Mercedes A0019972572 - ФИТИНГ

O 303 301.110

32 SPRINGS AND SUSPENSION - 001 SPRINGS AND SUSPENSION IL. 1

Поз.
Артикул
Описание
11
A0039971236
VALVE ENGINE SHUT-OFF
14
A0004311468
VALVE PART
18
A0109974448
SEAL RING24X2 MM
20
A0079970248
SEAL RINGWABCO
23
A0049970640
SEAL RING VALVE TO VALVE
29
A0014310087
PROTECTIVE CAPWABCO
30
A0004305660
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
32
N080705012003
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
34
A0009905471
ELBOW FITTING LINE CONNECTIONS
36
A0004290827
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
38
A0019875046
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
41
N913004008005
NUT BRACKET TO SIDE MEMBER
999
A0019972572
FITTING LINE CONNECTION, Replaced By: N000000006446
