Поз.
Артикул
Описание
4
HOSE , Replaced By: A0009872827
4
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
11
SLEEVE LINE CONNECTION
11
BUSHING , Replaced By: N915062009000
17
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
17
PLASTIC PIPE RISING PIPE 4X6 MM
23
BUSHING , Replaced By: N915062004000
23
SLEEVE LEAK LINE
29
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
29
BANJO UNION , Replaced By: N915052004003
35
BANJO UNION , Replaced By: N915052004019
35
BANJO UNION HOSE WIDTH, / I.D., 4/16 MM
377
BUSHING FUEL LINE THRU FRAME SIDE MEMBER
381
LOOM TIE LINE MOUNTING 280 MM
385
LOOM TIE LINE MOUNTING
389
CLIP
999
BUSHINGWABCO,5 433388
999
VALVE SEAT RINGWABCO,5 433388
999
GASKETTO 003 429 22 44
999
VALVE , Replaced By: A0004290782
999
VALVE , Replaced By: A0004291182
999
COVERTO 000 429 51 30,4 434235
999
VALVE BODYTO 002 429 95 44
999
COVER"WABCO", NOT USED
999
COVER SUPPLY, RED "WABCO"
999
SEAL RING"WABCO"
999
SEAL RING , Replaced By: A0004292184
999
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
999
REPAIR KITTO KNORR
999
REPAIR KITTO 003 429 02 44
999
REPAIR KIT"KNORR"
999
GASKET34X2X6 MM,GRAU
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
FITTING ,4 667210
999
FITTING , Replaced By: A0019900970
999
GROOVED PINTO 000 429 51 30,4 434235
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
ROD , 556499 EXCEPT FOR 553210,556146
999
ROD , Replaced By: N900331010667
999
SEAL RING23.47X2.62,TO GRAU
999
SEAL RING9X1.5,TO GRAU
999
SEAL RING30X2,TO GRAU
999
SEAL RING100X3,TO GRAU
999
SEAL RING44.2X3,TO GRAU
999
SEAL RING64.77X2.62,TO GRAU
999
SEAL RING90X3,TO GRAU
999
SEAL RING39.2X3 TO 001 431 74 05,
999
SEAL RING18X2.5,TO GRAU
999
SEAL RING21.3X2.4 TO 001 431 74 05,
999
SEAL RING7X1.5,TO GRAU
999
SEAL RING"GRAU"
999
VALVE TRUCK-TRACTOR BRAKE VALVE,RIGHT CONNECTION 21,22, TRUCK-TRACTOR BRAKE VALVE WITH THROTTLE CHECK VALVE
999
BALLTO 003 429 22 44
999
REPAIR KIT , Replaced By: A0024301860
999
REPAIR KIT , Replaced By: A0004301109
999
REPAIR KITTO WABCO
999
REPAIR KIT VALVE DISC TO 001 431 67 05,BOSCH 061 214
999
GASKET KIT SEAL RING TO 001 431 67 05,BOSCH 061 214
999
ELBOW FITTING TRAILER CONTROL VALVE,CONNECTION: 1.1
999
REPAIR KITTO 001 431 67 05, BOSCH 061 010
999
VALVE DRAIN, Replaced By: A0004322107
999
VALVE. DRAIN VALVE DRAIN
999
VALVE DRAIN, Replaced By: A0004322407
999
VALVE SEATTO 001 431 74 05,GRAU 355 029 001
