Поз.
Артикул
Описание
55
OIL PAN
55
OIL PAN
55
OIL PAN
55
OIL PAN
61
OIL PAN
67
OIL PAN
67
OIL PAN
67
OIL PAN
85
OIL PAN
85
OIL PAN WITH OIL RETURN CONNECTION FLANGE,310563
85
OIL PAN
88
OIL PAN
88
OIL PAN
88
OIL PAN
88
OIL PAN
88
OIL PAN
88
OIL PAN
94
OIL PAN
94
OIL PAN
94
OIL PAN
94
OIL PAN
121
SEAL RING LINE CONNECTION
121
SEAL RING OIL DRAIN
121
SEAL RING
121
SEAL RING VALVE TO VALVE,K 025179
121
SEAL RING OIL DRAIN 26X34 MM
125
SCREW PLUG OIL DRAIN
125
SCREW PLUG
125
SCREW PLUG , Replaced By: A4039970230
125
SCREW PLUG OIL DRAIN
125
SCREW PLUG , UP TO ENGINE 921 001982 927 000355 928 000589 929 000007
125
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
136
SCREW PILLAR TO BRACKET AND TO FRONT PANEL
136
SCREW , Replaced By: N304017008030
138
SEAL RING LINE CONNECTION
138
SEAL RING
139
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
139
SCREW PLUG , Replaced By: N007604014110
139
SCREW PLUG FUEL TANK
144
GASKET KIT OIL PAN
144
GASKET KIT , Replaced By: A3520105827
144
GASKET KIT , NOT USED, Replaced By: A3520102480
144
GASKET KIT , Replaced By: A3520100580
144
GASKET KIT , NOT USED, Replaced By: A3660100880
144
GASKET KIT , Replaced By: A3660100780
144
GASKET KIT. GASKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 996747YEAR OF MANUFACTURE 1990, Replaced By: A3660100680
144
GASKET KIT , Replaced By: A3520101980
144
PART NAME MISSING OIL PAN
144
GASKET KIT OIL PAN
144
GASKET KIT , Replaced By: A3520102280
144
GASKET OIL PAN
144
GASKET KIT OIL PAN
144
GASKET KIT OIL PAN
144
GASKET KIT , NOT USED
144
GASKET KIT OIL PAN
145
STUD BOLT OIL PAN TO CYLINDER CRANKCASE M 8X50
145
STUD BOLTM 8X45, WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
145
STUD OIL PAN TO CYLINDER CRANKCASE
145
STUD HEATING WATER CONNECTION TO CYLINDER HEAD
151
SCREW , Replaced By: N304017006031
151
SCREW , Replaced By: N304017008030
151
SCREW TRAILER CONTROL VALVE TO BRACKET,4 940459
151
SCREWM 8X40
151
SCREW AIR COMPRESSOR LINE
151
SCREW OIL PAN TO CYLINDER CRANKCASE
151
SCREW PILLAR TO BRACKET AND TO FRONT PANEL
151
SCREW
151
SCREW INJECTION PUMP DRIVE TO TIMING CASE M 8X140
175
NUT , Replaced By: N913004008001
175
NUT
175
NUT POWER CYLINDER
175
NUT SHIFTING CYLINDER TO PIN,5 353829
175
NUT , Replaced By: N304032008006
295
FLANGE TURBOCHARGER OIL RETURN,310563
295
FLANGE TURBOCHARGER OIL RETURN
295
FLANGE TURBOCHARGER OIL RETURN
295
FLANGE OIL RETURN
295
FLANGE OIL RETURN
295
FLANGE OIL RETURN
307
FLANGE
307
FLANGE
313
GASKET FLANGE TO OIL PAN
313
GASKET , Replaced By: A3660180380
325
SPRING WASHER , Replaced By: N000137008212
325
LOCK WASHER BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT
325
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
325
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
331
SCREWROCKINGER,TYP 59 U150
331
SCREW
331
SCREW EXHAUST PIPE TO MUFFLER AND TO HEATER UNIT M 8X55
331
SCREW STOP TO BEARING BRACKET M 6X12,781683, 10/50820177, 20/60
331
SCREW
331
SCREW , Replaced By: N000000000190
331
SCREW , Replaced By: A0009847929
337
SCREW , Replaced By: N304017008043
337
SCREW , Replaced By: N304017008030
337
SCREW PILLAR TO BRACKET AND TO FRONT PANEL
337
SCREW VALVE TO BRACKET M 8X55
367
BRACKET OIL RETURN LINE
367
BRACKET OIL RETURN LINE
373
SCREW LICENSE PLATE BRACKET
379
CLAMP
999
SCREW FITTING , Replaced By: A4039971172
999
SCREW BEARING COVER TO TRANSMISSION CASE M 8X65
999
COMBINATION BOLT , Replaced By: A0049901601
999
THREADED INSERT
999
GASKET SUCTION BASKET TO OIL PUMP COVER, 343.919-016 UP TO ENGINE 122779 343.919-016 FROM ENGINE 104828
999
SCREW PLUG , Replaced By: A3219970630
999
STUD OIL FILLER NECK TO OIL PAN
999
EXPANSION PLUG P.T.O.
