Поз.
Артикул
Описание
140
BANJO UNION FROM BULKHEAD FITTING TO PRESSURE REGULATOR
140
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
590
VALVE (RELAY VALVE) BOSCH
591
VALVE (RELAY VALVE) KNORR
592
VALVE (RELAY VALVE) GRAU
596
REPAIR KITKNORR
597
VALVEBOSCH
597
VALVE GASKET KIT TO 003 429 16 44,BOSCH,UP TO 03.82
597
REPAIR KIT , Replaced By: A0004201071
598
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
598
REPAIR KIT , Replaced By: A0004301109
609
THRUST RING CHECK VALVE TO AIR RESERVOIR
609
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
612
O-RING CHECK VALVE TO AIR RESERVOIR
613
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
614
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
615
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
616
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
617
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
618
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
632
FITTING DIAPHRAGM CYLINDER,CONNECTION:
634
FITTING LEFT AND RIGHT BRAKE HOSES
999
VALVETO 003 429 04 44,WABCO
999
GUIDE , Replaced By: N071752014000
999
PROTECTIVE CAPTO 008 420 62 18,KNORR
999
VALVE TAPPETTO 002 429 96 44,VOSS
999
FILTER ELEMENTTO 000 429 28 95,GRAU
999
FILTER ELEMENT MAJOR TO 000 429 27 95,WABCO
999
FILTER ELEMENT MINOR TO 000 429 27 95,WABCO
999
THRUST WASHERTO 003 429 12 44,SCHAEFER
999
SEAL CONETO 003 429 12 44,SCHAEFER
999
FILTER ELEMENTTO 000 429 25 95,BOSCH
999
DIAPHRAGMTO 000 429 28 95,GRAU
999
DIAPHRAGMTO 000 429 25 95,BOSCH
999
SEAL RINGTO 002 429 96 44,VOSS
999
ADAPTER FITTING , Replaced By: A0069970072
999
ADAPTER FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "22"
999
ADAPTER FITTING LINE CONNECTION TO ENGINE
999
ADAPTER FITTING PASSAGE OF LINE THRU SIDE MEMBER,5 395033
999
REPAIR KIT BRAKE POWER REGULATOR TO 002 431 05 12,KNORR
999
REPAIR KITTO 001 431 93 06,BOSCH 62201,K 087820
999
REPAIR KITTO 000 429 26 95,KNORR
999
REPAIR KITTO 002 431 83 06, KNORR 90309
999
REPAIR KIT PRESSURE REGULATOR BOSCH,241
999
REPAIR KIT DIAPHRAGM PART BOSCH,209
999
REPAIR KIT BRAKE POWER REGULATOR BOSCH
999
REPAIR KIT VALVE BOSCH
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE WABCO
999
REPAIR KITTO 000 430 56 81,WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KIT SEAL RING BOSCH,209
999
GASKET34X2X6 MM,GRAU
999
TEST CONNECTION
999
VALVE SEATGRAU
999
DIAPHRAGMTO 007 420 42 18,KNORR
999
DIAPHRAGMBOSCH,K 262627
999
VALVE
999
VALVEWABCO
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
SEALING CORDTO 000 429 27 95, WABCO
999
CONNECTOR REPAIR SIZE
999
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK ELECTRIC CABLE THRU CAB FLOOR
999
SCREW. UNION SCREW LINE CONNECTION
999
HANDLEKNORR
999
COUPLING FROM CHECK VALVE TO PARKING BRAKE VALVE
999
PLUG
999
VALVE PARKING BRAKE VALVE BOSCH
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
VALVE PARKING BRAKE VALVE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0024309981
999
PROTECTIVE CAPTO WABCO
999
PROTECTIVE CAPTO BOSCH
999
PROTECTIVE CAPKNORR
999
REPAIR KIT COVERING TO 001 431 36 12
999
SEAL RING28X2 MM,GRAU
999
SEAL RING86X2 MM,GRAU
999
VALVE , Replaced By: A0034315006
999
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 087820 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034315006
999
SEALING CORD38X8 MM
999
BANJO UNION BRAKE POWER REGULATOR W/RELAY VALVE, CONNECTION: "40"
999
T-FITTING RIGHT SPRING LOAD ACCUMULATOR BRAKE CYLINDER,CONNECTION "1"
999
ELBOW FITTING RELAY VALVE,CONNECTIONS: "21,22"
999
T-FITTING LEFT AND RIGHT BRAKE HOSES
999
FITTING AIR RESERVOIR,CONNECTION: "11"
999
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
ELBOW FITTING AIR RESERVOIR,CONNECTION: "13", PLUG CONNECTION
999
FITTING AIR RESERVOIR,CONNECTION: "13"
999
SEAL RINGTO 000 429 25 95,BOSCH
999
REPAIR KIT. BRAKE CYLINDER DIAPHRAGM PART TO 007 420 42 18, KNORR
999
VALVE , Replaced By: A0034295344
999
VALVE (CHECK VALVE) VOSS
999
REPAIR KIT VALVE KIT WABCO,5 148812
999
VALVE PARKING BRAKE VALVE KNORR
999
VALVE , Replaced By: A0024312706
999
