Поз.
Артикул
Описание
10
PITMAN ARM
10
PITMAN ARM
10
PITMAN ARM
10
PITMAN ARM STEERING GEAR
10
PITMAN ARM
10
PITMAN ARM
10
PITMAN ARM STEERING GEAR
10
PITMAN ARM , Replaced By: A9454630101
15
NUT PITMAN ARM TO STEERING BOX ASSEMBLY
15
NUTM42X1.5
15
NUT PITMAN ARM TO STEERING BOX ASSEMBLY M45X1.5
20
DRAG LINK FROM PITMAN ARM TO FRONT AXLE I
20
DRAG LINK FROM PITMAN ARM TO FRONT AXLE I
20
DRAG LINK FROM PITMAN ARM TO FRONT AXLE I
20
DRAG LINK FROM PITMAN ARM TO FRONT AXLE I
30
DRAG LINK END R.H. THREAD
30
DRAG LINK ENDEHRENREICH
40
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
40
CLAMP CLAMP, ONE-HOLE
40
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER, TO 002 460 14 05, 15 05,K 226468
40
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
50
HEXAGON HEAD BOLTM10X1X50
50
SCREW STRUT TO FRAME M 12X62
55
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
55
NUT REINFORCEMENT TO BRACKET
75
STEERING ARM LEFT STEERING KNUCKLE
75
STEERING ARM LEFT STEERING KNUCKLE
75
STEERING ARM LEFT STEERING KNUCKLE
75
STEERING ARM LH LEFT STEERING KNUCKLE
75
STEERING ARM LEFT STEERING KNUCKLE
75
STEERING ARM RIGHT FRONT
110
DRAG LINK FROM STEERING INTERMEDIATE BRACKET II TO FRONT AXLE II
110
DRAG LINK FROM STEERING INTERMEDIATE BRACKET II TO FRONT AXLE II
120
BALL JOINT L.H. THREAD
120
DRAG LINK END R.H. THREAD
120
DRAG LINK END R.H. THREAD
120
DRAG LINK END L.H. THREAD
125
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER, TO 002 460 14 05, 15 05,K 226468
130
SCREW STRUT TO FRAME M 12X62
135
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
430
DRAG LINK FROM INTERMEDIATE LEVER I TO INTERMEDIATE LEVER II, REPAIR IMPOSSIBLE
430
DRAG LINK FROM INTERMEDIATE LEVER I TO INTERMEDIATE LEVER II
430
DRAG LINK FROM STEERING INTERMEDIATE BRACKET I TO STEERING INTERMEDIATE BRACKET II
430
DRAG LINK FROM INTERMEDIATE LEVER I TO INTERMEDIATE LEVER II, Replaced By: A6624602205
440
DRAG LINK FROM PITMAN ARM TO FRONT AXLE I
450
DRAG LINK ENDEHRENREICH
450
DRAG LINK END R.H. THREAD
450
DRAG LINK END L.H. THREAD
450
DRAG LINK END R.H. THREAD
450
DRAG LINK END R.H. THREAD EHRENREICH
460
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
460
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER, TO 002 460 14 05, 15 05,K 226468
460
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
465
SCREW STRUT TO FRAME M 12X62
470
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
523
DRAG LINK FROM STEERING INTERMEDIATE BRACKET II TO STEERING INTERMEDIATE BRACKET III
523
DRAG LINK FROM STEERING INTERMEDIATE BRACKET II TO STEERING INTERMEDIATE BRACKET III
525
DRAG LINK FROM STEERING INTERMEDIATE BRACKET II TO STEERING INTERMEDIATE BRACKET III
570
DRAG LINK END L.H. THREAD TO A 662 463 12 15
570
DRAG LINK END R.H. THREAD
570
DRAG LINK END R.H. THREAD
570
BALL JOINT R.H. THREAD
570
BALL JOINT L.H. THREAD TRW
570
DRAG LINK ENDEHRENREICH
570
DRAG LINK END R.H. THREAD
570
DRAG LINK END L.H. THREAD
570
DRAG LINK END R.H. THREAD
570
DRAG LINK END L.H. THREAD EHRENREICH
570
BALL JOINT L.H. THREAD
580
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER, TO 002 460 14 05, 15 05,K 226468
580
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
580
CLAMP CLAMP, ONE-HOLE
580
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
585
SCREW STRUT TO FRAME M 12X62
585
HEXAGON HEAD BOLTM10X1X50
590
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
590
NUT REINFORCEMENT TO BRACKET
592
DRAG LINK FROM STEERING INTERMEDIATE BRACKET II TO FRONT AXLE II
594
DRAG LINK END R.H. THREAD
594
BALL JOINT L.H. THREAD
598
CLAMP CLAMP, ONE-HOLE
601
HEXAGON HEAD BOLTM10X1X50
603
NUT REINFORCEMENT TO BRACKET
605
DRAG LINK FROM STEERING INTERMEDIATE BRACKET III TO STEERING INTERMEDIATE BRACKET IV
605
DRAG LINK FROM STEERING INTERMEDIATE BRACKET III TO FRONT AXLE II
650
BALL JOINT L.H. THREAD TRW
650
BALL JOINT R.H. THREAD
650
DRAG LINK END R.H. THREAD EHRENREICH
650
DRAG LINK END , Replaced By: A0014607748
650
DRAG LINK END , Replaced By: A0014607848
650
DRAG LINK END L.H. THREAD TRW, Replaced By: A0024600348
660
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER, TO 002 460 14 05, 15 05,K 226468
670
SCREW STRUT TO FRAME M 12X62
670
SCREW CONSOLE TO CROSS MEMBER
680
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
700
STEERING ARM LEFT STEERING KNUCKLE
800
NUT DRAG LINK TO LEVER
800
NUT DRAG LINK END M 24X1.5
800
NUT STEERING WHEEL TO STEERING COLUMN
