Поз.
Артикул
Описание
1
TS DOUBLE FITTING SOLENOID VALVE
1
FITTING , Replaced By: A0029906071
7
T-FITTING AT DISTRIBUTOR,4 481288
17
VALVE (SOLENOID VALVE) HERION
19
FITTING LINE CONNECTION
19
FITTING LINE CONNECTION, Replaced By: N000000006446
20
SEAL RING LINE CONNECTION
22
BRACKET VALVE
24
CLAMP SENSOR CABLE TO BRACKET
24
CLAMP , Replaced By: N916016006201
26
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
26
BRACKET FUEL LINES
28
HOSE (QUICK BREATHER VALVE)
28
HOSE
29
SEAL RING LINE CONNECTION
30
SCREW-IN FITTING
31
BRACKET LINE MOUNTING
32
CLAMP LINE MOUNTING
36
PLUG SOCKET REPAIR VERSION, NOT FOR DANGER CATEGORY VEHICLES M 24X1
37
PIN BUSHING HOUSING. PLUG HOUSING FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH
38
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
39
CLAMP CABLE HARNESS MOUNTING,4 494992
39
CLAMP , Replaced By: A0005460875
40
SWITCH TWO-SPEED REAR AXLE CONTROL,4 188089
40
SWITCH TWO-SPEED REAR AXLE CONTROL,4 188089
41
NUT POTENTIOMETER TO INSTRUMENT PANEL
41
NUT ,928519
41
NUT SWITCH TO APPARATUS PLATE
42
BUTTON TWO-SPEED REAR AXLE CONTROL,4 188089
42
BUTTON SWITCH,928519
43
BOOT ,928519
44
BOOT SWITCH,928519
999
SHELL TWO-SPEED REAR AXLE CONTROL,4 188089
999
SHELL TWO-SPEED REAR AXLE CONTROL,4 188089
999
NUT , Replaced By: A0029906251
999
SWITCH , Replaced By: A3445457111
999
REPAIR KITTO 001 997 34 36,002 997 58 36,
999
PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 2.5 MM2
999
REPAIR KIT , Replaced By: A0012608357
999
BRACKET , Replaced By: A3124761236
