Поз.
Артикул
Описание
12
GLOW PLUG
12
GLOW PLUG
12
GLOW PLUG
12
GLOW PLUG
12
GLOW PLUG
12
GLOW PLUG , Replaced By: A9061590101
12
GLOW PLUG , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3661590401
12
GLOW PLUG , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3661590401
12
GLOW PLUG , Replaced By: A9061590101
12
GLOW PLUG , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3641590401
12
GLOW PLUG , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3641590401
24
NUT
36
FLANGE
36
FLANGE
48
SEAL TO LOCK THE BORE MEANT FOR FLAME START SYSTEM
48
SEAL , Replaced By: A4420780180
60
SCREW RELAY VALVE TO BRACKET
72
VALVE (ELECTROMAGNET VALVE)
72
VALVE (ELECTROMAGNET VALVE)
72
VALVE , Replaced By: A0000784749
72
VALVE , Replaced By: A0000784749
72
VALVE , Replaced By: A0000784849
84
BRACKET SOLENOID VALVE
84
BRACKET SOLENOID VALVE
84
BRACKET
96
HEXAGON HEAD BOLT END COVER TO HOUSING M6X12
96
SCREW FEED LINE AND RETURN LINE
96
SCREW , Replaced By: N304017006018
96
SCREW COVER PLATE TO COVER PLATE M 6 X 12
102
WASHER HEAT SHIELD TO BRACKET
102
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
108
SCREW FUEL FILTER TO SUPPORT
120
SWITCH,AUTOMATIC TEMPERATURE
120
SWITCH,AUTOMATIC (TEMPERATURE SWITCH)
120
SWITCH,AUTOMATIC , Replaced By: A0075455224
134
LINE , Replaced By: A3660781302
134
LINE FROM SOLENOID VALVE TO HEATER PLUG
138
LINE , Replaced By: A3660781402
138
LINE , Replaced By: A3660781302
138
LINE FROM SOLENOID VALVE TO HEATER PLUG
148
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
148
PLASTIC PIPE RISING PIPE 4X6 MM
160
CONNECTOR FUEL LINES TO SOLENOID VALVE
172
UNION NUT FUEL LINES TO SOLENOID VALVE
172
UNION NUT
172
UNION NUT
184
FITTING
196
SEAL RING PNEUMATIC VALVE
196
SEAL RING , Replaced By: N007603010110
208
DOUBLE TAPER RING LEAK LINE TO CYLINDER HEAD
220
UNION NUT BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
232
HOLLOW SCREW FUEL LINE LEADING TO FUEL PUMP
246
HOLLOW SCREW FUEL LINE LEADING TO FUEL PUMP
258
SEAL RING SCREW PLUG
270
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
270
BANJO UNION AXLE BREATHING 4/8
270
BANJO UNION HOSE WIDTH, / I.D., 4/16 MM,5 999999K 040105
282
BANJO UNION , Replaced By: N000000000363
282
BANJO UNION FEED
282
BANJO UNION HEATING CONNECTION,K 169122
294
SCREW PLUG , Replaced By: N007604014110
294
SCREW PLUG FUEL TANK
306
SEAL RING INJECTION PUMP
318
LOOM TIE LINE MOUNTING 280 MM
318
LOOM TIE , Replaced By: A0019978390
326
VALVE FROM INJECTION PUMP OVERFLOW VALVE TO RETURN CONNECTION
332
SEAL RING FUEL LINE TO FEED PUMP
338
FITTING HAND PUMP TO FUEL FILTER
999
SCREW
999
SCREW FUEL FILTER TO SUPPORT, NOT USED
999
SCREW , Replaced By: N304017010051
999
PLUG SOCKET , Replaced By: A0025403481, +001A0025408181
999
BRACKET , Replaced By: A3604293140
999
LINE FROM SOLENOID VALVE TO HEATER PLUG, NOT USED
999
BRACKET SOLENOID VALVE
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
PARTS KIT TWO PIN JACK CONNECTOR
