Поз.
Артикул
Описание
4
BEARING BRACKET CLUTCH, IN CASE OF PEDAL BEARING BRACKET WITH SHIMS,DELIVER ADDITIONALLY: 3X 000939 008136,1X 620 290 03 34 UP TO IDENT NO. 5 238024, SEE SERVICE INFORMATION 29/4
4
BEARING BRACKET ,4 247126 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 655107, Replaced By: A3812901219
8
STUD BOLT BRACKET TO TRANSMISSION
8
STUD BOLT BRACKET TO CROSS MEMBER
12
WASHER EXHAUST MUFFLER TO STRAP
12
WASHER , Replaced By: N000125008443
16
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
16
NUT , Replaced By: N913004008001
16
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
29
GROMMET FIRE WALL,LEFT,IN FRONT LEGROOM,5 2380255 301948
30
STOP PEDAL ASSEMBLY
31
LOCK STOP TO BEARING BRACKET
31
LOCK RING , Replaced By: A0079942041
32
PEDAL , 415 5 014669 416 5 000516 417 4 972024, Replaced By: A6202900216
32
PEDAL CLUTCH PEDAL,4 915383
35
PIN CLUTCH PEDAL,5 238024
36
NUT SWITCH TO FLOOR PLATE
40
SPACER TUBE CLUTCH PEDAL
44
NEEDLE BEARING
44
NEEDLE BEARING , Replaced By: A0119813410
44
NEEDLE BEARING , Replaced By: A0119813410
48
PAD BRAKE
52
SPRING CLUTCH PEDAL RESET
56
PIVOT PIN PEDAL TO BEARING BRACKET
60
LOCK RING
64
LOCK PEDAL TO BEARING BRACKET
68
SCREW PUMP TO BRACKET
68
SCREW , Replaced By: N304017006016
72
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
76
SPRING RETAINER SPRING TO PUSH ROD
80
SPRING (DEAD CENTER SPRING) 35 MM
82
SPRING (DEAD CENTER SPRING) 23.2 MM
84
SPRING RETAINER SPRING TO PUSH ROD
92
NEEDLE BEARING JOINT TO PIN
92
NEEDLE BEARING JOINT TO PIN
92
NEEDLE BEARING JOINT TO PIN
92
NEEDLE BEARING JOINT TO PIN
96
NUT PUSH ROD
96
NUT , Replaced By: N308675010000
104
WASHER BRACKET TO CROSS MEMBER
108
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
110
REPAIR KIT DEAD CENTER SPRING
112
MASTER CYLINDER CLUTCH,LESS DE-AERATION
112
MASTER CYLINDER , Replaced By: A0012952906
112
MASTER CYLINDER , Replaced By: A0012956006
120
VALVE , Replaced By: A3075530107
120
VALVE CLUTCH SLAVE CYLINDER
124
PROTECTIVE CAP ,5 962906
124
PROTECTIVE CAP , Replaced By: A0004217187
128
INTERMEDIATE PIECE CLUTCH MASTER CYLINDER
132
PLUG
136
REPAIR KIT TO MASTER CYLINDER HAVING SYNTHETIC PISTON TO 001 295 60 06
136
REPAIR KIT TO MASTER CYLINDER HAVING ALUMINUM PISTON TO 000 295 68 06,001 295 29 06
136
REPAIR KIT , Replaced By: A0002903412
140
SCREW DELIVERY AND SUCTION HOSES TO COUPLING MOUTH CROSS MEMBER,5 598039
144
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
148
ROD MASTER CYLINDER
152
NUT
152
NUT , Replaced By: N304035008001
156
ARTICULATION PIECE CLUTCH MASTER CYLINDER
156
ARTICULATION PIECE CLUTCH MASTER CYLINDER
160
NEEDLE BEARING JOINT TO PIN
160
NEEDLE BEARING JOINT TO PIN
160
NEEDLE BEARING JOINT TO PIN
160
NEEDLE BEARING JOINT TO PIN
164
WASHER BRACKET TO CROSS MEMBER
168
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
173
BEARING BRACKET BRAKE
176
STUD BOLT BRACKET TO CROSS MEMBER
180
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
184
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
184
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
184
NUT , Replaced By: N913004008001
188
SPACER TUBE , Replaced By: A3604270253
188
SPACER TUBE , Replaced By: A3604270253
188
SPACER TUBE BEARING BRACKET TO STEERING COLUMN BRACKET
192
SCREW BEARING BRACKET TO STEERING COLUMN BRACKET
196
WASHER BEARING BRACKET TO STEERING COLUMN BRACKET
196
WASHER , Replaced By: A4039900040
200
SPRING WASHER STEERING COLUMN BRACKET TO CAB
204
PLUG CAB FLOOR SEALING
204
EXPANSION PLUG STEERING COLUMN END 20 MM,4 4307305 062722
204
EXPANSION PLUG , Replaced By: A0009973220
204
PLUG , Replaced By: A0009972020
212
PEDAL BRAKE
212
PEDAL BRAKE
216
SPACER TUBE
220
STOP
224
NEEDLE BEARING , Replaced By: A0119813410
224
NEEDLE BEARING , Replaced By: A0119813410
224
NEEDLE BEARING
228
PAD BRAKE
232
PIVOT PIN PEDAL TO BEARING BRACKET
236
LOCK RING
240
SPRING BRAKE PEDAL RELEASE SPRING
244
LOCK CLUTCH AND BRAKE PEDAL PINS TO BEARING BRACKETS
244
LOCK , Replaced By: A6732920073
248
SCREW , Replaced By: N304017006018
248
SCREW COVER PLATE TO COVER PLATE M 6 X 12
252
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
284
YOKE OPERATING ROD,K 202311
288
ROD PISTON ROD AND PUSH ROD
288
ROD , Replaced By: A9702900039
292
NUT , Replaced By: N304035008001
292
NUT
296
PIN ROD TO BRAKE PEDAL
300
WASHER BRACKET TO CROSS MEMBER
304
COTTER PIN LEVER TO ROD
304
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
ROD OVER-CENTER ACTING SPRING
999
ROD OVER-CENTER ACTING SPRING
999
PIN PUSH ROD TO PEDAL
999
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING M 6X60
