Поз.
Артикул
Описание
85
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
87
CLAMP LINE CONNECTION
87
CLAMP , 10/20 695199 50/60 695577 8 000001
89
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
89
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
95
LINE FROM VALVE TO BRAKE HOSE 1600 MM
95
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL 1700 MM,4 478329
95
LINE FROM VALVE TO BRAKE HOSE 1600 MM
97
LINE FROM CLUTCH MASTER CYLINDER TO HYDRAULIC HOSE 350 MM,556500-604337
97
LINE FROM DISTRIBUTOR TO BRAKE HOSE ON REAR AXLE 415 MM,4 478330
100
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
100
LINE , Replaced By: A0005516256
105
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
110
HOSE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER 8 X 14 MM, ORDER BY THE METER4 940458
115
CLAMPTO 005 420 99 18
120
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
120
FITTING , Replaced By: A0009970171
122
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
122
SEAL RING , Replaced By: N007603012121
124
FITTING FROM BRAKE BOOSTER,"A" CONNECTION,TO VALVE,"V" CONNECTION, UP TO IDENT NO. 840080 EXCEPT FOR 500001-599999
124
FITTING AIR BRAKE CYLINDER,549430
130
UNION NUT BUTT SCREW CONNECTION
132
GLAND LINE CONNECTION
134
THRUST RING BUTT SCREW CONNECTION
136
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
136
SEAL RING , Replaced By: N007603012121
140
UNION NUT
140
UNION NUT LINE CONNECTION
142
GLAND LINE CONNECTION
999
PULL ROD , FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
SEAL RING SCREW PLUG
999
WIRE120 MM, UP TO IDENT NO. 4 477510 FROM IDENT NO. SEE UNIT MICROFICHE MODEL 750.5 ORDER BY THE METER
999
CONSOLE , Replaced By: A3604301311
999
RESERVOIR , Replaced By: A0024320501
999
CONSOLE AIR RESERVOIR TO SUPPORT
999
RESERVOIR , Replaced By: A3454308205
999
CLAMP , NOT USED
999
BRACKET
999
CONSOLE
999
BRACKET
999
BRACKET TWO-WAY VALVE, UP TO IDENT NO. 4 282707 AND FROM IDENT NR. 8 000001-8 001702
999
BRACKET
999
LEVER
999
RESERVOIR FROM AIR RESERVOIR TO ANTI-FREEZE DEVICE
999
CONSOLE BRAKE BOOSTER,4 282707
999
LEVER BRAKE LINKAGE,4 282707
999
BRACKET ,4 282707
999
BRACKET , 10/20 695199-986791 50/60 695577-986791
999
CONSOLE , 10/20 695199 50/60 695577 8 0000014 2827078 000001-8 001702
999
ROD FROM HAND BRAKE LEVER TO FRONT INTERMEDIATE LEVER
999
LEVER
999
LEVER
999
BRAKE INTERMEDIATE SHAFT
999
LEVER BRAKE LINKAGE,6951998 0000014 2827078 000001
999
RESERVOIR40L,276 MM,8.5 BAR
999
RESERVOIR , Replaced By: A0034322501
999
BRAKE MASTER CYLINDER ,4 282707
999
VALVE
999
BRAKE MASTER CYLINDER , Replaced By: A0024300701
999
PLUG
999
SPRING
999
VALVE , Replaced By: A0004320807
999
VALVE , Replaced By: A0004320807
999
BRAKE BOOSTER , Replaced By: A0004319014
999
BRAKE CYLINDER. BRAKE BOOSTER , Replaced By: A0004319114
999
WASHER
999
WASHERTO 002 430 41 01, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
SPRING RETAINER BRAKE MASTER CYLINDER
999
COVER. THREADED UNION
999
WASHER , Replaced By: A0004311176
999
BLEEDER VALVE. VALVE , Replaced By: A0004201055
999
VALVE , Replaced By: A3075530107
999
VALVE (SAFETY VALVE)
999
VALVE
999
T-FITTING AIR RESERVOIR I
999
DIAPHRAGM
999
DIAPHRAGM , Replaced By: A0004290745
999
DIAPHRAGMTO 344 429 73 44
