Поз.
Артикул
Описание
5
BATTERY12V/100AH, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 37458720070910, Replaced By: A0009823308
5
BATTERY PARTS KIT
5
BATTERY12 V / 66 AH VARTA
5
BATTERY100 AH
5
BATTERY12 V / 66 AH VARTA, Replaced By: A0009823708
15
BOOT , Replaced By: A0015460835
15
BOOT POS. POLE
20
RAIL BATTERY
25
WASHER COMPRESSED AIR LINE TO BRACKET
25
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
30
CAP NUT SWITCH TO CAB FRONT PANEL
35
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
40
STOP PLUG. PLUG ON BATTERY,LATERALLY
45
ELBOW FITTING. DISTRIBUTOR
50
HOSE , ORDER BY THE METER
50
HOSE BREATHER LINE 65X45 MM, ORDER BY THE METER
55
GROMMET FOR PASSAGE OF LINE, UP TO IDENT NO. 5 033766,ALSO INSTALLED ON 5 039977
55
GROMMET CLOCK
60
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR
65
CABLE HARNESS. WIRING HARNESS STARTING CABLE
65
CABLE HARNESS. WIRING HARNESS STARTING CABLE
67
CABLE DUCT
70
CABLE SHOE FROM BATTERY POS.POLE TO STARTING MOTOR
75
CLAMPING PIECE POS. POLE
80
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
80
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
85
NUT SPRING-LOADED PUSH ROD
85
NUT HORN TO BRACKET M8
85
NUT
85
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
87
BOOT. PROTECTIVE CAP CABLE TO STARTING MOTOR,TERMINAL 30, R 69835220040630569835220040630
90
NUT HORN TO BRACKET M8
90
NUT RELAY TO BRACKET M5
95
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
100
GROMMET STARTING CABLE TO STARTING MOTOR
105
ELECTRIC CABLE (GROUND CABLE)
110
SOLDERING TERMINAL NEG.POLE
110
CLAMPING PIECE BATTERY
110
CLAMPING PIECE BATTERY
115
CABLE SHOE NEG. CABLE
115
CABLE SHOE BATTERY CABLE
120
GROUND STRAP FROM ENGINE TO FRAME
120
NEG. CABLE , Replaced By: A9015400741
125
SPRING WASHER , Replaced By: N000137008212
125
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
130
NUT
135
COMBINATION BOLT
140
RELAY (BATTERY CUT-OFF RELAY)
142
RELAY (BATTERY CUT-OFF RELAY) 12 V
145
PIN BUSHING HOUSING BIPOLAR
150
PIN BUSHING WITH DETENT,LESS CATCH FOR HOUSING 0.5-1.0 MM2
150
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
152
PIN BUSHING HOUSING FROM BATTERY TO CONTACTOR
153
CONTACT SPRING0.5MM2-1.0MM2, A 843748 X 019421
155
TAPPING SCREW STEERING COLUMN MOUNTED SWITCH PLUGCONNECTION 4.8X13
155
TAPPING SCREW STEERING COLUMN MOUNTED SWITCH PLUGCONNECTION
160
CONTACTOR RELAY
165
SCREW RELAY
170
LOCK WASHER BRACKET TO STEERING COLUMN END
175
NUT IN CASE OF SUBSEQUENT INSTALLATION
175
NUT , Replaced By: N304032005005
