM
197
CLUTCH LINING ASBESTOS-FREE
197
CLUTCH LINING
197
CLUTCH LINING ASBESTOS-FREE
197
CLUTCH LINING
197
CLUTCH LINING , Replaced By: A0022520010
197
CLUTCH LINING , Replaced By: A0012528310
202
RIVET , Replaced By: A0002524875
202
RIVET , Replaced By: A0002524675
202
RIVET , Replaced By: A0002523775
202
RIVET LINING WITH INTERMEDIATE SPRING,5 563495
202
RIVET LINING WITH CLUTCH DISC
202
RIVET LINING WITH CLUTCH DISC,5 563495
999
GREASE CUP ,5 190179, Replaced By: A6209880135, +001A6209970088
999
SHAFT (CLUTCH RELEASE SHAFT)
999
INTERMEDIATE PIECE ,5 190179, Replaced By: A6209970088, +001A6209880135
999
BEARING TOP
