Поз.
Артикул
Описание
1
LINE , Replaced By: A3074669465
1
LINE FROM POWER STEERING PUMP TO HOSE
2
HOSE FROM PUMP TO STEERING
2
HOSE FROM PUMP TO STEERING
2
HOSE FROM PUMP TO STEERING
4
LINE , Replaced By: A0005516256
4
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
5
LINE FROM PUMP TO STEERING 1685 MM
6
LINE , Replaced By: A0005516256
7
LINE , Replaced By: A0005516256
7
LINE , Replaced By: A0005516256
7
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
8
LINE , Replaced By: A3004600124
8
LINE FROM PUMP TO STEERING 15 MM, LENGTH AVAILABLE:3000 MM
10
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
11
GLAND LINE CONNECTION
12
UNION NUT LINE CONNECTION
15
SEAL RINGTO 006 997 00 72
16
FITTING POWER STEERING PUMP M16X1,5/M22X1,5,D 084765
17
SEAL RING VALVE TO VALVE,K 025179
18
FITTING RETURN LINE TO STEERING,5 424435
20
LINE , Replaced By: A3014600424
20
LINE FROM STEERING TO OIL TANK 1225 MM, WITH MERCEDES-BENZ BODY UP TO IDENT NO.038940,LESS MERCEDES-BENZ BODY UP TO IDENT NO.039008
20
LINE FROM STEERING TO OIL TANK
21
LINE , Replaced By: A0004291601
21
LINE , Replaced By: A0004291601
22
LINE , Replaced By: A0004291601
23
LINE , Replaced By: A3014605924
23
LINE FROM STEERING TO OIL TANK
24
LINE FROM STEERING TO OIL TANK,001565
24
LINE , Replaced By: A3014601624
24
LINE FROM STEERING TO OIL TANK,001566
25
FITTING HIGH PRESSURE LINE TO STEERING
26
GLAND , Replaced By: A0019901267
27
UNION NUT LINE CONNECTION, Replaced By: N000000006243
29
FITTING SUCTION LINE TO OIL PUMP
30
TANK STEERING OIL TANK
31
COVER , Replaced By: A0004664405
32
SEAL RINGTO 000 466 38 02
33
NUTTO 000 466 38 02
34
OIL DIPSTICK
35
RUBBER SLEEVETO 000 466 38 02
36
CENTERING RINGTO 000 466 38 02
38
FILTER CARRIERTO 000 466 38 02
39
SPACER TUBETO 000 466 38 02
40
FITTING , 993034
41
WASHER , Replaced By: A9402680552
41
SPACER WASHERTO 000 466 38 02
42
FILTER , Replaced By: A0004660604
42
FILTER
43
BRACKET , Replaced By: A0004660640
43
BRACKET
44
SEAL RING , Replaced By: A0059970848
44
SEAL RINGTO 000 466 38 02
45
CONNECTOR ,12068001, 344.030,031,032,03312009118, 345.001,002,003,300
46
SEAL RING
47
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
48
NUT , Replaced By: N304032008006
49
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
50
NUT , Replaced By: N910113010000
50
NUT STRAP TO BRACKET
51
LINE , Replaced By: A3014600024
51
LINE FROM OIL TANK TO HOSE
52
HOSE
53
BRACKET , Replaced By: A3764291040
53
BRACKET , Replaced By: A3464296040
53
BRACKET OIL LINE MOUNTING
55
LINE , Replaced By: A3014600324
55
LINE FROM HOSE TO OIL PUMP 620 MM
56
BRACKET HIGH PRESSURE LINE TO EXHAUST BRAKE BRACKET,006895
57
CLAMP LINE MOUNTING
58
CLAMP , Replaced By: N916016022203
58
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
59
SCREW CAB FLOOR COVERING M 6X25
60
WASHER , Replaced By: N009021006208
60
WASHER COMPRESSED AIR LINE TO BRACKET
61
NUT , Replaced By: N910113006001
61
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
999
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
999
UNION NUT LINE CONNECTION, Replaced By: N000000006239
999
NUT STEERING WHEEL TO STEERING COLUMN
999
SCREW , Replaced By: N304017010055
999
GLAND , Replaced By: A0019901967
999
SCREW , Replaced By: N304017010050
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER , Replaced By: N000125010532
999
WOOD SCREW STEERING COLUMN PANELLING
999
COTTER PINROCKINGER,TYP 260 G150,260 G140
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PIN LEVER TO SUPPORT
999
CLAMP25-40X13 MM
999
PLUG TOP,5 220080
999
SHELL STEERING COLUMN PANELLING,FRONT
999
SHELL STEERING COLUMN PANELLING,REAR
999
STEERING COLUMN BRACKET , NOT USED
999
BUSHING ,582084
999
BUSHING BRACKET TO FRAME
999
STEERING SUPPORT
999
STEERING COLUMN BRACKET , NOT FOR USE WITH MERCEDES-BENZ CAB
999
STEERING SHAFT , Replaced By: A3014601009, +001A0119815110, +001A0119817310
999
BUSHINGTO 301 460 01 09
999
STEERING SHAFT ,045858, Replaced By: A3014600909, +001A0119815110, +001A0119817310
999
STEERING SHAFT
999
STEERING SHAFT
999
NEEDLE BEARING TOP
999
NEEDLE BEARING , Replaced By: A0129818510, +001A3574620075
999
NEEDLE BEARING
999
SEAL CONE LINE CONNECTION
999
FITTING , Replaced By: A0004660571
999
SEALING CORD , Replaced By: A0059970848
999
REINFORCEMENT , Replaced By: A0004660095
999
BALL JOINT
999
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
999
BOOT FIXED PART OF JOINT