999
WASHER SHIFTING CYLINDER TO CASE
999
SPRING WASHER , Replaced By: N000137008212
999
GUIDE TUBE OIL DIPSTICK
999
SCREW PLUG
999
SUCTION PIPE , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 931773/89, Replaced By: A3961800551
999
SUCTION BASKET SUCTION PIPE,OIL PUMP
999
SUCTION BASKET ,057309, Replaced By: A3661860101, +001A3641810020
999
SUCTION PIPE
999
SUCTION PIPE ,057309, Replaced By: A3661800251, +001A3641810020
999
OIL PAN
999
OIL PAN
999
OIL PAN , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 032598, Replaced By: A3660102613
999
OIL PAN , Replaced By: A3520104127, +001A3520100680, +001N007603014104, +001N007604014106
999
OIL PUMP
999
HOSE
999
HOSE , Replaced By: A3529972482, +002A0009961501, +002N000934010014
999
FITTING , Replaced By: N915013008002
999
SCREW PLUG , Replaced By: A3469970030
999
WASHER
999
REPAIR KIT , Replaced By: A3520100880
999
REPAIR KIT , Replaced By: A3520100680
999
REPAIR KIT , Replaced By: A3520100580
999
REPAIR KIT , Replaced By: A3520100480
999
REPAIR KIT , Replaced By: A3520100380
999
SUCTION BASKET OIL PUMP
999
SUCTION BASKET ,000141844205, Replaced By: A3521861901, +001A3641810020
999
SUCTION BASKET ,931773, Replaced By: A3521861801, +001A3641810020
999
SUCTION BASKET
999
HOUSING
999
DRIVE SHAFT
999
DRIVE SHAFT
999
COVER
999
HELICAL GEAR , Replaced By: A3661810108
999
COVER , Replaced By: A3521811220
999
HELICAL GEAR , Replaced By: A3521811108
999
DRIVE SHAFT , 03081673.5 KW (100 PS) 02551080.9 KW (110 PS) 06737492.6 KW (126 PS) 003613 110.3 KW (150 PS)
999
HOUSING
999
HOUSING
999
DRIVE SHAFT
999
HOUSING
999
COVER
999
GEAR
999
DRIVE SHAFT , Replaced By: A3441810205
999
OIL PUMP , Replaced By: A3521807001, +001A3521800955, +001A3121860080, +002N000137008204, +002N000931008075
999
OIL PUMP , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 110592, Replaced By: A3641800101
999
OIL PUMP
999
OIL PUMP , Replaced By: A3521807001, +001A3521800951, +001A3121860080, +002N000933008050
999
OIL PUMP , Replaced By: A3521807001
999
OIL PUMP , Replaced By: A3521806401
999
OIL PUMP , Replaced By: A3521807001, +001A3521800951, +001A3121860080, +002N000933008050
999
OIL PUMP , Replaced By: A3521807001, +001A3521800651, +001A3521810120, +001A3121860080, +002N000933008048
999
OIL PUMP
999
OIL PUMP , Replaced By: A3521806401, +001A3521800451, +001A3121860080, +002N000933008040
999
OIL PUMP , Replaced By: A3521807001, +001A3521800955, +001A3121860080, +002N914010008008
999
OIL PUMP , Replaced By: A3521807001, +001A3521800855, +001A3121860080, +002N914010008008
999
OIL PUMP , SEE SA 083017, Replaced By: A3521807001, +001A3521801251, +001A3121860080, +001N000931008075, +001N000933008050
999
OIL PUMP , Replaced By: A3521804201
999
OIL LINE TURBOCHARGER OIL RETURN
999
SUCTION PIPE ,844205, Replaced By: A3521803051, +001A3641810020
999
SUCTION PIPE ,844205, Replaced By: A3521802951, +001A3641810020
999
SUCTION PIPE , Replaced By: A3521802451
999
SUCTION PIPE , Replaced By: A3521802351
999
SUCTION PIPE , Replaced By: A3521801951, +001A1101800355, +001N007993070100
999
SUCTION PIPE , Replaced By: A3521802651
999
SUCTION BASKET , Replaced By: A3521861301, +001A1101800355, +001N007993070100
999
SUCTION BASKET , Replaced By: A3521801651, +001A1101800355, +001N007993070100
999
OIL LINE TURBOCHARGER OIL RETURN,310563
999
SUCTION BASKET , Replaced By: A3521861201, +001A1101800355, +001N007993070100
999
SUCTION BASKET , Replaced By: A3521860801, +001A1101800155, +001A1101860007, +001N007993070100
999
SUCTION PIPE , Replaced By: A3521801451
999
SUCTION BASKET ,291735, Replaced By: A3521801055
999
SUCTION PIPE , Replaced By: A3521801355
999
SUCTION BASKET , Replaced By: A3521861301, +001A1101800355, +001N007993070100
999
SUCTION BASKET , Replaced By: A3521861201, +001A1101800355, +001N007993070100
999
SUCTION PIPE , Replaced By: A3521800451
999
BRACKET SUCTION PIPE TO OIL PUMP TO 352 180 43 01
999
SUCTION PIPE , Replaced By: A3141801551
999
CONNECTOR , Replaced By: A3521800284
999
SUCTION PIPETO 352 180 43 01
999
GASKET , Replaced By: A3660180380
999
FLANGE , Replaced By: A3520181744
999
OIL PAN , Replaced By: A3520109813
999
OIL BAFFLE , Replaced By: A3520140166
999
OIL FILLER NECK , Replaced By: A3520109764
999
OIL PAN , Replaced By: A3520109513
999
OIL PAN , Replaced By: A3520104827, +001A1210140457
999
OIL PAN , Replaced By: A3520109113, +001A3520180244, +001A3520181744, +002A3660180380, +001A3529970472, +002N000912006004, +003N000912008012, +001N007603014400, +002N007980006003, +006N007980008003
999
OIL PAN
999
OIL PAN , Replaced By: A3520104013
999
OIL PAN , Replaced By: A3520104013
