Поз.
Артикул
Описание
651
TIRE INFLATOR CYLINDER
652
BALL
653
SPRING
654
SCREW PLUG
655
GUIDE SLEEVE
656
SEAL RING
657
FILTER ELEMENT
658
SNAP RINGWEBER,TO 000 553 40 01, UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
659
SCREW PLUG
660
SEAL RING
661
SPRING
662
VALVE DISC
663
PIN
664
SEAL RING
665
SNAP RING
666
SEAL RING
667
SCREW PLUG
668
AIR CLEANERGRAU, ON SPECIAL REQUEST
669
PRESSURE REGULATOR
670
SEAL RING
671
COMPENSATOR
672
SEAL RING
673
VALVE DISC
674
SCREW ,A 027954
675
LOCK WASHER CONTACT PLATE TO STEERING WHEEL
676
SPRING
677
BUSHING
678
SCREW PLUG
679
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
680
NUT
681
SCREW BRACKET TO CROSS CONNECTION STRUT
681
SCREW , Replaced By: N304017008034
682
STUD
684
NUT , Replaced By: N304032005005
684
NUT IN CASE OF SUBSEQUENT INSTALLATION
685
VALVE DISC
686
SPRING
687
SPRING
688
SEAL RING LINE TO OIL PUMP
689
SCREW PLUG
690
SPRING
691
PISTON
692
SEAL RING
693
WASHER
694
SCREW PLUG
695
STRAINER
696
SEAL RINGTO 000 431 77 14,KNORR
697
BREATHER PIPE
698
SCREW ,511032
699
PRESSURE REGULATOR WITH TIRE INFLATING CONNECTION
699
VALVE , FROM CHASSIS 023244, EXCEPT FOR, SEE FOOTNOTE 78, Replaced By: A0004318906
700
SLEEVE , Replaced By: A0007630553
700
SLEEVE
701
STRAINER
702
VALVE DISC
703
VALVE DISC ON TAPPED
704
PAD , FROM CHASSIS 023244, EXCEPT FOR, SEE FOOTNOTE 78
705
SCREW 3/2-WAY VALVE TO BRACKET M 8X105
706
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
708
ANTI-FREEZE DEVICE
708
ANTI-FREEZE DEVICE , Replaced By: A0004312615
709
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
710
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
711
SEALING CORD , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
712
SEALING CORD
713
SEAL RINGTO 001 431 37 05,4 375193
714
WICK , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
715
SEAL RING FUEL LINE TO FEED PUMP
716
SCREW PLUG
717
ANTI-FREEZE DEVICE AUFLEITUNG SIEHE /1-/10 WAHLWEISE MIT 000 431 08 15, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
718
CUP
719
VALVE DISCTO 000 429 48 30
720
BRAKE BOOSTER , Replaced By: A3444317014
721
CUPTO 000 431 21 14,BOSCH, WITH BOSCH CHARACTERISTIC NUMBER 724
722
SEAL RING
723
CUPBOSCH
724
VALVE DISCTO 000 429 48 30
725
VALVE DISCTO 000 429 48 30
726
SPRINGTO 000 429 16 30
727
SEAL RING OIL DRAIN 30X36 MM
728
YOKE , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
729
PIN
730
WASHER
731
HEADLESS SETSCREW
732
WASHER
733
AIR CLEANER
734
PROTECTIVE CAP BRAKE BOOSTER
735
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
736
SCREW BRACKET TO SIDE MEMBER
736
SCREW , Replaced By: N304017010002
737
BRACKET
738
BRACKET , 003795
740
PRESSURE SENDER UNIT , ON VEHICLES HAVING LOAD-DEPENDING BRAKE
741
PISTON , UP TO IDENT NO. 721608 EXCEPT FOR 500001-599999
742
VALVE PART
743
BRACKET PRESSURE SENDER UNIT, FOOTNOTE 67 FROM CHASSIS 017275
744
BRAKE PRESSURE REGULATOR , Replaced By: A0004314112
744
BRAKE PRESSURE REGULATOR , 752204
745
SEAL RING
746
CUP
747
SEAL RING , Replaced By: A0129975448
747
SEAL RING
748
BRACKET , ON VEHICLES HAVING LOAD-DEPENDING BRAKE
999
SCREW PLUG , Replaced By: A0004315433
999
SCREWED NIPPLE. FITTING , Replaced By: A0084230084
999
SCREW PLUG CONNECTION "1","2",4 478330
999
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
999
BRACKET. LOCK , Replaced By: A6525040038
999
BRAKE HOSE FRONT AXLE, FROM IDENT NO.: 001078 ALSO INSTALLED ON 000486,000532,000698,000721,000732,000737,000764,000794,000795,000798,000816,000823,000827,000828, 000833,000840,000847,000853,000865,000870,000884,000891,000901,000909,000944,000984,001032,001078, 001155,001156,001219,001363,001385,001427.
