Поз.
Артикул
Описание
316
RESERVOIRTO 344 430 79 01,345 430 79 01, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
316
RESERVOIR , Replaced By: A3454300002
317
SCREW LICENSE PLATE TO BRACKET,4 300861
318
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
319
NUT
320
LINE FROM FLUID RESERVOIR TO BRAKE MASTER CYLINDER,FRONT AXLE BRAKE CIRCUIT 8X0.7 MM
321
FITTING
322
GROMMET GROUND CABLE
324
LINE FROM MASTER CYLINDER TO DISTRIBUTOR 6X0.7 MM
325
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
325
UNION SCREW , Replaced By: A0004280072
328
CONNECTOR
328
CONNECTOR OIL DELIVERY LINE
370
LINE6X0.7 MM
372
LOCK
373
SCREW BRACKET TO DISC WHEEL M 8X16,D 315831
374
BRAKE HOSE
374
BRAKE HOSE , Replaced By: A3454287135
374
BRAKE HOSE
374
BRAKE HOSE
375
DISTRIBUTOR REAR AXLE
375
VERTEILERSTUCK. DISTRIBUTOR REAR AXLE,4 478330
376
SCREW POWER CYLINDER TO BEARING BRACKET
377
LOCK WASHER RAIL TO BATTERY SUPPORT
378
NUT LEVER TO SHIFTING SHAFT
379
BRACKET
379
BRACKET , Replaced By: A3444280440
380
SCREW BRACKET TO TRANSMISSION CASE
383
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
383
UNION SCREW , Replaced By: A0004280072
384
CLAMP LINE TO SIDE MEMBER
384
CLAMP , Replaced By: N916016006200
387
SCREW BRACKET MOUNTING
390
LOCK WASHER PLUG SOCKET
393
NUT TACHOGRAPH TO BRACKET
440
BRAKE HOSE
440
BRAKE HOSE , Replaced By: A3644287335
440
BREMSSCHLAUCH F 380 LANG. BRAKE HOSE FRONT WHEEL BRAKE CYLINDER
444
ANGLE LEFT AND RIGHT BRAKE HOSES
445
SCREW BRACKET TO TRANSMISSION CASE
446
LOCK WASHER RAIL TO BATTERY SUPPORT
447
NUT LEVER TO SHIFTING SHAFT
450
BRACKET. LOCK , Replaced By: A6525040038
460
LINE FROM DISTRIBUTOR TO RIGHT FRONT WHEEL BRAKE HOSE 6X0.7 MM
465
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
465
UNION SCREW , Replaced By: A0004280072
506
LINE FROM FLUID RESERVOIR TO BRAKE MASTER CYLINDER,REAR AXLE BRAKE CIRCUIT 8X0.7 MM
507
GROMMET GROUND CABLE
508
CLAMP ,K 147121, Replaced By: N000000000319
508
CLAMP , Replaced By: N916016008200
509
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
514
LINE FROM CONNECTOR I TO CONNECTOR II 6X0.7 MM
515
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
515
UNION SCREW , Replaced By: A0004280072
516
CONNECTOR
516
CONNECTOR OIL DELIVERY LINE
517
CLAMP LINE TO SIDE MEMBER
518
SCREW BRACKET MOUNTING
519
LOCK WASHER PLUG SOCKET
520
HEX. NUT M 5 DIN 934-5 S. NUT PLUG SOCKET TO FRAME
523
CONNECTOR
523
CONNECTOR OIL DELIVERY LINE
526
LINE FROM CONNECTOR II TO BRAKE HOSE 6X0.7 MM,D 037447
526
LINE FROM CONNECTOR II TO BRAKE HOSE 6X0.7 MM,D 037446
527
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
527
UNION SCREW , Replaced By: A0004280072
529
HOSE BRAKE LINE TO REAR AXLE,4 644238
532
CLAMP WATER TEMPERATURE GAUGE CABLE TO FIRE WALL
535
SCREW FLEXIBLE SHAFT TO BRACKET
538
WASHER VALVE TO BRACKET,5 602406
541
LOCK WASHER T-FITTING TO BRACKET
544
HEX. NUT M 4 DIN 934-5 S. NUT FUEL CONSUMPTION DISPLAY
547
HOSE BRAKE LINE TO REAR AXLE,4 644238
550
CLAMP
552
WASHER PLUG MOUNTING, FOR VEHICLES HAVING HIGH CAB 344
554
SHEET METAL SCREW LINE TO ELBOW CONNECTION
560
CLAMP LINE TO SIDE MEMBER
560
CLAMP , Replaced By: N916016006200
561
SCREW BRACKET MOUNTING
562
LOCK WASHER PLUG SOCKET
563
VALVE , Replaced By: A3454300281
576
BRACKET
576
ANGLE , Replaced By: A3214280440
580
DISTRIBUTOR REAR AXLE
580
VERTEILERSTUCK. DISTRIBUTOR REAR AXLE,4 478330
582
BRACKET
582
BRACKET , Replaced By: A3524280740
582
ANGLE DISTRIBUTOR
583
SCREW POWER CYLINDER TO BEARING BRACKET
586
LOCK WASHER RAIL TO BATTERY SUPPORT
590
LINE FROM DISTRIBUTOR TO LEFT REAR WHEEL 6X0.7 MM,D 037447
590
LINE FROM DISTRIBUTOR TO LEFT REAR WHEEL 6X0.7 MM,D 037446
593
LINE FROM DISTRIBUTOR TO RIGHT REAR WHEEL 6X0.7 MM, 364.101 FROM CHASSIS 37068, -364.111 FROM CHASSIS 38388, -364.152 FROM CHASSIS 36730, -364.162 FROM CHASSIS 35746, -364.173 FROM CHASSIS 36749
593
