Поз.
Артикул
Описание
1
FRAME
1
FRAME ,4 282708
1
FRAME ,4 282707
1
FRAME , ONLY APPLICABLE TO 353
1
FRAME , ONLY APPLICABLE TO 072,0924 282708
1
FRAME , ONLY APPLICABLE TO 072,0924 282707
1
FRAME , ONLY APPLICABLE TO 070,0904 282708
1
FRAME , ONLY APPLICABLE TO 070,0904 282707
1
FRAME
1
FRAME , ONLY APPLICABLE TO 053,058,0674 282708
1
FRAME
1
FRAME , ONLY APPLICABLE TO 053,058,0674 282707
1
FRAME
1
FRAME ,4 282708
1
FRAME ,4 2827084 477457
1
FRAME
1
FRAME ,4 282707
1
FRAME ,4 282707
9
CROSS MEMBER FRONT,4 373947
9
CROSS MEMBER FRONT,4 373946
17
SCREW BRACKET TO SIDE MEMBER
17
SCREW BRACKET TO SIDE MEMBER
17
SCREW , Replaced By: N304017010002
25
NUT STRAP TO BRACKET
25
NUT , Replaced By: N910113010000
33
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
41
NUT STRAP TO BRACKET
41
NUT , Replaced By: N910113010000
49
SCREW END PIECE TO EXHAUST PIPE M 10X25
57
NUT STRAP TO BRACKET
57
NUT , Replaced By: N910113010000
249
SUPPORT HYDRAULIC PUMP
257
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
257
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
265
NUT STRAP TO BRACKET
265
NUT STRAP TO BRACKET
265
NUT , Replaced By: N910113010000
273
WASHER BRACKET TO COVERING
273
WASHER BRACKET TO COVERING
273
WASHER , Replaced By: N009021010209
281
BRACKET HYDRAULIC PUMP
281
BRACKET HYDRAULIC PUMP
369
SUPPORT HYDRAULIC PUMP
649
RUBBER BUFFER HYDRAULIC PUMP BRACKET TO BODY SUPPORT
657
SCREW STRAP TO BRACKET
665
WASHER BRACKET TO COVERING
665
WASHER , Replaced By: N009021010209
673
NUT STRAP TO BRACKET
673
NUT , Replaced By: N910113010000
681
SCREW BRACKET TO CROSS CONNECTION STRUT
681
SCREW , Replaced By: N304017008034
689
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
689
NUT , Replaced By: N913004008001
697
SCREW
697
SCREW
705
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
705
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
713
RUBBER BUFFER HYDRAULIC PUMP BRACKET TO BODY SUPPORT
721
SCREW BRACKET TO CROSS CONNECTION STRUT
721
SCREW , Replaced By: N304017008034
729
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
729
NUT , Replaced By: N913004008001
737
SCREW BRACKET TO BELL HOUSING
745
WASHER BRACKET TO COVERING
745
WASHER , Replaced By: N009021010209
753
NUT STRAP TO BRACKET
753
NUT , Replaced By: N910113010000
761
COUPLING , Replaced By: A3018950005
761
COUPLING (TOW BAR COUPLING) ROCKINGER TYP SK 4
769
COVERING TRAILER COUPLING
777
COVER TOW BAR COUPLING TO CROSS MEMBER,4 477457
785
SHIM TOW BAR COUPLING TO CROSS MEMBER,4 477457
793
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
793
SCREW , Replaced By: N308676014020
801
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
809
WASHER STRUT TO CROSS MEMBER
809
WASHER , Replaced By: N007349010007
825
LINE FROM CONNECTOR TO TEST CONNECTION 2800 MM,4 478330
833
ANGLE LINE MOUNTING
841
SCREW PIPE CLAMP
841
SCREW , Replaced By: N304017008021
849
WASHER EXHAUST MUFFLER TO STRAP
849
WASHER , Replaced By: N000125008443
857
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
857
NUT , Replaced By: N913004008001
865
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
865
CLAMP ,K 147121, Replaced By: N000000000319
865
CLAMP , Replaced By: N916016008200
873
SCREW CLAMP MOUNTING M 6X16
873
SCREW , Replaced By: N000000001146
881
NUT PUMP TO BRACKET
881
NUT , Replaced By: N913004006001
999
PIN
999
ROLLER BEARING , UP TO CHASSIS 830523,FROM CHASSIS,SEE SA 16447
999
SEAL RING , UP TO CHASSIS 830523,FROM CHASSIS,SEE SA 16447
999
RUBBER BUFFER EXHAUST MUFFLER
999
SPRING , UP TO CHASSIS 830523,FROM CHASSIS,SEE SA 16447
999
SPRING FOR VALVE DISC, UP TO CHASSIS 830523,FROM CHASSIS,SEE SA 16447
999
SEAL RING , UP TO CHASSIS 830523,FROM CHASSIS,SEE SA 16447
999
WOODRUFF KEY POWER STEERING PUMP
999
RIVET10X18 MM, TO BE ADAPTED DURING ASSEMBLY
