Поз.
Артикул
Описание
5
STEERING BOX ASSEMBLY
5
STEERING BOX ASSEMBLY , Replaced By: A3444601701
5
STEERING BOX ASSEMBLY , Replaced By: A3444600801
25
PITMAN ARM , 341.250 FROM CHASSIS A 002104
30
STEERING SUPPORT , 341.250 FROM CHASSIS A 002104
295
STEERING WHEEL
295
STEERING WHEEL
295
STEERING WHEEL , Replaced By: A3454607003
301
WOODRUFF KEY FLANGE TO SHIFTING TUBE
306
NUT STEERING WHEEL TO STEERING COLUMN
311
CAPTO 000 464 11 01
311
CAPTO 345 460 02 03
311
CAP
316
STEERING COLUMN BRACKET , 341.250 FROM CHASSIS A 002104
318
STUD
319
SCREW LINES TO BRACKET
320
LOCK WASHER RAIL TO BATTERY SUPPORT
322
HOSE
327
CLAMPING PIECE
327
CLAMPING PIECE , Replaced By: A3214620022
329
LOCK WASHER RAIL TO BATTERY SUPPORT
330
NUT
332
DRAG LINK FRONT, 341.250 FROM CHASSIS A 002104
332
DRAG LINK , Replaced By: A3444607605
337
GREASE NIPPLE PROTECTIVE TUBE
346
NUT BALL PIVOT TO STEERING ARM
351
COTTER PINROCKINGER TYP 260 G140
357
STEERING INTERMEDIATE ARM , 341.250 FROM CHASSIS A 002104
361
GREASE NIPPLE
366
TAPERED ROLLER BEARING FRONT
372
SPACER WASHER INTERMEDIATE LEVER TO BEARING BRACKET
376
SPACER WASHER INTERMEDIATE LEVER TO BEARING BRACKET
381
SEAL RING
381
RADIAL SEAL RING , Replaced By: A0079976446
387
BEARING BRACKET
387
TRUNNION BEARING , Replaced By: A3644630038
391
TAPERED ROLLER BEARING INTERMEDIATE LEVER TO BEARING BRACKET
396
THRUST WASHER STEERING INTERMEDIATE ARM BEARING
402
NUT BALL PIVOT TO STEERING ARM
408
COTTER PINROCKINGER TYP 260 G140
414
CAP AT STEERING INTERMEDIATE ARM
417
SCREW STEERING INTERMEDIATE ARM
423
SCREW DIFFERENTIAL GEAR
432
NUT , Replaced By: N910113014001
447
DRAG LINK MAKE NAKATA
447
DRAG LINK , Replaced By: A3444607405
453
BALL SOCKET HEADTO 98 344 460 03 05
458
GREASE NIPPLE PROTECTIVE TUBE
463
DUST CAPTO 98 344 460 04 05
463
DUST CAP , Replaced By: G983213380056
467
NUT BALL PIVOT TO STEERING ARM
473
COTTER PINROCKINGER TYP 260 G140
477
SCREW , L 1113 FROM CHASSIS 071990,LP/LPO 1113 FROM CHASSIS 071679 344.030,032,033,040,041,057,058 UP TO CHASSIS 415524,UP TO CHASSIS SEE SPARE PARTS LIST 732.7
483
NUT , L 1113 FROM CHASSIS 071990,LP/LPO 1113 FROM CHASSIS 071679 344.030,032,033,040,041,057,058 UP TO CHASSIS 415524,UP TO CHASSIS SEE SPARE PARTS LIST 732.7
488
COTTER PINTO 345 460 94 05
493
SHOCK ABSORBER
493
SHOCK ABSORBERMONROE
493
SHOCK ABSORBER , Replaced By: A3444607066
498
BALL JOINTTO 344 460 01 66
505
GREASE NIPPLE INTERMEDIATE LEVER
510
DUST CAPTO 344 460 01 66
514
CLAMPING SLEEVETO 344 460 01 66
518
RUBBER RINGTO 344 460 70 66
518
RUBBER RINGTO 344 460 01 66
523
BUSHINGTO 344 460 70 66, NOT CARRIED AS A SPARE PART
523
BUSHING TOP AND BOTTOM TO 308 326 70 00,72 00
528
BRACKET
528
BRACKET , Replaced By: A3214630340
533
SCREW
537
NUT , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
542
COTTER PIN , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
546
SCREW BRACKET TO REAR SPRING SADDLE COUNTER PLATE
553
NUT M14X1,5 MM
558
COTTER PIN SHIFT LEVER TO CASE
563
LOCK PLATE
568
NUT , 341.250 FROM CHASSIS A 002104
999
GASKET KIT , TO 341 460 10 01,344 460 17 01,384 460 71 01,390 460 70 01
999
GASKET KIT , TO 344 460 17 01
999
GASKET KIT , TO 344 460 17 01
999
GASKET KIT , TO 344 460 17 01
999
GASKET KIT , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
GASKET KIT
999
GASKET KIT , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
STEERING WORM WITH STEERING NUT, 10 UP TO CHASSIS 629394,20 UP TO CHASSIS 601108
999
STEERING WORM , TO 044 460 34 01,344 460 08 01
999
STEERING WORM , TO 344 460 17 01
999
PIN AS REQUIRED 6.04MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
PIN AS REQUIRED 6.05 MM, UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
PIN AS REQUIRED 6.06 MM
999
VALVE
999
SEAL RING AS REQUIRED 2.5 MM, UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
SEAL RING AS REQUIRED 2.6 MM
999
BOX , TO 044 460 34 01,344 460 08 01
999
SEAL RING AS REQUIRED 2.7 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SEAL RING AS REQUIRED 2.8 MM
999
SEAL RING
999
SEAL RING , TO 341 460 10 01,344 460 17 01,384 460 71 01,390 460 70 01
999
BOX , TO 344 460 17 01
999
