Поз.
Артикул
Описание
10
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
14
FITTING ENGINE AIR COMPRESSOR,CONNECTION: "20"
14
FITTING CONNECTION "2"
18
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
18
SEAL RING , Replaced By: N007603012121
22
THRUST RING BUTT SCREW CONNECTION
26
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
34
UNION NUT BUTT SCREW CONNECTION
38
GLAND LINE CONNECTION
40
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
40
SEAL RING , Replaced By: N007603012121
41
THRUST RING BUTT SCREW CONNECTION
42
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
42
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
44
CLAMP LINE MOUNTING
46
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
48
WASHER COMPRESSED AIR LINE TO BRACKET
48
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
50
NUT PUMP TO BRACKET
50
NUT , Replaced By: N913004006001
70
BRACKET LINE MOUNTING, TO BE ADAPTED DURING ASSEMBLY
74
CLAMP DELIVERY AND SUCTION LINES TO STEERING
74
CLAMP , Replaced By: A6739950001
78
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
82
NUT PUMP TO BRACKET
82
NUT , Replaced By: N913004006001
86
BRACKET COMPRESSED AIR LINE
88
BRACKET CABLE TO TRANSMISSION
88
BRACKET , Replaced By: A3434290940
88
BRACKET CABLE TO TRANSMISSION
90
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
92
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
93
CLAMP DELIVERY AND SUCTION LINES TO STEERING
93
CLAMP , Replaced By: A6739950001
94
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
98
NUT PUMP TO BRACKET
98
NUT , Replaced By: N913004006001
100
BRACKET BATTERY CABLE MOUNTING
102
CLAMP DELIVERY AND SUCTION LINES TO STEERING
102
CLAMP , Replaced By: A6739950001
108
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
110
NUT PUMP TO BRACKET
110
NUT , Replaced By: N913004006001
112
SCREW CABLE HARNESS MOUNTING
112
SCREW , Replaced By: N304017008023
114
WASHER EXHAUST MUFFLER TO STRAP
114
WASHER , Replaced By: N000125008443
116
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
116
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
116
NUT , Replaced By: N913004008001
999
GUIDE , Replaced By: N071752014000
999
ADAPTER FITTING , Replaced By: A0004296634
999
ADAPTER FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "22"
999
ADAPTER FITTING , Replaced By: A0004296934
999
HANDLETO 001 430 17 81,KNORR
999
REPAIR KITTO 001 430 18 81/78 81
999
REPAIR KIT , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO WABCO NR.0182, Replaced By: A0004306260
999
REPAIR KIT , Replaced By: A0014300460
999
REPAIR KIT , Replaced By: A0024209324, +002A0024209424
999
CONNECTOR , Replaced By: A0004311064
999
BANJO UNION , Replaced By: N915052004006
999
CONNECTOR REPAIR SIZE
999
BUSHING , Replaced By: N915062004000
999
BUSHING , Replaced By: N915062004000
999
BUSHING , Replaced By: N915062009000
999
SPRING , Replaced By: A0009935205
999
SCREW. UNION SCREW LINE CONNECTION
999
VALVE , Replaced By: A0034291644
999
VALVE , Replaced By: A0024300381
999
PRESSURE REGULATOR , Replaced By: A0024314906
999
SEAL RING , Replaced By: A0009971548
999
GASKET , Replaced By: A0004311980
999
VALVE , Replaced By: A0014318406
999
VALVE , Replaced By: A0024310406
999
VALVE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0024312906
999
PLUGTO 008 420 59 18,KNORR
999
VALVE , Replaced By: A0034295344
999
VALVE , Replaced By: A0024319306
999
REPAIR KIT , Replaced By: A0025865242
999
REPAIR KIT , Replaced By: A0024301560
999
REPAIR KIT , Replaced By: A0004301160, +001A0004310273, +001A0004318383, +002A0004312185
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
HOSE LEVER TO SUPPORT
999
BRACKET AIR RESERVOIRS I AND II,5 586938
999
STOP LIGHT SWITCH , Replaced By: A0005457009
999
GROMMET CAB FLOOR
999
BRACKET , Replaced By: A3525422840
999
BRACKET (PROTECTION AGAINST TORSION),FRONT AXLE
999
LINE , Replaced By: A3834290801
999
LINE , Replaced By: A6194290801
999
BRACKET , Replaced By: A6205243040
999
BRACKET LINE MOUNTING,4 4389724 691315
999
LINE , Replaced By: A6254293501
999
BRACKET BRACKET TO CROSS MEMBER
999
LOCK (PROTECTION AGAINST TORSION),5 934168
999
WASHER , Replaced By: N000125017016
999
WASHER BRACKET TO FRAME
999
NUT , Replaced By: N308675016001
999
SCREW PLUG , Replaced By: N000908022011
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
999
SCREW , Replaced By: N304017008021
999
FITTING , Replaced By: A0009907871
999
SEAL RING LINE CONNECTION
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
SCREW PIPE CLAMP
999
NUT FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "22",4 821954
