Поз.
Артикул
Описание
65
FITTING INTAKE MANIFOLD
65
CONNECTOR
65
INTAKE PIPE , Replaced By: A3521340256
65
FITTING , Replaced By: A4032030008
65
CONNECTOR , Replaced By: A6012030008
85
FITTING AIR COMPRESSOR,CONNECTION: "10"
85
FITTING AT AIR COMPRESSOR
95
PIPE BEND AT AIR COMPRESSOR
100
SEAL RINGTO 376 131 74 01
100
SEAL RING LINE CONNECTION
105
SEAL RING FROM PIPE ELBOW TO AIR COMPRESSOR
115
NUT SUCTION LINE TO OIL PUMP
115
NUT , Replaced By: N080705026003
115
NUT INTERMEDIATE SPEED STOP
115
NUT 3/2-WAY VALVE TO CAB,4 685151
155
HOSE FROM BUBBLE SEPARATOR TO HEATING PIPE 18X27 MM, ORDER BY THE METER
155
HOSE FROM CYLINDER HEAD COVER TO AIR COMPRESSOR 22X29 MM, ORDER BY THE METER
155
HOSE AIR COMPRESSOR CONNECTION 240 MM, ORDER BY THE METER
155
HOSE 18-MM-DIA. LINE
155
HOSE FROM HEATING PIPE AT ENGINE TO HEATING PIPE AT RADIATOR, ORDER BY THE METER
160
HOSE , ORDER BY THE METER
160
HOSE , Replaced By: A4969970082
160
HOSE , Replaced By: A4969970082
160
HOSE , Replaced By: A3909970682
160
HOSE , Replaced By: A3909970682
160
HOSE340 MM
160
HOSE HOSE TO OIL FILLER PIPE AND TO PIPE SOCKET ON OIL PAN 135 MM, ORDER BY THE METER
160
HOSE , Replaced By: A3909970682
160
HOSE HOSE TO AIR INTAKE PIPE & TO AIR COMPRESSOR & ENGINE BREATHER,RESP., ORDER BY THE METER
160
HOSE INTAKE PIPE TO BREATHER PIPE,OM 352
170
INTAKE PIPE BELT-DRIVEN AIR COMPRESSOR, FROM ENGINE 048760 ALSO INSTALLED ON 048663,048665-048668,048670,048672,048675-048677,048679,048681-048682,048684,048686,048688,048690, 048692,048694,048696,048698,048700-048702,048704,048716-048719,048726,048728-048742,048744-048757. UP TO ENGINE 234537 YEAR OF MANUFACTURE 1992
170
INTAKE PIPE AIR COMPRESSOR
170
INTAKE PIPE , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 238225/92, Replaced By: A3661341701
175
INTAKE PIPE , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 238225/92, Replaced By: A3661301801
175
INTAKE PIPE CAMSHAFT-DRIVEN,AND BELT-DRIVEN,AIR COMPRESSORS, UP TO ENGINE 234537 YEAR OF MANUFACTURE 1992
175
INTAKE PIPE AIR COMPRESSOR
180
INTAKE PIPE SUCTION LINE TO AIR COMPRESSOR, FROM ENGINE 238226 YEAR OF MANUFACTURE 1992
180
INTAKE PIPE SUCTION LINE TO AIR COMPRESSOR, FROM ENGINE 234538 YEAR OF MANUFACTURE 1992 UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
185
INTAKE PIPE SUCTION LINE TO AIR COMPRESSOR
185
INTAKE PIPE FROM AIR INTAKE PIPE TO AIR COMPRESSOR
190
INTAKE MANIFOLD AIR COMPRESSOR
210
INTAKE PIPE AIR COMPRESSOR
215
INTAKE PIPE AIR-COMPRESSOR AIR INTAKE
215
INTAKE PIPE AIR-COMPRESSOR AIR INTAKE
215
INTAKE PIPE AIR-COMPRESSOR AIR INTAKE,216580/91
220
INTAKE PIPE AIR-COMPRESSOR AIR INTAKE
220
INTAKE PIPE AIR-COMPRESSOR AIR INTAKE
230
LOOM TIE , Replaced By: N000000000668
230
LOOM TIE , Replaced By: A1049970590
230
CLAMP , Replaced By: N000000000667
230
CLAMP , Replaced By: A0069970490
230
CLAMP25-40X13 MM
230
LOOM TIE FROM AIR COMPRESSOR TO OIL PAN