SEAL RING , TO 341 460 10 01,344 460 17 01,384 460 71 01,390 460 70 01
999
SEAL RING , TO 341 460 10 01,344 460 17 01,384 460 71 01,390 460 70 01
999
VALVE , Replaced By: A0004611982
999
SEAL RING , TO 341 460 10 01,344 460 17 01,384 460 71 01,390 460 70 01
999
SEAL RING , TO 341 460 10 01,344 460 17 01,384 460 71 01,390 460 70 01
999
VALVE , Replaced By: A0004612182
999
VALVE
999
COVERTO 000 461 57 01
999
VALVE , UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
COVER , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
COVER , TO 344 460 17 01
999
COVER , TO 344 460 17 01
999
COVERTO 000 461 71 01, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
BOX , Replaced By: A0004617101, +001A0004614205
999
BOX , TO 344 460 17 01
999
BOX , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
BOOT , Replaced By: A3454667096
999
SCREW COLLAR , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
BOOT ON DRIVE END
999
STEERING NUT , UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
NUT , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
COUPLING COLLAR
999
BALL CAGE
999
BOOT , TO 341 460 10 01,344 460 17 01,384 460 71 01,390 460 70 01
999
RING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
PIN , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
PISTON
999
RING
999
SCREW , UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
STEERING SHAFT
999
RING
999
LOCK
999
RING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
LOCK , UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
RING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
BALL RACE , UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
PISTON
999
WASHER
999
PISTON , TO 344 460 17 01
999
BUSHING , Replaced By: A0005861946
999
RING
999
WASHER , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
BUSHING , TO 344 460 17 01
999
BUSHING , TO 044 460 34 01,344 460 08 01
999
STEER.COLUMN JACKET TUBE
999
STEERG. WORM SECTOR SHAFT , Replaced By: A0004625212
999
STEERG. WORM SECTOR SHAFT , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
STEERG. WORM SECTOR SHAFT , NOT USED
999
RING
999
RING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
RING
999
SPACER WASHER
999
OUTER RACE
999
INNER RING38.00 MM
999
INNER RING38.015 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SCREW , Replaced By: A3454667091
999
SCREW BREATHER, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SCREW
999
NUT , Replaced By: N000937035000
999
FITTING ,12068000, 344.030,031,032,03312009117, 345.001,002,003,300
999
SPACER WASHER AS REQUIRED 2.95 MM
999
SPACER WASHER AS REQUIRED 3.00 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.05 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.10 MM
999
SPACER WASHER AS REQUIRED 3.15 MM
999
SPACER WASHER AS REQUIRED 3.20 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.25 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.30 MM
999
SPACER WASHER AS REQUIRED 3.35 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.40 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER
999
NEEDLE BEARING
999
NEEDLE BEARING
999
NEEDLE BEARING
999
NEEDLE BEARING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
NEEDLE BEARING
999
BALL AS REQUIRED 7.991 MM, UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
BALL AS REQUIRED 7.992 MM
999
BALL AS REQUIRED 7.995 MM
999
BALL AS REQUIRED 7.998 MM
999
BALL AS REQUIRED 8.000 MM
999
BALL AS REQUIRED 8.002 MM
999
BALL AS REQUIRED 8.005 MM
999
BALL AS REQUIRED 8.008 MM
999
NEEDLE BEARING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
BALL AS REQUIRED 8.010 MM
999
NEEDLE BEARING
999
BALL AS REQUIRED 7.990 MM
999
BALL AS REQUIRED 7.993 MM
999
BALL AS REQUIRED 7.994 MM, UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
BALL AS REQUIRED 7.996 MM
999
BALL AS REQUIRED 7.997 MM, UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
BALL AS REQUIRED 7.999 MM
999
BALL AS REQUIRED 8.001 MM
999
BALL AS REQUIRED 8.003 MM
999
BALL AS REQUIRED 8.004 MM
999
BALL AS REQUIRED 8.006 MM
999
BALL AS REQUIRED 8.007 MM
999
BALL AS REQUIRED 8.009 MM
999
BALL AS REQUIRED 8.011 MM
999
BALL AS REQUIRED 8.012 MM
999
BALL AS REQUIRED 8.013 MM
