Поз.
Артикул
Описание
1
WHEEL BRAKE CYLINDER , Replaced By: A0034207918
1
WHEEL BRAKE CYLINDER , Replaced By: A0034207918
1
WHEEL BRAKE CYLINDER
1
WHEEL BRAKE CYLINDER LESS THRUST PIN 46.83 MM,TEVES
2
SPRING , UP TO IDENT NO 910369 EXCEPT FOR 501415-599999,FROM IDENT NO 910370 ALSO INSTALLED ON 501415-599999,SEE 744.4 UNIT SPARE PARTSLIST
3
CUP , UP TO IDENT NO 910369 EXCEPT FOR 501415-599999,FROM IDENT NO 910370 ALSO INSTALLED ON 501415-599999,SEE 744.4 UNIT SPARE PARTSLIST
4
PISTON , UP TO IDENT NO 910369 EXCEPT FOR 501415-599999,FROM IDENT NO 910370 ALSO INSTALLED ON 501415-599999,SEE 744.4 UNIT SPARE PARTSLIST
5
PROTECTIVE CAP , Replaced By: A3454237087
6
THRUST PINTEVES
7
VALVE CLUTCH SLAVE CYLINDER
7
VALVE , Replaced By: A3075530107
8
PROTECTIVE CAP , Replaced By: A0004217187
8
PROTECTIVE CAP , Replaced By: A3454237020
8
PROTECTIVE CAP ,5 962906
9
PROTECTIVE PLATE , FOR 002 420 77 18,003 420 78 18
10
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
11
SCREW END PIECE TO EXHAUST PIPE M 10X25
12
BRAKE ANCHOR PLATE ,796990, 10/20, 790758, 50/60
12
BRAKE ANCHOR PLATE , Replaced By: A3024201316
13
INSPECTION HOLE COVER
14
RIVET
15
ADJUSTER , Replaced By: A3025860442
16
HEXAGONAL PIECE BRAKE ANCHOR PLATE TO REAR AXLE TUBE
17
GROOVED PIN BRAKE READJUSTMENT
18
SPRING ADJUSTING ECCENTRIC TO BRAKE ANCHOR PLATE, 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
19
LOCK BRAKE ANCHOR PLATE TO REAR AXLE TUBE
20
SCREW , UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501414,FROM CHASSIS 910370 AND 501415-599999 SEE SPARE PARTS LIST 744.3
21
LOCK WASHER ,796990, 10/20, 790758, 50/60
22
NUT STRAP TO SUPPORT
23
SCREW , Replaced By: A3029900804
24
SCREW , Replaced By: A3029900204
25
NUT SHOCK ABSORBER TO CONSOLE AND TO CAB, UP TO CHASSIS 781743 EXCEPT FOR 500001-599999
26
SCREW FRONT WHEEL BRAKE TO STEERING KNUCKLE, 10/20 UP TO CHASSIS 796990, 50/60 UP TO CHASSIS 790758 EXCEPT FOR, 500001-599999 NOT FOR USE WITH 360 338 05 07, 360 338 05 08, 360 338 07 06, 360 338 08 05
27
NUT FRONT WHEEL BRAKE TO STEERING KNUCKLE, 10/20 UP TO CHASSIS 796990, 50/60 UP TO CHASSIS 790758 EXCEPT FOR, 500001-599999
29
BRAKE SHOE LESS LINING
30
BRAKE LINING (PARTS KIT) (BRAKE LINING 17.30 MM)
30
BRAKE LINING (PARTS KIT),REPAIR SIZE II (ASBESTOS-FREE BRAKE LINING) 17.30 MM
30
BRAKE LINING (PARTS KIT),REPAIR SIZE I (ASBESTOS-FREE BRAKE LINING) 16.30 MM
30
BRAKE LINING (PARTS KIT) (BRAKE LINING 15.30 MM)
30
BRAKE LINING (PARTS KIT) (BRAKE LINING 16.30 MM)
30
BRAKE LINING (PARTS KIT),STANDARD (ASBESTOS-FREE BRAKE LINING) 15.30 MM
31
RIVET BRAKE LINING 15 MM
32
REPAIR KIT BRAKE SHOE SHACKLE, UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
32
SHACKLE
32
REPAIR KIT , Replaced By: A3384200289
33
PIN SHACKLE TO BRAKE SHOE
34
LOCK RING TRANSMISSION CASE,TOP
35
PIN
36
SPACER WASHER
37
SPRING
38
LOCK , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
39
PIVOT PIN SHACKLE TO BRAKE SHOE
40
LOCK RING TRANSMISSION CASE,TOP
41
SPRING LONG
41
SPRING , Replaced By: A3524210192
42
SPRING SHORT
43
PIN
44
FILLER
45
SPRING , UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
45
SPRING
46
FILLER
47
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
48
NUT
999
CLAMP ,K 147121, Replaced By: N000000000319
999
SLEEVE LINE CONNECTION
999
FITTING LINE CONNECTION TO FIRE WALL,5 726664
999
HOLLOW SCREW HEATING CONNECTION
999
UNION NUT LINE CONNECTION
999
UNION NUT
999
COMBINATION BOLT ADJUSTING ECCENTRIC TO BRAKE ANCHOR PLATE
999
NUT , Replaced By: N910113014001
999
NUT , Replaced By: N910113010000
999
NUT , Replaced By: N913004008001
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004006001
999
NUT PUMP TO BRACKET
999
LOCK WASHERROCKINGER TYP 59 G140,59 G150
999
LOCK WASHER FITTING TO BRACKET
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK PULL TO FASTENER
999
LOCK , Replaced By: N912002008003
999
NUT BRACKET TO SIDE MEMBER
999
NUT SUPPORT TO SIDE MEMBER
999
NUT STRAP TO BRACKET
999
PULL ROD REAR AXLE SELF-LEVELLING DEVICE
999
SCREW FOR SPRING CLAMPS,5 484789
999
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
999
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
999
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
999
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW PIPE CLAMP
999
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
999
FITTING CONNECTION "2"
999
NUT CHECK VALVE TO AIR RESERVOIR
999
T-FITTING COMPRESSED AIR VALVE CONNECTION
999
ELBOW FITTING LINE CONNECTION
999
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
999