230
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
255
BRACKET PULL ROD TO SUPPORT,5 352764 TO BE ADAPTED DURING ASSEMBLY
255
BRACKET , Replaced By: A3184924841
270
BRACKET , Replaced By: A6454310740
270
BRACKET , Replaced By: A4420981439
270
BRACKET , Replaced By: A4420982239
270
BRACKET FUEL LINE TO BELL HOUSING
270
BRACKET COMPRESSED AIR LINE MOUNTING SA 48042
275
SCREW STOP TO BATTERY CASE
275
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
285
CLAMP
285
CLAMP BRAKE HOSE BRACKET
285
CLAMP HOSE TO BRACKET 25/20,5 206397
285
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
285
CLAMP FRAME MOUNTED CABLE HARNESS TO CAB
285
CLAMP HOSE TO FLANGE AND TO VALVE
285
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
290
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
290
SCREW , Replaced By: N304017008016
290
SCREW , Replaced By: N914146006102
290
SCREW CLAMP MOUNTING M 6X16
290
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
290
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
295
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
300
NUT SPRING-LOADED PUSH ROD
300
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
315
SCREENING PLATE , Replaced By: A3660900634
315
SCREENING PLATE ,234537/92
320
SCREW , Replaced By: N304017008021
320
SCREW PIPE CLAMP
325
WASHER , Replaced By: N000125008443
325
WASHER EXHAUST MUFFLER TO STRAP
330
SCREW CROSS MEMBER TO REINFORCEMENTS AND TO SIDE MEMBERS,5 129709
335
BRACKET SCREENING PLATE, FROM ENGINE 234538 YEAR OF MANUFACTURE 1992 UP TO ENGINE 351138 YEAR OF MANUFACTURE 1994
335
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 108103/90, Replaced By: A3660901041
340
SCREW BRACKET TO PLATE
345
HOSE (MOLDED HOSE),AIR INTAKE
350
CLAMP , Replaced By: N000000000673
350
CLAMP HOSE TO RETARDER 60-80X13 MM
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
FITTING , NOT USED
999
LOOM TIE LINE MOUNTING 280 MM
999
SEAL RING , NOT USED
999
CLAMP HOSE FASTENING 28-35 MM,V 207570
999
FITTING AIR COMPRESSOR AND OIL PAN
999
BRACKET INTAKE MANIFOLD
999
BRACKET INTAKE MANIFOLD
999
HOSE , Replaced By: A3641870082
999
CONNECTOR AT ENGINE,591819
999
INTAKE PIPE AIR COMPRESSOR
999
HOSE (INTAKE HOSE)
999
INTAKE PIPE BELT-DRIVEN AIR COMPRESSOR
999
INTAKE PIPE AT CYLINDER HEAD, NOT USED
999
HOSE
999
BRACKET SUCTION LINE TO CHARGING AIR ELBOW, NOT USED
999
BRACKET INTAKE HOSE TO FILTER
999
HEXALOBULAR BOLT GROUND CABLE TO GENERATOR M6X20
999
SCREW PLUGTO 376 131 74 01
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
NUT BALL PIVOT TO LEVER
999
NUT , Replaced By: N304032008006
999
SCREW SCREENING PLATE TO ALTERNATOR M 10X1X12,027925
999
HEXAGON HEAD BOLT BRACKET TO BRACKET
999
NUT
999
NUT STEERING WHEEL TO STEERING COLUMN
999
HEXAGON HEAD BOLT COVERING TO CAB
999
CLAMP LINE MOUNTING
999
CLAMP , Replaced By: N000000000667
999
CLAMP , Replaced By: A0069974290