VALVE , Replaced By: A0024319106
999
PRESSURE REGULATORKNORR,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
VALVE , Replaced By: A0034315006
999
REPAIR KITGRAU,5 148812
999
REPAIR KITTO 001 431 12 06, KNORR 3200
999
REPAIR KIT , Replaced By: A0034303181
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 433281
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
999
VALVE (CHECK VALVE) SCHAEFER
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,000 2
999
REPAIR KITTO 002 430 98 81,99 81,KNORR
999
REPAIR KITTO 001 430 56 81,001 430 57 81
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO
999
REPAIR KITTO 001 430 66 81,001 430 67 81,KNORR
999
SEAL RING , Replaced By: A0289972348
999
SPRINGTO 000 429 27 95,WABCO
999
SEAL RING22.3X2.4 MM,GRAU
999
SEAL RINGTO 000 429 28 95,GRAU
999
FITTING SHUTTLE VALVE,CONNECTION: "20",5 434013
999
WHEEL BRAKE CYLINDER TRISTOP CYLINDER KNORR
999
WHEEL BRAKE CYLINDER TRISTOP CYLINDER WABCO
999
WHEEL BRAKE CYLINDER TRISTOP CYLINDER WABCO
999
WHEEL BRAKE CYLINDER TRISTOP CYLINDER KNORR
999
WHEEL BRAKE CYLINDER TRISTOP CYLINDER BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
WHEEL BRAKE CYLINDER TRISTOP CYLINDER BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
SEAL RING34.6X2.6 MM
999
SEAL RING19.3X2.4 MM,TO 003 429 04 44,WABCO
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RING28.4X2.6 MM
999
SEAL RING56X1.7 MM
999
SEAL RING , Replaced By: A0049972248
999
SEAL RING , Replaced By: A0009870746
999
WHEEL BRAKE CYLINDER TRISTOP CYLINDER GRAU
999
WHEEL BRAKE CYLINDER TRISTOP CYLINDER GRAU
999
SEAL RING
999
SEAL RING13.6X2 MM,TO 003 429 12 44,SCHAEFER
999
SEAL RING15.3X2.4 MM,TO 003 429 12 44,SCHAEFER
999
SEAL RINGTO 000 429 25 95,BOSCH
999
SEAL RINGTO 000 429 27 95, WABCO
999
WASHER TRAILER COUPLING TO REAR CROSS MEMBER
999
WASHER BRACKET TO CROSS MEMBER,5 434013
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
BRACKET LINK
999
ROD , Replaced By: A3954310192
999
BRACKET BRAKE POWER REGULATOR
999
ADHESIVE FOIL GUIDE SIGN
999
BEARING BRACKET WHEEL CYLINDER, IN CASE OF STEEL AXLE
999
BRACKET METAL SPRING BELLOWS
999
ROD BRAKE POWER REGULATOR CONTROL
999
BRACKET HEAT SHIELD
999
BRACKET RIGHT, TO BE ADAPTED DURING ASSEMBLY
999
BRACKET LEFT FRONT
999
BRACKET BRAKE LINE MOUNTING
999
SEAL RING TO SEAL CABLE HARNESS OPENING IN CAB
999
LOCK BRAKE HOSE TO ANGLE
999
BRACKET FOR PASSAGE OF LINE
999
BRACKET FOR PASSAGE OF LINE
999
STRAP AIR RESERVOIR TO BRACKET
999
STRAP AIR RESERVOIR III,5 088362
999
BRACKET , NOT USED
999
BRACKET METAL SPRING BELLOWS
999
BRACKET METAL SPRING BELLOWS,REAR AXLE I
999
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
999
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
LOCK WASHER METAL SPRING BELLOWS,5 197195
999
NUT , Replaced By: N308675016001
999
NUT COMPRESSED AIR LINE THRU FRAME,5 395034
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017008040
999
SCREW HAND PUMP TO BRACKET
999
SCREW BRACKET TO REAR AXLE M 20X1.5X55
999
SCREW BRACKET TO REAR AXLE M 20X1.5X45
999
WASHER STRAP TO SUPPORT
999
CLAMPING SLEEVEKNORR
999
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
999
BULKHEAD FITTING THROUGH SIDE MEMBER
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 350368
999
CLAMPING SLEEVE , IN CASE OF STEEL AXLE
999
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
999
SEAL RING FUEL LINE TO FEED PUMP
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
SHEET METAL SCREW BRACKET TO ELECTRICAL APPARATUS COMPARTMENT 4,8X19
999
WASHER , Replaced By: N009021005205
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
999
YOKETO 008 420 95 18,008 420 97 18,BOSCH
999
NUT CHECK VALVE TO AIR RESERVOIR
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
NUT BRACKET TO SIDE MEMBER
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW BRACKET TO SIDE MEMBER
999
NUT FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "22",4 821954
999
LOCK RING PULL ROD TO LINK
999
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
999
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
