Поз.
Артикул
Описание
4
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
4
PLASTIC PIPE RISING PIPE 4X6 MM
8
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
14
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
20
UNION NUT
25
GLAND , Replaced By: A0019901667
25
SEAL CONE
30
SLEEVE LEAK LINE
35
TS DOUBLE FITTING SOLENOID VALVE
40
SLEEVE LEAK LINE
45
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
50
BRACKET LINE MOUNTING
55
ANGLE LINE MOUNTING
60
SCREW , Replaced By: N304017008027
60
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
65
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
65
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
65
NUT , Replaced By: N913004008001
70
SCREW BRACKET TO SIDE MEMBER
70
SCREW , Replaced By: N304017010002
75
NUT STRAP TO BRACKET
75
NUT , Replaced By: N910113010000
80
CLAMP LINE MOUNTING
80
CLAMP LINE MOUNTING
85
SCREW COVER PLATE TO BRACKET
88
SCREW COVER PLATE TO COVER PLATE M 6 X 10
88
SCREW , Replaced By: N304017006034
90
NUT PUMP TO BRACKET
90
NUT , Replaced By: N913004006001
93
NUT BALL PIVOT TO LEVER
95
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
100
VALVE"WESTINGHOUSE"
100
VALVE EXHAUST BRAKE OPERATING MECHANISM WESTINGHOUSE
100
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH, OPTIONAL WITH 000 434 08 01
100
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH
105
CUP 3/2-WAY VALVE WABCO
105
CUP 3/2-WAY VALVE WABCO
110
HANDLETO 000 434 24 01
110
HANDLETO 000 434 23 01
115
SEAL RINGTO 000 434 21 01
115
SEAL RINGTO 000 434 23 01
115
SEAL RINGTO 000 434 23 01
120
SPRINGTO 000 434 21 01
125
STRAINERTO 000 434 21 01
130
REPAIR KIT 3/2-WAY VALVE WABCO
130
REPAIR KITTO 000 434 11 01
130
REPAIR KIT 3/2-WAY VALVE BOSCH
135
FITTING CONNECTION TO STOP LIGHT SWITCH, Replaced By: A3899970272
135
FITTING CONNECTION TO STOP LIGHT SWITCH
140
SEAL RING LINE CONNECTION
145
FITTING CONNECTION TO STOP LIGHT SWITCH, Replaced By: A3899970272
145
FITTING CONNECTION TO STOP LIGHT SWITCH
145
FITTING CONNECTION TO STOP LIGHT SWITCH
145
FITTING CONNECTION TO STOP LIGHT SWITCH
150
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
150
BREATHER , Replaced By: A3933280065
150
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
155
FITTING , Replaced By: A0029906071
155
TS DOUBLE FITTING SOLENOID VALVE
160
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
160
FITTING FROM PUMP TO CYLINDER
165
SEAL RING LINE CONNECTION
165
SEAL RING LINE CONNECTION
170
HOLLOW SCREW HEATING CONNECTION
170
HOLLOW SCREW HEATING CONNECTION
175
DISTRIBUTOR WITH BRACKET, NOT USED
180
SWITCH EXHAUST BRAKE,K 251255
185
SCREW BRACKET TO SIDE MEMBER
190
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
195
NUT BRACKET TO SUPPORT AND TO END PIECE
200
WASHER OPERATING VALVE TO SIDE MEMBER SHELL
205
NUT , Replaced By: N080705026003
205
NUT 3/2-WAY VALVE TO CAB,4 685151
210
SPRING WASHER AT CAB FLOOR
215
PROTECTIVE PLATE OPERATING VALVE TO SIDE MEMBER SHELL
220
BRACKET
225
SCREW , Replaced By: N304017008021
225
SCREW PIPE CLAMP
230
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
235
NUT
240
WASHER , Replaced By: N001440027000
240
WASHER VALVE TO BRACKET
245
NUT , Replaced By: N080705026003
245
NUT 3/2-WAY VALVE TO CAB,4 685151
250
WASHER , Replaced By: N000125008443
250
WASHER EXHAUST MUFFLER TO STRAP
250
WASHER , Replaced By: N009021006208
250
WASHER COMPRESSED AIR LINE TO BRACKET
255
LOOM TIE LINE MOUNTING 280 MM
999
LINE , Replaced By: A0004296201
999
ELBOW FITTING
999
BRACKET POS. CABLE,XB209706
999
INSULATION
999
FITTING , Replaced By: A0019909871
