Поз.
Артикул
Описание
8
PLASTIC PIPE RISING PIPE 4X6 MM
8
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
16
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
24
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
32
BANJO UNION HOSE WIDTH, / I.D., 4/16 MM
40
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
48
LOOM TIE LINE MOUNTING 280 MM
56
GROMMET
64
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
72
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
80
VALVE 3/2-WAY VOSS
80
VALVE 3/2-WAY WABCO
80
VALVE 3/2-WAY BOSCH
80
VALVE 3/2-WAY KNORR
88
SPRING INSIDE WABCO
96
SEAL RING INSIDE WABCO
104
SEAL RING TOP WABCO
112
HOLLOW SCREW LINE CONNECTION
120
SEAL RING PNEUMATIC VALVE
120
SEAL RING , Replaced By: N007603010110
128
BRACKET VALVE TO CAB
136
SCREW COVER PLATE TO BRACKET
144
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
152
NUT , Replaced By: N913004006001
152
NUT PUMP TO BRACKET
160
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
168
HOLLOW SCREW FITTING PNEUMATIC CYLINDER,CONNECTION: "10",5 308944
176
SEAL RING LINE CONNECTION
184
SWITCH EXHAUST BRAKE,K 251255
999
HOLLOW SCREW LINE CONNECTION
999
HOLLOW SCREW HEATING CONNECTION
999
SEAL RING
999
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
