Поз.
Артикул
Описание
5
RADIATOR
5
RADIATOR"BEHR"
5
RADIATOR
56
SCREW PLUG , Replaced By: N007604014101
56
SCREW PLUG WATER DRAIN
61
SEAL RING FUEL LINE TO FEED PUMP
86
FAN SHROUD RADIATOR
86
FAN SHROUD RADIATOR
86
FAN SHROUD RADIATOR
91
CLIP-TYPE NUT FAN SHROUD TO RADIATOR
93
DETENT FAN SHROUD TO RADIATOR
94
LOCK , Replaced By: N912002008003
94
LOCK PULL TO FASTENER
96
BOOT FAN SHROUD TO FAN RING
101
BOOT , Replaced By: A6205050286
101
BOOT RADIATOR
102
BRACKET BOOT
103
WASHER , Replaced By: N000125006421
103
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
103
WASHER COMPRESSED AIR LINE TO BRACKET
104
SCREW , Replaced By: N304017006020
104
SCREW LICENSE PLATE TO BRACKET
105
SPRING WASHER LICENSE PLATE TO BRACKET
146
SCREW , Replaced By: N304017010028
146
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
151
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
SCREW WATER DRAIN
999
LOCK
999
HOSE DE-AERATION LINE, ORDER BY THE METER, Replaced By: A9575011982
999
BRACKET HEATING PIPE TO FAN SHROUD BRACKET
999
LINE HEATING AND BREATHING
999
HOSE , Replaced By: A0805013482
999
HOSE DE-AERATION LINE, ORDER BY THE METER
999
SEAL RING , Replaced By: N007603010110
999
SEAL RING PNEUMATIC VALVE
999
SEAL RING LINE CONNECTION
999
HOLLOW SCREW LINE CONNECTION
999
HOLLOW SCREW HEATING CONNECTION
999
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
999
BANJO UNION HOSE WIDTH, / I.D., 6/10 MM
