Поз.
Артикул
Описание
9
BRACKET CLUTCH PEDAL AND BRAKE PEDAL,314244
9
BRACKET CLUTCH PEDAL AND BRAKE PEDAL,314243
15
STOP
21
PEDAL CLUTCH,526441
21
PEDAL ,526440, Replaced By: A3092902016, +001A3102900339, +001A1232950150, +001N000931008047, +001N913004008004
21
PEDAL ,526440, Replaced By: A3102900316, +001A3102900339, +001A1232950150, +001N000931008047, +001N913004008004
21
PEDAL ,526440, Replaced By: A3102900416, +001A3102900339, +001A1232950150, +001N000931008047, +001N913004008004
27
BUSHING , Replaced By: A1242920050
27
BUSHING BRAKE PEDAL
34
PEDAL BRAKE
40
BUSHING BRAKE PEDAL
40
BUSHING , Replaced By: A1242920050
47
PAD , Replaced By: A1072910182
47
PAD BRAKE
53
WASHER PEDALS TO PIVOT PINS
60
LOCK AT WATER EXPANSION TANK
66
SWITCH STOP LIGHT
66
SWITCH STOP LIGHT
72
NUT SWITCH
79
SPRING RELEASE SPRING
86
ROD OVER-CENTER ACTING SPRING
86
ROD , Replaced By: A3132900139
86
ROD , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 565454, Replaced By: A3102900439
92
BUSHING , Replaced By: A3132900139
99
SPRING (DEAD CENTER SPRING) 35 MM
106
SPRING RETAINER SPRING TO PUSH ROD
113
NUT
127
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
134
SPRING RETAINER SPRING TO PUSH ROD
138
REPAIR KIT DEAD CENTER SPRING
141
MASTER CYLINDER , Replaced By: A0012958706
141
MASTER CYLINDER , 000,003,007,102,103,105,200 A 091118 083,086,093,183,190,193,280,283 F 015866, Replaced By: A0012954406, +001A0002950833
141
MASTER CYLINDER , Replaced By: A0002959106
141
MASTER CYLINDER , 077222
144
PLUG
149
INTERMEDIATE PIECE FROM CLUTCH MASTER CYLINDER TO RESERVOIR
151
REPAIR KIT MASTER CYLINDER, 000,003,007,102,103,105,200 A 091118 083,086,093,183,190,193,280,283 F 015866
151
REPAIR KIT TO MASTER CYLINDER HAVING ALUMINUM PISTON TO 000 295 77 06
155
SCREW DISTRIBUTOR TO CAB
155
SCREW DISTRIBUTOR TO CAB
155
SCREW , Replaced By: N000933006151
161
NUT , Replaced By: N913004006001
161
NUT PUMP TO BRACKET
168
SPACER TUBE MASTER CYLINDER TO CONSOLE TO 000 295 91 06
171
ROD FROM CLUTCH PEDAL TO MASTER CYLINDER,526441
171
ROD
174
BUSHING
180
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
180
SCREW SUPPORT TO FENDER
180
SCREW , Replaced By: N304017008018
180
SCREW , Replaced By: N304017008016
186
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
186
NUT , Replaced By: N913004008001
186
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
186
NUT ROD TO LEVER,526440
192
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
198
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 700 MM,4 644237
205
GROMMET
205
GROMMET , Replaced By: A0079975881
205
GROMMET , Replaced By: A1079970881
212
LOCK , Replaced By: A1072950173
212
LOCK HYDRAULIC LINE TO CAB
220
HOSE FROM CLUTCH HOSE TO SLAVE CYLINDER
226
SCREW PIPE CLAMP
226
SCREW , Replaced By: N304017008021
232
WASHER , Replaced By: N000125008443
232
WASHER EXHAUST MUFFLER TO STRAP
239
GROMMET ,D 314239
239
GROMMET PLUG SOCKET
246
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
999
BOOT
999
PLUG , Replaced By: A0009971186
999
BUSHING PISTON ROD TO CLUTCH PEDAL
999
WASHER , Replaced By: N000125008443
999
LOCK RING19 MM
