Поз.
Артикул
Описание
140
UNION NUT LINE CONNECTION
144
BANJO UNION , Replaced By: N915052006002
144
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
752
VALVE (RELAY VALVE) WABCO
754
VALVE (RELAY VALVE) GRAU
756
VALVE (RELAY VALVE) BOSCH
758
VALVE (RELAY VALVE) KNORR
759
SEAL RING22.3X2.4 MM,GRAU
760
VALVE SEATGRAU
761
SEAL RINGTO 000 429 28 95,GRAU
762
SEAL RING28X2 MM,GRAU
763
SEAL RING86X2 MM,GRAU
764
GASKET34X2X6 MM,GRAU
765
REPAIR KITWABCO
766
REPAIR KIT , Replaced By: A0004201071
766
VALVE GASKET KIT TO 003 429 16 44,BOSCH,UP TO 03.82
766
VALVEBOSCH
767
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
767
REPAIR KIT , Replaced By: A0004301109
768
REPAIR KITKNORR
770
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
772
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
774
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
776
FITTING DELIVERY LINE TO PUMP
778
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
780
THRUST RING CHECK VALVE TO AIR RESERVOIR
780
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
781
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
782
O-RING CHECK VALVE TO AIR RESERVOIR
784
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
786
BRACKET RELAY VALVE TO CROSS MEMBER
788
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
788
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
788
NUT , Replaced By: N913004008001
790
SCREW BRACKET TO CROSS CONNECTION STRUT
790
SCREW , Replaced By: N304017008034
792
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
792
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
792
NUT , Replaced By: N913004008001
999
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
999
SEAL RING , Replaced By: N007603012121
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
999
WASHER , Replaced By: N009021005205
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 350368
999
CLAMPING SLEEVEKNORR
999
WASHER STRAP TO SUPPORT
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
999
STRAP AIR RESERVOIR III,5 088362
999
STRAP AIR RESERVOIR TO BRACKET
999
ADHESIVE FOIL GUIDE SIGN
999
SEAL RINGKNORR
999
REPAIR KIT TRISTOP CYLINDER TO 009 420 22 18, KNORR
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO
999
REPAIR KITTO 002 430 98 81,99 81,KNORR
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,000 2
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
999
ELBOW FITTING ,5 433281
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
VALVE , Replaced By: A0034295344
999
ELBOW FITTING AIR RESERVOIR,CONNECTION: "13", PLUG CONNECTION
999
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
T-FITTING LEFT AND RIGHT BRAKE HOSES
999
PROTECTIVE CAPKNORR
999
PROTECTIVE CAPTO BOSCH
999
PROTECTIVE CAPTO WABCO
999
REPAIR KIT , Replaced By: A0044201724, +002A0044201324
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
PLUG
999
PLUGTO 009 420 22 18,008 420 20 18
999
HANDLEKNORR
999
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
999
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
CONNECTOR REPAIR SIZE
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
DIAPHRAGMTO 008 420 61 18,009 420 22 18
999
VALVEWABCO
999
DIAPHRAGM , Replaced By: A0004314128
999
DIAPHRAGM , Replaced By: A0004314128
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE WABCO
999
REPAIR KITTO 002 431 83 06, KNORR 90309
999
REPAIR KITTO 000 429 26 95,KNORR
999
DIAPHRAGM
999
DIAPHRAGM , Replaced By: A0004290745
999
PROTECTIVE TUBE , Replaced By: A0004290286
999
SEAL RINGKNORR
999
CUPTO 007 420 68 18,WABCO