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
999
GREASE NIPPLE PROTECTIVE TUBE
999
INSULATING HOSE BLACK 10 MM, ORDER BY THE METER
999
SCREW LINE MOUNTING M 6X16
999
SHEET METAL SCREW LINE MOUNTING
999
SEAL RING LINE CONNECTION
999
SEAL RING VALVE TO VALVE,K 025179
999
SEAL RING FUEL LINE TO FEED PUMP
999
SEAL RING LINE CONNECTION
999
WASHER SPARE WHEEL CARRIER
999
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
999
WASHER , Replaced By: N007349013005
999
RIVET
999
TOOTHED WASHER HANDLE TO RATCHET ROD
999
GLAND LINE CONNECTION
999
TURNBUCKLE , Replaced By: A3859960034
999
GROOVED PIN , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
SCREW BEARING BRACKET TO FRAME
999
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
999
SCREW BRACKET TO LEFT SIDE MEMBER
999
SCREW , Replaced By: N308676012026
999
SCREW AT ENGINE MOUNTING,TO MOUNT LINES
999
SCREW , Replaced By: N308765012007
999
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
999
NUT , Replaced By: N308673016001
999
NUT , Replaced By: N308673012002
999
NUT STRAP TO SUPPORT,5 149419
999
NUT PULL ROD
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
NUT BALL PIVOT TO LEVER
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
SCREW BRACKET TO EXHAUST MUFFLER BRACKET
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW BRACKET TO BATTERY/APPARATUS SUPPORT
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: N304017008021
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
SCREW FRONT AXLE REGULATING SOLENOID VALVE
999
SCREW , Replaced By: N304017008039
999
SCREW BRACKET TO BELL HOUSING
999
SCREW STRAP TO BRACKET
999
SCREW SUPPORT WITH EDDY CURRENT BRAKE TO SUPPORT
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW , Replaced By: N000933008134
999
SCREW CONNECTOR
999
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
999
LOCK RING
999
LOCK RING SHACKLE TO BEARING BRACKET,965965
999
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
999
WASHER , Replaced By: N000433013010
999
WASHER VIBRATION ABSORBER TO BRACKET
999
WASHER , Replaced By: N000433010510
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER , Replaced By: N000125010532
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PINTO 345 431 70 16, USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
COTTER PIN STRAP TO CONSOLE
999
COTTER PIN CYLINDER TO BRACKET
999
COTTER PIN VIBRATION ABSORBER TO BRACKET,5 117575
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
SCREW PROTECTION PLATE TO BRACKET
999
SCREW LICENSE PLATE TO BRACKET,4 300861
999
SCREW ,374026
999
REPAIR KIT , Replaced By: A3954200041
999
REPAIR KIT BRAKE SHOE BEARING
999
ADHESIVE FOIL GUIDE SIGN
999
GROMMET LINE MOUNTING 19/13 MM
999
NUT FROM BRAKE SHAFT TO BRAKE LEVER
999
BRACKET , Replaced By: A3812711640
999
BRACKET DELIVERY AND SUCTION LINES
999
CLAMP LINE MOUNTING
999
NUT ,796991, 10/20, 790759, 50/60 360.0 UP TO IDENT NO. 4 337020, FROM IDENT NO. 4 337021,SEE MICROFICHE 103
999
T-FITTING AT DISTRIBUTOR,4 481288
999
REPAIR KIT , Replaced By: A3604200241
999
GUIDE SIGN , 752204
999
BRACKET , UP TO CHASSIS 721608 EXCEPTO FOR:500001-599999
999
BRACKET , 752204
999
ROD ,4 399152, 10/20, 4 416113, 50/60752205-4 478504, 002,003,012,013,022,023, 734560-4 478504, 010,011,014,015,021, Replaced By: N900331008426, +001A0004310867, +001N000934008010, +001N000934008035
999
ROD ,4 478504, Replaced By: N900331008426, +001A0004310667, +001A0004310867, +001N000934008010, +001N000934008035
999
CONSOLE
999
CLAMP , Replaced By: N916016008200
999
ANGLE LINE MOUNTING
999
LEVER
999
LEVER LEFT
999
LEVER RIGHT,2 068748
999
LEVER , Replaced By: A3604260711
999
LEVER , Replaced By: A3604260611
999
BRAKE LINING (PARTS KIT),REPAIR SIZE II (ASBESTOS-FREE BRAKE LINING) 17.70 MM
999
BRAKE LINING (PARTS KIT),REPAIR SIZE I (ASBESTOS-FREE BRAKE LINING) 16.70 MM
999
BRAKE CAMSHAFT , 10/20 FROM CHASSIS 981193,50/60 FROM CHASSIS 986145
999
BRAKE CAMSHAFT
999
STOP WASHER BRAKE SHAFT TO BEARING BRACKET
999
LOCK
999
BRAKE SHOE ,910369 EXCEPT FOR 501456-599999910370 ALSO INSTALLED ON 501456-599999, SEE SPARE PARTS LIST 731.3, Replaced By: A3024202019, +002A3604210810, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202019, +002A3604212510, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202019, +002A3604212410, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202119, +002A3604231510, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202119, +002A3604231410, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202119, +002A3604231310, +016A3079900197
