Поз.
Артикул
Описание
169
FAN
175
PULLEY FAN
175
PULLEY FAN
181
LOCK WASHER PARKING BRAKE
187
SCREW. CAP BOLT COVER TO CASE M8X25
187
SCREW
187
SCREW , Replaced By: N000912008202
187
SCREW , Replaced By: N000000000190
193
NEEDLE BEARING
199
THRUST WASHER FAN
203
THRUST WASHER FAN
205
SPACER TUBE FAN
208
THRUST RING FAN
211
SEAL RING FAN
214
SEAL RING FAN
217
THRUST WASHER
223
THRUST RING
235
EXPANSION PLUG
241
LOCK WASHER BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT
247
SCREW , Replaced By: N000912006175
247
SCREW , Replaced By: A0019907212
247
SCREW SHIM TO LEAF SPRING
253
V-BELT12.5X1525, UP TO ENGINE 400824 YEAR OF MANUFACTURE 1995
253
V-BELT12.5X1435 MM
265
PULLEY
271
LEVER
277
PIVOT PIN
283
HUB
289
LOCK RING SHIFT LEVER BEARING
295
SEAL RING
301
SPACER WASHER
307
GROOVED BALL BEARING
313
GASKET
319
SPACER RING
325
LOCK RING
331
PULLEY
337
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
343
SCREW BRACKET TO EXHAUST PIPE BRACKET
343
SCREW , Replaced By: N304017008024
349
SEAL RING SCREW PLUG
355
SCREW PLUG HEATING PIPE,6112368 0000014 375862
361
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
367
NUT RELEASE BEARING LUBRICATION
367
NUT , Replaced By: N308675014000
367
NUT , Replaced By: N308675014002
373
SCREW BEARING BRACKET TO FRONT AXLE M 20X115,5 290345
379
LOCK WASHER BRACKET TO SUPPORT
385
NUT REAR SPRING TO REAR AXLE
385
NUT , Replaced By: N308673020002
385
NUT , Replaced By: N308674020000
391
SCREW , Replaced By: N304017008040
391
SCREW BRACKET TO SIDE MEMBER
397
NUT
397
NUT , Replaced By: N304032008006
999
OIL SEPARATOR , Replaced By: A0000184235
999
STUDTO 002 151 81 01,003 151 57 01
999
STUDTO 002 151 81 01,003 151 57 01
999
STUDTO 002 151 81 01,003 151 57 01
999
SHAFT WITH COUPLING TO 002 151 81 01,003 151 57 01
999
SPRINGTO 002 151 81 01,003 151 57 01BOSCH
999
CARBON BRUSH SETTO 000 151 33 01, 001 151 38 01
999
ARMATURE , Replaced By: A0001514315
999
EXCITER COIL COIL 1 TO 001 151 38 01
999
SPACER WASHER0.30 MM,TO 002 151 81 01,003 151 57 01
999
SPACER WASHER0.50 MM,TO 002 151 81 01,003 151 57 01
999
ARMATURE , Replaced By: A0001514015
999
SPACER WASHER0.20 MM,TO 0021518101,0031515701 BOSCH
999
BUSHING STARTER PINION TO 004 151 58 01/003 151 87 01
999
SPRINGTO 001 151 38 01
999
SPACER WASHER0.20 MM,TO 0021518101,0031515701 DELCO
999
BEARINGTO 002 151 81 01,003 151 57 01
999
SPRINGTO 003 151 57 01
999
ARMATURETO 002 151 81 01
999
BUSHINGTO 002 151 81 01,003 151 57 01
999
BUSHINGTO 002 151 81 01,003 151 57 01
999
ARMATURE
999
CARBON BRUSH SET
999
EXCITER COIL , Replaced By: A0001517055
999
EXCITER COIL , Replaced By: A0001519255
999
EXCITER COILTO 003 151 57 01
999
EXCITER COIL , Replaced By: A0011512255
999
PINIONTO 002 151 81 01
999
CARBON BRUSH SET , Replaced By: A0001518914
999
CARBON BRUSH SET
999
CARBON BRUSH SETTO 003 151 57 01
999
EXCITER COILTO 003 151 04 01/74 01/88 01
999
SOLENOID SWITCHTO 003 151 04 01/74 01,001 151 96 01
999
SOLENOID SWITCHTO 001 151 41 01,001 151 38 01
999
SOLENOID SWITCH CONTROL RELAY TO 002 151 81 01,003 151 57 01BOSCH, Replaced By: A0011529010
999
SOLENOID SWITCH ENGAGEMENT RELAY TO 003 151 57 01 BOSCH
999
SOLENOID SWITCH , Replaced By: A0001528910
999
SOLENOID SWITCH
999
SOLENOID SWITCH ENGAGEMENT RELAY TO 002 151 81 01
999
REPAIR KIT STARTING MOTOR TO 004 151 00 01
999
SCREWTO 003 151 87 01
999
SCREWTO 003 151 18 01
999
SCREW , Replaced By: A0019905520
999
STUDTO 003 151 13 01
999
SNAP RINGTO 002 151 81 01,003 151 57 01
999
V-BELT , Replaced By: A0049971392
999
EXCITATION WINDING
999
SOLENOID SWITCH ENGAGEMENT RELAY TO 003 151 57 01 DELCO
999
SOLENOID SWITCH CONTROL RELAY TO 002 151 81 01,003 151 57 01DELCO
999
SCREWTO 004 151 58 01
999
COUNTERSUNK BOLT W SLOTTO 003 151 08 01
999
SCREWTO 003 151 08 01, Replaced By: A0019904102
999
SEAL RING
999
V-BELT , Replaced By: A0039973092
999
SEAL RINGTO 002 151 81 01,003 151 57 01
999
SEAL RINGTO 000 431 59 14
999
ALTERNATOR
999
SEAL RINGTO 001 151 38 01
999
NEEDLE BEARING , Replaced By: A0001513849
999
NEEDLE BEARINGTO 002 151 81 01,003 151 57 01
999
SEAL RING , Replaced By: A0001513849
999
SPRINGTO 002 151 81 01,003 151 57 01DELCO
999
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
999
SEAL RINGTO 004 151 00 01
999
SEALING RING. SEAL RING GUIDE TUBE SEAL HOLDER
999
OIL DIPSTICK
999
GUIDE TUBE OIL DIPSTICK
999
SPACER TUBE
999
GASKET
999
GUIDE TUBE
999
BRACKET , Replaced By: A3520186340
999
VIBRATION ABSORBER , Replaced By: A3520303903
999
VIBRATION ABSORBER ONE-GROOVE
999
POINTER
999
POINTER AT TIMING CASE COVER
999
PULLEY THREE-GROOVE
999
THRUST RING VIBRATION ABSORBER TO CRANKSHAFT
999
FAN , FROM ENGINE 548055-999999 YEAR OF MANUFACTURE 1979-1990 FROM ENGINE 100001 YEAR OF MANUFACTURE 1990
999
PULLEY
999
BELL HOUSING
999
SCREW VIBRATION ABSORBER WITH PULLEY TO CRANKSHAFT
999
CLAMP
999
BALL
999
KEYTO 003 151 57 01,002 151 81 01
