Поз.
Артикул
Описание
2
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
4
UNION NUT BUTT SCREW CONNECTION
6
GLAND LINE CONNECTION
8
THRUST RING BUTT SCREW CONNECTION
10
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
10
SEAL RING , Replaced By: N007603012121
12
HOSE , Replaced By: A0009872827
12
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
13
FITTING (PARTS KIT),LINE RUPTURE
14
BUSHING , Replaced By: N915062009000
14
SLEEVE LINE CONNECTION
16
SEAL CONE LINE CONNECTION
16
GLAND , Replaced By: A0019901967
18
UNION NUT LINE CONNECTION
18
UNION NUT LINE CONNECTION, Replaced By: N000000006239
20
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
20
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
21
FITTING (PARTS KIT),LINE RUPTURE
22
SLEEVE , Replaced By: N915062006000
22
SLEEVE LINE CONNECTION
24
GLAND LINE CONNECTION
26
UNION NUT LINE CONNECTION
27
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
28
T-FITTING DIAPHRAGM CYLINDER,CONNECTION: "11",5 272559
28
T-FITTING RIGHT SPRING LOAD ACCUMULATOR BRAKE CYLINDER,CONNECTION "1"
29
ELBOW FITTING DELIVERY LINE TO PUMP
29
ELBOW FITTING DELIVERY LINE TO PUMP
29
FITTING , Replaced By: A0019902771
34
T-FITTING 3/2-WAY VALVE, CONNECTIONS "P1,R2",4 307219
34
T-FITTING INSIDE AND OUTSIDE AIR RESERVOIRS, FRONT CONNECTION
34
T-FITTING INSIDE AND OUTSIDE AIR RESERVOIRS, FRONT CONNECTION
34
T-FITTING INSIDE AND OUTSIDE AIR RESERVOIRS, FRONT CONNECTION
36
T-FITTING CONNECTION: 12, 10/20 FROM CHASSIS 4 270414,50/60 FROM CHASSIS 4 270290
36
FITTING PRESSURE REGULATOR,CONNECTION "2.1",4 967998
36
T-FITTING , Replaced By: N074317000100
41
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
43
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
44
O-RING CHECK VALVE TO AIR RESERVOIR
46
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
46
THRUST RING CHECK VALVE TO AIR RESERVOIR
48
NUT CHECK VALVE TO AIR RESERVOIR
90
VALVE (OVERFLOW VALVE) GRAU
90
VALVE TRAILER BRAKE
90
VALVE (OVERFLOW VALVE) KNORR
90
VALVE (OVERFLOW VALVE) BOSCH
92
DIAPHRAGM
92
DIAPHRAGM
92
DIAPHRAGMTO 001 429 48 44
94
REPAIR KITBOSCH
96
SEAL RING LINE CONNECTION
98
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
98
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
99
O-RING CHECK VALVE TO AIR RESERVOIR
100
FITTING SHUTTLE VALVE
100
FITTING SHUTTLE VALVE
101
THRUST RING CHECK VALVE TO AIR RESERVOIR
101
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
102
NUT BRACKET TO SIDE MEMBER
102
NUT BRACKET TO SIDE MEMBER
103
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
104
BRACKET LINE CONNECTIONS
105
NUT CHECK VALVE TO AIR RESERVOIR
106
BRAKE VALVE , Replaced By: A0014313705
106
BRAKE VALVE , THE OLD PART MUST NO LONGER BE INSTALLED PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034313505
106
BRAKE VALVE , THE OLD PART MUST NO LONGER BE INSTALLED PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034313505
106
BRAKE VALVE TRAILER CONTROL VALVE BOSCH,4 375193 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
106
BRAKE VALVE TRAILER CONTROL VALVE BOSCH,4 375193 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
106
BRAKE VALVE TRAILER CONTROL VALVE WABCO,4 375193
106
BRAKE VALVE TRAILER CONTROL VALVE WABCO,4 375193
108
REPAIR KITTO 001 431 34 05,4 375193
108
REPAIR KITTO 001 431 48 05,4 375193
109
BRAKE VALVE SEAL RING TO 001 431 18 05,4 412020
110
REPAIR KIT VALVE KIT TO 001 431 37 05,4 375193
110
REPAIR KIT , Replaced By: A0024306581
110
REPAIR KITTO 001 431 37 05,4 375193
