Поз.
Артикул
Описание
5
WHEEL BRAKE CYLINDER
5
WHEEL BRAKE CYLINDERFA.VARGA
8
VALVE BREATHER
11
PROTECTIVE CAPTO001 295 91 07
14
REPAIR KITTO 688 420 01 18
17
THRUST PIN WHEEL CYLINDER
20
SCREW , Replaced By: N304017008034
23
PIN BREATHER VALVE CONNECTION
26
ADJUSTER , Replaced By: A6704200438
26
ADJUSTER MECHANICAL
29
SCREW ADJUSTER TO 601 420 20 38,670 420 03 38, ONLY VALID IF MERCEDES-BENZ BRAKE IS FITTED
32
CUP , Replaced By: A6014230886
35
PROTECTIVE CAP , Replaced By: A6014230886
38
SCREW ADJUSTER TO BRAKE ANCHOR PLATE
41
WASHER STRUT TO CONSOLE
44
LEVER HAND BRAKE LEVER,495609
47
LEVER HAND BRAKE,P 060996
50
ROD HAND BRAKE
53
PIN HAND BRAKE
56
LOCK PLATE INTERMEDIATE BEARING
59
LOCK PLATETO 002 250 95 04,003 250 20 04
62
SPRING HAND BRAKE LEVER TO BRAKE ANCHOR PLATE, FROM REAR AXLE571724 - FOR R.H.D. FROM REAR AXLE579081 - FOR L.H.D.
65
RETAINER HAND BRAKE LEVER TO BRAKE ANCHOR PLATE, HYDRAULIC BRAKE
68
RETAINER BRAKE SHOE TO BRAKE ANCHOR
71
THRUST PIN HAND BRAKE LEVER TO BRAKE ANCHOR PLATE 56 MM, FROM REAR AXLE571724 - FOR R.H.D. FROM REAR AXLE579081 - FOR L.H.D.
74
BRAKE CABLE LEFT
74
BRAKE CABLE RIGHT
77
SCREW CARRIER TO BRACKET
999
LOCK RING TORSION BAR
999
ADJUSTING PIN ADJUSTER TO 672 420 01 38,02 38, ONLY VALID IF MERCEDES-BENZ BRAKE IS FITTED
999
CUP READJUSTMENT OF REAR WHEEL BRAKE TO 601 420 20 38, ONLY VALID IF MERCEDES-BENZ BRAKE IS FITTED
999
SEAL RING READJUSTMENT OF REAR WHEEL BRAKE TO 601 420 20 38, ONLY VALID IF MERCEDES-BENZ BRAKE IS FITTED
