Поз.
Артикул
Описание
4
LINE FROM FOUR-CIRCUIT PROTECTIVE VALVE TO AIR RESERVOIR 9X12 MM, LENGTH AVAILABLE 3000 MM
8
UNION NUT LINE CONNECTION, Replaced By: N000000006239
8
UNION NUT LINE CONNECTION
12
GLAND , Replaced By: A0019901967
12
SEAL CONE LINE CONNECTION
16
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
20
UNION NUT BUTT SCREW CONNECTION
24
GLAND LINE CONNECTION
28
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
28
HOSE , Replaced By: A0009872827
32
UNION NUT LINE CONNECTION, Replaced By: N000000006239
32
UNION NUT LINE CONNECTION
36
GLAND , Replaced By: A0019901967
36
SEAL CONE LINE CONNECTION
40
SLEEVE LINE CONNECTION
40
BUSHING , Replaced By: N915062009000
44
BANJO UNION , Replaced By: N915052009000
44
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
44
BANJO UNION FROM BULKHEAD FITTING TO PRESSURE REGULATOR
45
BRACKET LINE MOUNTING 11 MM
46
CLAMP ELECTRIC CABLE TO BRAKE HOSE
98
HOSE FLUID RESERVOIR
98
HOSE , Replaced By: A6039970482
98
HOSE , Replaced By: A3109970382
128
LOOM TIE LINE MOUNTING
144
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
148
SEAL RING LINE CONNECTION
176
BRACKET , Replaced By: A3104290940
176
BRACKET LINE TO FRAME
176
BRACKET LINE MOUNTING,567960
180
RUBBER BUFFER COVERING TO FRAME
184
WASHER EXHAUST MUFFLER TO STRAP
184
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
184
WASHER , Replaced By: N000125008443
192
SCREW , Replaced By: N304017006016
192
SCREW PUMP TO BRACKET
196
NUT PUMP TO BRACKET
196
NUT , Replaced By: N913004006001
200
CLAMP , Replaced By: A6739950001
200
CLAMP LINE MOUNTING
200
CLAMP DELIVERY AND SUCTION LINES TO STEERING
204
NUT , Replaced By: N913004008001
274
RESERVOIR WITH WARNING DEVICE,4 314610
274
RESERVOIRTO 344 430 78 01
284
RESERVOIR , Replaced By: A0004318302, +001A0004313733, +001A0004313134
284
RESERVOIR WITH CLUCH AND BRAKE SYSTEM WARNING DEVICE, FROM IDENT NO. 352291 EXCCEPT FOR 352759,353163,353868,354161. ALSO INSTALLED ON 350368,350793,350843,350954,351074,351169,351284,351434,351903,352001,352271,352272.
285
FILLER CAP
287
STRAINER
288
FILLER CAPTO 001 431 38 02,000 431 58 02
290
SEAL RING
291
SEAL RING42X21.5 MM
293
STRAINERTO 001 431 38 02
295
CLAMPTO 000 431 58 02
298
BRACKET FLUID RESERVOIR
302
SCREW COVER PLATE TO BRACKET
306
NUT PUMP TO BRACKET
306
NUT , Replaced By: N913004006001
310
CLAMPTO 000 431 58 02
314
SCREW COVER PLATE TO BRACKET
318
NUT PUMP TO BRACKET
318
NUT , Replaced By: N913004006001
418
T-FITTING AT SIDE MEMBER
422
BUSHING T-FITTING TO SIDE MEMBER
426
NUT CHECK VALVE TO AIR RESERVOIR
430
SEAL RING , Replaced By: N007603012121
430
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
434
FITTING BRAKE LINE COUPLING,CONNECTION: "11,12"
434
ADAPTER FITTING , Replaced By: A0029971072
840
BUSHING FUEL LINE THRU FRAME SIDE MEMBER
841
GROMMET AT SHOCK ABSORBER BRACKET AND AT FENDER BRACKET
842
BUSHING COMPRESSED AIR LINE
999
SCREW COVERING TO RAIL
999
CLAMP , Replaced By: N916016008200
999
BASE STRAP
999
REPAIR KIT , Replaced By: A3534200167
999
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL 2200 MM,4 478329
999
LINE FROM BRAKE MASTER CYLINDER TO LEFT FRONT WHEEL 1550 MM
999
HOSE BRAKE CABLE TO FORK 45 MM,556500 ALSO INSTALLED ON 553210,556146 ORDER BY THE METER
