Поз.
Артикул
Описание
10
WHEEL HOUSE LEFT
10
WHEELHOUSE LEFT, Replaced By: A2126200550
10
WHEEL HOUSE LEFT, Replaced By: A2126203300
20
SUPPORT LEFT
30
SIDE MEMBER LEFT
50
BRACKET LEFT
60
LONGITUDINAL MEMBER LEFT, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 50904920110801, Replaced By: A2126200187
60
LONGITUDINAL MEMBER LEFT
63
RIVET NUT
65
BRACKET LEFT REAR FENDER
67
LONGITUDINAL MEMBER LEFT
70
SUPPORT TOP LEFT
75
PLATE ON CARRIER AT TOP LEFT
80
SUPPORT LEFT, PEDAL FLOOR PANEL, A 20130629
80
CROSS MEMBER LEFT, PEDAL FLOOR PANEL, A 20130629
90
STRUT LEFT
95
REINFORCEMENT STRUT TO LEFT SIDE PANEL
100
WHEEL HOUSE RIGHT
100
WHEELHOUSE RIGHT, Replaced By: A2126200650
100
WHEEL HOUSE RIGHT
110
SUPPORT RIGHT
120
SIDE MEMBER RIGHT
140
BRACKET RIGHT
150
LONGITUDINAL MEMBER RIGHT
150
LONGITUDINAL MEMBER RIGHT, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 50904920110801, Replaced By: A2126200287
153
RIVET NUT
155
BRACKET RIGHT REAR FENDER
157
LONGITUDINAL MEMBER RIGHT
160
SUPPORT TOP RIGHT
165
PLATE ON CARRIER AT TOP LEFT
170
SUPPORT RIGHT, PEDAL FLOOR PANEL
180
STRUT RIGHT
185
REINFORCEMENT STRUT TO RIGHT SIDE PANEL
300
INTEGRAL CARRIER , F 17963220080501
310
BLIND CLINCH NUT IN FRAME-TYPE INTEGRAL SUPPORT M10
320
PLATE STEERING TO FRAME-TYPE INTEGRAL SUPPORT
320
PLATE STEERING TO FRAME-TYPE INTEGRAL SUPPORT
323
HEXAGON HEAD BOLT. SCREW FRONT EXHAUST PIPE TO BRACKET
340
THREAD FORMING SCREW FRONT FRAME-TYPE INTEGRAL SUPPORT M14X1,5X53
340
BOLT FRONT FRAME-TYPE INTEGRAL SUPPORT M14X1,5-SGX50
350
BOLT REAR FRAME-TYPE INTEGRAL SUPPORT M14X1,5-SGX100
380
EXPANSION PLUG ELECTRIC CABLE THRU FIRE WALL,4 9400475 187082
500
SCREW (PARTS KIT) PARTITION PANEL TO WHEELHOUSE
505
BLIND RIVET REPAIR SOLUTION 6,4 X 12MM / 1-3,5MM, NO LONGER AVAILABLE RIVET ONLY VALID FOR BR222. REPAIR INFORMATION SEE WIS. ADDITIONAL INFORMATION ON TECHNICAL MARKET SUPPORT
510
WELD STUD GROUND CONNECTION M8
510
WELD STUD GROUND CONNECTION M6
