Поз.
Артикул
Описание
115
PLASTIC PIPE FUEL LINE 16X2 MM, ORDER BY THE METER
115
HOSE , Replaced By: A0009872927
120
UNION NUT
125
GLAND
130
SLEEVE
135
FITTING (PARTS KIT),LINE RUPTURE
140
CONNECTOR PRESSURE REGULATOR BREATHING
145
COUPLING MUFFLER TO SUBSTRUCTURE
145
CONNECTOR HOSE WIDTH, / I.D., 6 MM
150
ELBOW FITTING. T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22, M 12X1.5 / 12 MM, VOSS 230
155
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22, 12 MM, VOSS 230
160
T-FITTING PRESSURE REGULATOR ON GAS MIXER
163
FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
165
LINE FROM FOUR-CIRCUIT PROTECTIVE VALVE TO AIR RESERVOIR 9X12 MM, LENGTH AVAILABLE 3000 MM
165
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
165
HOSE , Replaced By: A0009872827
165
HOSE PLASTIC LINE 12X18 MM, ORDER BY THE METER
175
UNION NUT LINE CONNECTION, Replaced By: N000000006239
175
UNION NUT LINE CONNECTION
180
GLAND , Replaced By: A0019901967
180
SEAL CONE LINE CONNECTION
185
SLEEVE LINE CONNECTION
187
NUT BRACKET TO SIDE MEMBER
190
FITTING (PARTS KIT),LINE RUPTURE
195
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
195
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
195
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
195
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
200
O-RING CHECK VALVE TO AIR RESERVOIR
200
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
200
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
200
SEAL RING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTIONS: "23"
200
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
205
NUT CHECK VALVE TO AIR RESERVOIR
210
FITTING , Replaced By: N915059010001
210
FITTING BULKHEAD FITTING,CONNECTION: "10"
215
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
215
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 16
215
ELBOW FITTING9MM TO M22
220
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
230
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
235
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16, 4 MM
240
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
242
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION M 12X1.5, TO SA 48003
242
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION M 14X1.5, TO SA 48003
245
T-FITTING HOSE WIDTH, 9 MM,TO M 22
245
T-FITTING
245
T-FITTING , Replaced By: A0029909070
250
CONNECTOR COMPRESSED AIR PIPING,YB227219
250
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION TO M22, M12X1.5/9MM/9MM, VOSS 230
260
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
265
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
270
DISTRIBUTOR HOSE WIDTH, 9 MM,TO M 22
275
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
280
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
283
BRAKE HOSE DELIVERY LINE TO CLUTCH BOOSTER SA 48026
284
HOSE (PROTECTIVE HOSE), TO BE ORDERED ONLY FROM MESSRS FA.ZIPPERTECHNIK GMBH NEU-ISENBURG ORDER BY THE METER
285
BRACKET ON BRACKET AT SUBSTRUCTURE
287
BRACKET CHARGING CABLE TO ENGINE
289
BRACKET BELL HOUSING
290
SCREW PIPE CLAMP
290
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
290
SCREW , Replaced By: N304017008021
290
SCREW , Replaced By: N304017008016
295
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
300
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
300
CLAMP HOSE TO BRACKET 25/20,5 206397
300
CLAMP ,K 147121, Replaced By: N000000000319
300
CLAMP OIL DIPSTICK GUIDE TUBE TO BRACKET
300
CLAMP LINE MOUNTING SA 088202/01
300
CLAMP FRAME MOUNTED CABLE HARNESS TO CAB
305
SCREW CAB FLOOR COVERING M 6X25
305
SCREW COVER PLATE TO BRACKET
310
WASHER COMPRESSED AIR LINE TO BRACKET
310
WASHER , Replaced By: N009021006208
315
NUT , Replaced By: N913004006001
315
NUT PUMP TO BRACKET
325
HOSE BATTERY VENTING 11 X 2 MM, ORDER BY THE METER
335
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
335
PLASTIC PIPE AERATION, ORDER BY THE METER
335
LINE CLUTCH 8 X 1, LENGTH AVAILABLE 3000 MM
340
UNION NUT LINE MOUNTING,5 9363655 812730
340
UNION NUT LINE CONNECTION
345
GLAND LINE CONNECTION
345
GLAND LINE MOUNTING,5 9363655 812730
350
SLEEVE LINE CONNECTION
355
FITTING (PARTS KIT),LINE RUPTURE
370
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
370
BANJO UNION HOSE WIDTH, / I.D., 6/10 MM
370
BANJO UNION6/14 MM
370
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
370
FITTING
375
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
375
BANJO UNIONSA 48025
385
BRAKE HOSE SPRING-LOAD ACCUMULATOR CYLINDER TWOWAY VALVE,LEFT
385
BRAKE HOSE AT CYLINDER, TO BE ADAPTED DURING ASSEMBLY
390
TS DOUBLE FITTING SOLENOID VALVE
395
FITTING
400
COUPLING DRIVER'S SEAT SA 48084
415
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
420
CONNECTOR , Replaced By: A0029905478
420
CONNECTOR HOSE WIDTH, 6 MM, TO M22
425
CONNECTOR PRESSURE GAUGE,CONNECTION: "11,12,21,22"
430
T-FITTING 3/2-WAY VALVE,CONNECTION: "33", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
432
ELBOW FITTING. T-FITTING LINE CONNECTION TO ENGINE TO M16
433
FITTING DRIVER'S SEAT SA 48084
434
T-FITTING EXHAUST-BRAKE POWER CYLINDER
435
ELBOW FITTING HOSE WIDTH, 6 MM,TO M 22
440
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION M 14 / 6 MM
442
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION,K 186868
445
ELBOW FITTING HOSE WIDTH, 6 MM,TO M22
445
ELBOW FITTING HOSE WIDTH, 9 MM,TO M22
445
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION 6 MM TO M16
445
ELBOW FITTING , Replaced By: A0049905371
448
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
448
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
448
FITTING FROM PUMP TO CYLINDER
449
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
450
FITTING (PARTS KIT),LINE RUPTURE
455
LOCKING CONE AT T-FITTING,038111
460
NUT TWO-CIRCUIT BRAKE VALVE,CONNECTIONS: "21,22", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
470
BRACKET COMPRESSED AIR LINE MOUNTING SA 48042
475
CLAMP SENSOR CABLE TO BRACKET
475
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
475
CLAMP LINE MOUNTING SA 088202/01
475
CLAMP ,K 147121, Replaced By: N000000000319
480
SCREW CAB FLOOR COVERING M 6X25
485
NUT , Replaced By: N913004006001
485
NUT PUMP TO BRACKET
999
T-FITTING AIR DEHYDRATOR,CONNECTION: "2,21"
999
BRACKET COMPRESSED AIR LINE MOUNTING SA 48042
999
CONNECTION FITTING HIGH PRESSURE LINE TO STEERING