999
SPRING ,556500 ALSO INSTALLED ON 553210,556146
999
HOSE BRAKE LINE TO REAR AXLE,4 644238
999
CLAMP BRAKE LINE MOUNTING
999
DAMPING RING
999
CONNECTOR HAND BRAKE LEVER,556500 ALSO INSTALLED ON 553210,556146
999
BEARING BODY ,556500 ALSO INSTALLED ON 553210,556146
999
SPHERICAL PIECE ,556500 ALSO INSTALLED ON 553210,556146
999
NUT , FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
ROD ,556500 ALSO INSTALLED ON 553210,556146
999
ROD , FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
ROD , FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
LEVER INTERMEDIATE LEVER, FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
SUPPORT ,556500 ALSO INSTALLED ON 553210,556146
999
SUPPORT UPPER PART
999
BUSHING , Replaced By: A0009973481
999
LINE WITH BEAD,10 MM
999
GASKET BRACKET TO FIRE WALL,707221
999
GASKET BRACKET TO FIRE WALL,707221
999
BRACKET BRAKE BOOSTER BRACING
999
BRACKET BRAKE BOOSTER ASSEMBLY
999
GROMMET , Replaced By: A0019877625
999
BRACKET RIGHT
999
BRACKET LEFT
999
HANDLETO 341 420 00 88
999
BRAKE LEVER
999
BEARING BRACKET HAND BRAKE LEVER, UP TO CHASSIS 556499 EXCEPT FOR 553795,555902,556120
999
RATCHET ROD
999
PROTECTIVE PLATE
999
PROTECTIVE PLATE ,544549
999
SPHERICAL PIECE , Replaced By: A3025860242
999
PIN BRAKE PEDAL TO BRAKE BOOSTER
999
GASKET
999
CLAMP , Replaced By: A0004760436
999
SEAL RING42.52X2.62 MM,WABCO
999
SEAL RING , Replaced By: A0179979048
999
HOSE FROM RESERVOIR TO MASTER CYLINDER
999
BRAKE MASTER CYLINDER
999
BRAKE MASTER CYLINDER , 10/50 FROM CHAS.145737-162733 ALSO INSTALLED ON 139841,139842,140553,145397,145406,145409,145426,145445,145462,145592,145660, 145697,145701 CONTINUED SEE FOOTNOTE 20
999
THRUST RINGVOSS,707221
999
REPAIR KIT , Replaced By: A0034201724
999
HOSE
999
SEAL RING , Replaced By: A0009971548
999
BRAKE BOOSTER ASSEMBLY , UP TO IDENT NO. 352290 EXCEPT FOR 350368,350793,350843,350954,351074,351169,351284,351434,351903,352001,352271,352272. ALSO INSTALLED ON 352332,352759,353163,353868,354161.
999
BRAKE BOOSTER ASSEMBLY , FROM CHASSIS 018154 ALSO INSTALLED ON 017661,017829 EXCEPT FOR 018155,018156,018159,018308,018310,018315,018317,018318,018327,018350,018355. EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 533350, Replaced By: A0024305630, +001A1262920074, +001N912011008000
999
VALVE PARKING BRAKE KNORR
999
VALVE PARKING BRAKE WITH EMERGENCY RELEASE DEVICE AND TRAILER CONTROL KNORR
999
HOSE FROM PARKING BRAKE VALVE TO ELBOW FITTING
999
SPRING , Replaced By: A0009935205
999
BUSHING , Replaced By: N915062004000
999
ELBOW FITTING , Replaced By: A0019904371
999
BANJO UNION , Replaced By: N915052006005
999
OUTER RACETO 003 429 11 44,VOSS,707221
999
HOSE , Replaced By: A0004358382
999
PISTONVOSS
999
RESERVOIR , 10/50 FROM CHAS.145737-162733 ALSO INSTALLED ON 139841,139842,140553,145397,145406,145409,145426,145445,145462,145592,145660, 145697,145701 CONTINUED SEE FOOTNOTE 20
999
CUP , Replaced By: A0015864342
999
FILLER CAP , Replaced By: A0004317633
999
FILLER CAP , Replaced By: A0004316533
999
VALVE (CHECK VALVE)
999
FILTER BOTTOMTO 000 431 24 14
999
REPAIR KITTO 001 430 18 81/78 81
999
HANDLETO 001 430 17 81,KNORR
999
CONNECTOR OIL DELIVERY LINE