114
T-FITTING RELAY VALVE,CONNECTION: "20"
116
ELBOW FITTING TRAILER CONTROL VALVE,CONNECTION: 1.1
118
T-FITTING SHIFT VALVE,CONNECTION: "11", 415 5 014668 416 5 000515 417 4 972023
120
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
122
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
124
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
125
BRAKE VALVE SEAL RING TO 001 431 18 05,4 412020
126
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
128
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
128
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
130
FITTING RELAY VALVE,CONNECTION: "1,2"
130
FITTING DELIVERY LINE TO PUMP
130
FITTING DELIVERY LINE TO PUMP
132
FITTING , Replaced By: A0029979572
132
FITTING RELAY VALVE,CONNECTION: "40",5 359430
132
FITTING RELAY VALVE,CONNECTION: "40",5 359430
134
NUT , Replaced By: N913004008001
134
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
136
SPACER TUBE FRONT AXLE REGULATING SOLENOID VALVE
138
BRACKET TRAILER CONTROL VALVE
140
SCREW REINFORCEMENT TO ROCKER PANEL
142
NUT , Replaced By: N910113010000
142
NUT STRAP TO BRACKET
144
BRAKE LINE COUPLING SUPPLY, RED
144
BRAKE LINE COUPLING SUPPLY, RED
144
BRAKE LINE COUPLING SUPPLY, RED
144
BRAKE LINE COUPLING SUPPLY, RED
144
BRAKE LINE COUPLING BRAKE,YELLOW WESTINGHOUSE
144
BRAKE LINE COUPLING , Replaced By: A0004297830
144
BRAKE LINE COUPLING BRAKE,YELLOW BOSCH
144
BRAKE LINE COUPLING BRAKE,YELLOW KNORR
144
BRAKE LINE COUPLING BRAKE,YELLOW GRAU
146
SEAL RING , Replaced By: A0004296930
146
SEAL RINGTO 000 429 38 30
146
BRAKE LINE COUPLINGTO 000 429 38 30
148
COVERTO 000 429 51 30,4 434235
150
SEAL RING"WABCO"
152
GROOVED PINTO 000 429 51 30,4 434235
154
COVER SUPPLY, RED "WABCO"
154
COVERTO 000 429 49 30
154
COVER"WABCO", NOT USED
156
SEAL RING"WABCO"
156
SEAL RING"GRAU"
164
REPAIR KIT , TO 000 429 49 304 434235
164
REPAIR KITTO 000 429 63 30
164
REPAIR KIT"KNORR"
164
REPAIR KITTO 000 429 37 30
164
REPAIR KITTO 000 429 78 30,4 434236
166
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
166
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
168
FITTING SHUTTLE VALVE,CONNECTION: "20",5 727399
168
FITTING BRAKE LINE COUPLING TO BRACKET
170
NUT BRACKET TO SIDE MEMBER
172
WASHER BRACKET TO LEFT SIDE MEMBER
172
WASHER , Replaced By: A3609902340
172
WASHER , Replaced By: A3019900640
172
WASHER BEARING BRACKET TO SIDE MEMBER
172
WASHER BEARING BRACKET TO SIDE MEMBER
174
LOOM TIE , Replaced By: A0019978490
174
LOOM TIE LINE MOUNTING 280 MM
174
LOOM TIE , Replaced By: A0019978390
174
LOOM TIE LINE MOUNTING
999
FITTING ,4 667210
999
FITTING , Replaced By: A0029971372
999
FITTING , Replaced By: A0029971172
999
T-FITTING COMPRESSED AIR VALVE CONNECTION
999
WASHER HYDRAULIC HOSE TO BRACKET
999
T-FITTING ,5 936365, Replaced By: A0029902570
999
BRACKET COMPRESSED AIR LINE TO VALVE
999
BRACKET , Replaced By: A3854290840
999
CLAMP , Replaced By: A6739950001
999
BRACKET , Replaced By: A3853530440
999
BRACKET , Replaced By: A3604292940
999
BRACKET COMPRESSED AIR LINES TO FRAME
999
BRACKET , Replaced By: A3604292940
999
BRACKET COVERING
999
BRACKET , Replaced By: A3604292940
999
BRACKET LINE MOUNTING
999
FITTING , Replaced By: A0029906171
999
FITTING , Replaced By: A0029905971
999
SEAL RING
999
REPAIR KIT , Replaced By: A0004304606
999
VALVE , Replaced By: A0034295244
999
T-FITTING , Replaced By: A0019901070
999
BRAKE LINE COUPLING , Replaced By: A0004297930
999
SEAL RING , Replaced By: A0004292184
999
LINE , Replaced By: A0005516256
