Поз.
Артикул
Описание
8
LEVER
12
SCHALTHEBELKNOPF SCHWARZ. KNOB , 032,033,040,041,132,133,140,141 UP TO ENGINE 031699
12
BRACKET , 032,033,040,041,132,133,140,141 UP TO ENGINE 031699
16
PIN
21
SET SCREW , 032,033,040,041,132,133,140,141 UP TO ENGINE 031699
27
SPRING , 032,033,040,041,132,133,140,141 UP TO ENGINE 031699
32
WASHER , 032,033,040,041,132,133,140,141 UP TO ENGINE 031699
36
LOCK RING
41
CAP NUT , 032,033,040,041,132,133,140,141 UP TO ENGINE 031699
45
SPRING , 032,033,040,041,132,133,140,141 UP TO ENGINE 031699
49
SCREW , 032,033,040,041,132,133,140,141 UP TO ENGINE 031699
49
SCREW , 032,033,040,041,132,133,140,141 UP TO ENGINE 031699
54
ROD
59
BRACKET
63
LEVER
67
GUIDE TUBE
72
BRACKET
77
ROD
81
LEVER
85
BEARING
89
BUSHING
98
SCREW PLUG SOCKET TO FRAME
103
ROD
106
NUT
110
YOKE ACCELERATOR CONTROL
115
PIN
121
SCREW PLUG SOCKET TO FRAME
126
LOCK WASHER RAIL TO BATTERY SUPPORT
130
LEVER
134
BUSHING
138
WASHER
142
LOCK RING , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
146
GREASE NIPPLE PROTECTIVE TUBE
150
PIN
155
SPRING WASHER CABLE TO ALTERNATOR
160
COTTER PIN CLAMP TO BATTERY CASE,PB004444
164
ROD
168
NUT
172
YOKE ACCELERATOR CONTROL
176
NUT LEVER TO SHIFTING SHAFT
180
SPANNSCHLOSS. NUT
184
ROD
188
HEX. NUT. NUT FROM AIR SPRING VALVE TO REAR AXLE
192
PIN
196
SPRING WASHER CABLE TO ALTERNATOR
200
COTTER PIN CLAMP TO BATTERY CASE,PB004444
204
LEVER
208
BUSHING
212
BALL PIVOT , Replaced By: A3129910120
216
PULL ROD
220
NUT
226
BALL SOCKET AT CONTROL LEVER
238
CLAMPING PIECE
244
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
250
VALVE"WABCO DO BRASIL", USED WITH AIR BRAKE
250
VALVE"KNORR", USED WITH AIR BRAKE
250
VALVE , Replaced By: A3454347001
250
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 422115, Replaced By: A0004342301
253
REPAIR KIT , Replaced By: A0034301281
253
REPAIR KIT , Replaced By: A0004304106
253
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
253
REPAIR KIT SMALL SCOPE TO 345 434 71 01
253
REPAIR KIT LARGE SCOPE TO 000 434 30 01
253
REPAIR KIT SMALL SCOPE TO 000 434 30 01
256
ELBOW FITTING AT CYLINDER
256
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
262
SEAL RING
268
LINE FROM T-FITTING TO OPERATING VALVE 6X0.7 MM,13024439
274
UNION NUT
280
GLAND , Replaced By: A0019901667
286
LINE6X0.7 MM
292
LINE6X0.7 MM,13024439
298
LINE FROM CONNECTION FITTING I TO CONNECTION FITTING II 6X0.7 MM
298
LINE , Replaced By: A3214204926
304
LINE , Replaced By: A3214205026
304
LINE FROM CONNECTION FITTING II TO CONNECTION FITTING III 6X0.7 MM
310
LINE6X0.7 MM, UP TO CHASSIS 003351
316
LINE6X0.7 MM, UP TO CHASSIS 003351
999
NUT SUCTION LINE TO OIL PUMP
999
SECURING CLIP. CIRCLIP ACCELERATOR CONTROL
999
GREASE NIPPLE
999
CONNECTION FITTING , Replaced By: A0039979172
999
CLAMPING SLEEVEROCKINGER,TYP 59 U150
999
SCREW TIGHTENER PULLEY TO BRACKET ON ENGINE
999
NUT , Replaced By: N304032010002
999
NUT OIL COOLER TO BRACKET,TOP
999
NUT , Replaced By: N304032008006
999
SCREW COMPRESSED AIR ELBOW
999
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
999
LOCK WASHER , Replaced By: N912004010102
999
WASHER GROUND CABLE
999
999
999
GREASE NIPPLE
999
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
999
999
999
999
999
LINE6X0.7 MM, LENGHT AVAILABLE 6000 MM
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGTO 000 434 23 01
999
REPAIR KIT 3/2-WAY VALVE WABCO
999
HANDLETO 000 434 23 01
999
VALVE DISCTO 321 434 00 01,D 047018
999
CUP 3/2-WAY VALVE WABCO
999
SEAL RINGTO 321 434 00 01,D 047018
999
PROTECTIVE CAPTO 000 434 08 01,345 434 71 01
