Поз.
Артикул
Описание
37
FUEL FILTER , EXHAUST STOCK OF OLD PARTS NUMBER FIRST 035135, Replaced By: A0010921901
37
FILTERHENGST
37
FUEL FILTER , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 035153, Replaced By: A0010921801
37
FILTER
40
FILTER ELEMENT ,D 031294
40
FILTER ELEMENT REPAIR KIT
43
SCREW REAR AXLE REGULATING SOLENOID VALVE
43
SCREW , Replaced By: N304014008007
43
SCREW FRONT AXLE REGULATING SOLENOID VALVE
46
SEAL RING SCREW PLUG
49
SCREW PLUG , Replaced By: N007604014110
49
SCREW PLUG FUEL TANK
49
SCREW PLUG FUEL TANK BREATHING M 14X1.5
52
SEAL RINGTO 000 553 03 05,000 553 18 05,
55
SEAL RING CONTROL VALVE,5 093991
55
SEAL RING SCREW PLUG
55
SEAL RING SCREW PLUG
55
SEAL RING (BREATHER SCREW) TO 001 477 50 01
58
SCREW BREATHER TO 001 477 14 01
58
SCREW , Replaced By: A4420740071
58
SCREW BREATHER TO 422 090 02 52
58
SCREW BREATHER TO 001 477 50 01
61
SEAL RING ,D 031246
64
HOUSING
67
FILTER HEAD
67
COVERTO 001 477 49 01
76
SCREW BRACKET TO FRAME
79
LOCK WASHER FITTING TO BRACKET
82
LINE FEED AND RETURN LINES TO FUEL TANK 10X0.7 MM, LENGTH AVAILABLE 25.000 MM
85
LINE FUEL COMPENSATING
85
LINE FUEL COMPENSATING
85
LINE FUEL COMPENSATING
85
LINE FUEL COMPENSATING
85
LINE FUEL COMPENSATING
85
LINE WITH BANJO UNION
88
LINE FROM TANK TO SCREW CONNECTION, 741958
88
LINE FROM TANK TO SCREW CONNECTION, 741958
88
LINE FROM TANK TO SCREW CONNECTION, 741958
88
LINE FROM TANK TO SCREW CONNECTION, 741958
88
LINE WITH FITTING 1000 MM
91
LINE WITH SEAL CONE 3000 MM, 740810
91
LINE WITH SEAL CONE 3000 MM, 740810
91
LINE WITH SEAL CONE 1000 MM, TYPE 1113B UP TO CHASSIS 604683,TYP LP 1517 UP TO CHASSIS 600412,TYPE LP 1317 UP TO CHASSIS 601123,TYPE LP 911 B UP TO CHASSIS601688 CONTINUED,SEE FOOTNOTE 003
91
LINE WITH SEAL CONE 1000 MM, TYPE 1113B UP TO CHASSIS 604683,TYP LP 1517 UP TO CHASSIS 600412,TYPE LP 1317 UP TO CHASSIS 601123,TYPE LP 911 B UP TO CHASSIS601688 CONTINUED,SEE FOOTNOTE 003
91
LINE WITH SEAL CONE 1000 MM, TYPE 1113B UP TO CHASSIS 604683,TYP LP 1517 UP TO CHASSIS 600412,TYPE LP 1317 UP TO CHASSIS 601123,TYPE LP 911 B UP TO CHASSIS601688 CONTINUED,SEE FOOTNOTE 003
91
LINE WITH SEAL CONE 1000 MM, TYPE 1113B UP TO CHASSIS 604683,TYP LP 1517 UP TO CHASSIS 600412,TYPE LP 1317 UP TO CHASSIS 601123,TYPE LP 911 B UP TO CHASSIS601688 CONTINUED,SEE FOOTNOTE 003
94
UNION NUT FUEL HOSE
97
HOLLOW SCREW , Replaced By: N915036010108
97
HOLLOW SCREW FUEL LINE TO FEED PUMP
97
HOLLOW SCREW FUEL LINE TO FEED PUMP
100
HOLLOW SCREW CONNECTION: "12.2",4 697169
100
HOLLOW SCREW FUEL LINE TO FUEL FILTER
103
T-FITTING FUEL TANK SUPPORT
106
SEAL RINGTO 000 553 03 05,000 553 18 05,
106
SEAL RINGTO 000 553 03 05,000 553 18 05,
109
HOSE LEAK LINE
112
CLAMP , Replaced By: A0059970190
112
HOSE CLAMP LINE MOUNTING
115
HOSE RETURN
118
HOSE FUEL RETURN LINE
121
BRACKET FEED LINE AND RETURN LINE TO CLUTCH SLAVE CYLINDER
124
BRACKET FUEL LINES
124
BRACKET , Replaced By: A6004760236
124
BRACKET LINES TO BRACKET
127
CLAMP FEED AND RETURN LINES TO SUBSTRUCTURE
130
CLAMP , Replaced By: N916016010211
130
CLAMP , Replaced By: N000000001045
130
CLAMP CABLE HARNESS MOUNTING
130
CLAMP CABLE HARNESS MOUNTING
130
CLAMP ,K 147121, Replaced By: N000000000319
133
CLAMP
136
CLAMP , Replaced By: A0059970190
136
HOSE CLAMP LINE MOUNTING
139
BASE , Replaced By: A3142030084
139
SHIM BRACKET TO LEFT SIDE MEMBER
142
CLAMP LINE MOUNTING
142
CLAMP FUEL LINE, 741959
145
SCREW CAB FLOOR COVERING M 6X25
148
SCREW , Replaced By: N304017008016
148
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
151
WASHER , Replaced By: N009021006208
151
WASHER COMPRESSED AIR LINE TO BRACKET
154
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
157
NUT
160
SHEET METAL SCREW BRACKET TO CAB
163
CLAMP , Replaced By: N916016010211
163
CLAMP , Replaced By: N000000001045
163
CLAMP CABLE HARNESS MOUNTING
166
SCREW , Replaced By: N304017006018
166
SCREW COVER PLATE TO COVER PLATE M 6 X 12
169
PUMP (MANUAL AUXILIARY PUMP)
172
SEAL RINGTO 000 553 03 05,000 553 18 05,
175
HOLLOW SCREW , Replaced By: N915036010108
175
HOLLOW SCREW FUEL LINE TO FEED PUMP
178
HOLLOW SCREW FROM FUEL PUMP TO FILTER
178
HOLLOW SCREW AIR SPRING BELLOWS,LEFT AND RIGHT M14X1,5
999
FILTER ELEMENT , Replaced By: A0000922305
999
FILTER ELEMENT , Replaced By: A3524700092
999
FILTER HEADTO 001 092 19 01
999
FILLER CAP , Replaced By: A0004717930
999
COVERTO 001 477 48 01
999
SEAL RING , Replaced By: A1009970040
999
COVER , TO BE USED UP ON 001 477 71 01, Replaced By: A0000922808
999
FELT TUBE ELEMENT. FILTER ELEMENT , Replaced By: A0000922705
999
FILTER ELEMENT , Replaced By: A0000922705
999
SEAL RING
999
RUBBER HOSE,. HOSE AT SENDER UNIT
999
FUEL STRAINER AT TANK
999
FLANGE FUEL GAUGE SENDER UNIT TO FUEL TANK
999
LINE , Replaced By: A3404702665, +001N915008008402
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