LINE FROM DISTRIBUTOR TO RIGHT REAR WHEEL 6X0.7 MM,D 037446
594
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
594
UNION SCREW , Replaced By: A0004280072
595
CLAMP BRAKE LINE MOUNTING
597
HOSE BRAKE LINE TO REAR AXLE,4 644238
599
SCREW BRACKET TO DISC WHEEL M 8X16,D 315831
601
LOCK WASHER RAIL TO BATTERY SUPPORT
999
PROTECTIVE CAP , Replaced By: A0004217187
999
THRUST PIN SEE FIG. NO.: 080,FB330168
999
HOHLSCHRAUBE FUR. HOLLOW SCREW MASTER CYLINDER,CONNECTION "2.1",4 338292
999
CONNECTOR
999
CONNECTOR MASTER CYLINDER,CONNECTION "2.1",4 338292
999
RINGSTUTZEN. DISTRIBUTOR BRAKE MASTER CYLINDER, 600253-601115
999
DIAPHRAGMTO 344 429 73 44
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
SPRING RETAINERTO 000 429 63 44,000 429 59 44
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
999
BOTTOM VALVE. VALVE , Replaced By: A0015861543
999
REPAIR KITTO 003 430 44 01
999
REPAIR KIT SPRING LOAD ACCUMULATOR CYLINDER TO 345 431 72 14
999
REPAIR KITTO 345 431 72 14,98 345 431 02 14, USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
REPAIR KIT LARGE SCOPE TO 000 434 30 01
999
REPAIR KITTO 000 430 55 81,WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
SPACER RING AT BRAKE BOOSTER
999
LOCK
999
WASHER , Replaced By: A0004311176
999
SPRING RETAINERTO 002 430 27 01
999
SLIDETO 000 431 50 14,000 431 24 14
999
FILTER BOTTOMTO 000 431 24 14
999
PROTECTIVE CAP BRAKE BOOSTER
999
THREADED UNION BRAKE CYLINDER
999
WASHERTO 002 430 41 01, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
GASKET34X2X6 MM,GRAU
999
VALVE SEATWABCO,002 0,012 0
999
VALVE SEATGRAU
999
VALVEWABCO,002 0,012 0
999
BRAKE CYLINDER , Replaced By: A3644317014
999
PISTONTO 002 430 27 01
999
FILLER CAP
999
PROTECTIVE CAPTO 000 434 08 01,345 434 71 01
999
CUP , Replaced By: A0015864342
999
VALVE , Replaced By: A0004320807
999
CUP 3/2-WAY VALVE WABCO
999
VALVE"KNORR", USED WITH AIR BRAKE
999
GASKETTO 000 429 16 30
999
REPAIR KITTO 002 430 41 01
999
REPAIR KIT WHEEL CYLINDER
999
REPAIR KIT , Replaced By: A0004305760
999
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
CAPTO 001 431 71 14
999
T-FITTING FITTING,5 461950
999
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
999
SPRING
999
SPRINGWABCO,002 0,012 0
999
SPRINGWABCO,002 0,012 0
999
SPRINGBOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
SNAP RINGTO 002 430 41 01, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
CLAMP , Replaced By: N916016018204
999
HANDLETO 000 434 23 01
999
HANDLETO 345 430 73 81
999
REPAIR KIT , Replaced By: A0004304106
999
REPAIR KIT SMALL SCOPE TO 000 434 30 01
999
REPAIR KIT , B03543/06/08 UP TO IDENT NO.: 549429
999
SPRING
999
SEAL RING28X2 MM,GRAU
999
SEAL RING86X2 MM,GRAU
999
CUP , Replaced By: A0014312386
999
CUPTO BOSCH-NR.0481 027 104
999
CUP101
999
SPRINGTO BOSCH-NR.0481 027 024
999
REPAIR KIT , Replaced By: A0034201724
999
REPAIR KIT
999
FITTING
999
FITTING AIR RESERVOIR,CONNECTION: "13"
999
WHEEL BRAKE CYLINDER , Replaced By: A3454207418
999
REPAIR KITTO 000 430 47 81
999
REPAIR KIT 3/2-WAY VALVE WABCO
999
SEAL RING
999
REPAIR KIT SMALL SCOPE TO 345 430 73 81
999
SEAL RING BRAKE MASTER CYLINDER, UP TO IDENT NO. 734559,FROM CHASSIS,STANDARD EQUIPMENT
999
SEAL RING , Replaced By: A0179974148
999
SEAL RING22.3X2.4 MM,GRAU
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RING18.72X2.62 MM,WABCO,002 0,012 0
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGTO 000 434 23 01
999
SPRINGTO 345 420 71 18
999
WASHER , Replaced By: A3454317076
999
WASHER , Replaced By: A3454317376
999
CUPTO 344 430 73 01
999
CUP , Replaced By: A3454317286
999
PISTON
999
SPRINGTO 000 431 21 14
999
SEAL RING6.07X1.78 MM,WABCO,002 0,012 0
999
SEAL RING32.99X2.62 MM,WABCO,002 0,012 0
999
SEAL RING12.42X1.78 MM,WABCO,002 0,012 0
999
SEAL RING17.12X2.62 MM, 402,407 FROM CHASSIS 657000
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 30 01
999