999
LINE FROM FITTING TO VALVE 6X1 MM, LENGTH AVAILABLE 3000 MM
999
PIN
999
VALVE TAPPETTO 000 429 30 44
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
VALVETO 000 429 30 44
999
VALVE CONEBOSCH
999
VERTEILERSTUCK. DISTRIBUTOR REAR AXLE,4 478330
999
VALVETO 000 429 00 47
999
SEAL RING IN CASE
999
SEAL RING
999
COVERTO 000 429 48 30
999
AIR CLEANER ,4 390315
999
COVERWABCO
999
SHUT-OFF COCK
999
BRAKE LINE COUPLING WITH SHUT-OFF VALVE
999
SPRINGTO 000 429 00 47
999
SPRINGTO 000 429 00 47
999
SPRINGTO 000 429 16 31,4 940458
999
SPRINGTO 000 429 16 31,4 940458
999
AIR CLEANER
999
SEAL RINGTO 000 429 16 31,4 940458
999
VALVE
999
DISTRIBUTOR REAR AXLE,4 478330
999
BRAKE LINE COUPLING AT REAR CROSS MENBER
999
VALVE
999
BRAKE LINE COUPLING AT REAR CROSS MENBER
999
BRAKE LINE COUPLING AT REAR CROSS MENBER
999
REPAIR KITKNORR
999
STRAINERTO 002 430 31 01
999
YOKE , Replaced By: A0004310467
999
CONNECTOR , FROM IDENT NO. 001338 EXCEPT FOR 0013438 0000014 2827078 000001-8 001702
999
CLAMP FLUID RESERVOIR
999
YOKE BOTTOM
999
ANTI-FREEZE DEVICE , Replaced By: A0004312615
999
TEST CONNECTION
999
TEST CONNECTION , Replaced By: A0004311231
999
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
999
ROD , Replaced By: N900331008281, +001A0004310867, +001N000934008035
999
VALVE. PRESSURE REGULATOR ,FB486597
999
FILLER CAP , Replaced By: A0004315533
999
FILLER CAP , Replaced By: A0004315133
999
STRAINER , Replaced By: A0004314334
999
VALVE , Replaced By: A0004319106
999
STRAINER
999
WASHER ANTI-FREEZE DEVICE DRAIN
999
PROTECTIVE CAP , Replaced By: A0009979486
999
CUP , 010506, Replaced By: A0059974746
999
FILLER CAP , Replaced By: A0004315433
999
FILLER CAP BUTTRESS THREAD
999
FILLER CAPTO 000 431 87 02
999
PROTECTIVE CAP
999
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
999
PROTECTIVE CAPWEST 432 199 015 0,030 0
999
RESERVOIR
999
PRESSURE REGULATORBOSCH,4 208907 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE , Replaced By: A0004320807, +001N900397000201
999
VALVE DRAIN, Replaced By: A0004322407
999
VALVE. DRAIN VALVE DRAIN
999
VALVE DRAIN, Replaced By: A0004322107
999
SPRING CAPSULETO 000 429 16 30
999
VALVE TAPPETTO 000 429 16 30
999
GASKETTO 000 429 16 30
999
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
999
TUBE FEED AND RETURN LINES TO OIL COOLER, LENGTH AVAILABLE 3000 MM
999
REPAIR KITTO 002 430 61 01
999
REPAIR KITTO 002 430 41 01
999
REPAIR KITTEVES
999
REPAIR KIT
999
REPAIR KIT
999
REPAIR KITTO 000 429 14 31,5 116581
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
WICK PARTS KIT TO 000 431 26 15,WEST 432 199 030 0
999
CLAMP BRACKET TO AIR COMPRESSOR
999
PIPE CONNECTION NUT. FITTING ,613554
999
GROMMET
999
GROMMET
999
GROMMET CAB ROOF
999
HANDLETO 000 429 16 31,4 940458
999
SEAL RING
999
PLUG
999
VALVE
999
SEAL RINGTO 000 429 16 30
999
REPAIR KITWEST 432 199 015 0,432 199 030 0
999
REPAIR KIT , UP TO 625
999
REPAIR KITTO 000 431 91 06,BOSCH 0 481 039 011, UP TO BOSCH N 625
999
REPAIR KITWABCO
999
REPAIR KIT , FROM 626
999
RESERVOIR COMPRESSED AIR 60 L.
999
SEAL RING42X21.5 MM
999
SEAL RING
999
SEAL RINGTO 000 429 16 30
