Поз.
Артикул
Описание
55
70
VALVE"WABCO DO BRASIL"
70
VALVE"WESTINGHOUSE"
70
VALVE , Replaced By: A0004342401
70
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH, OPTIONAL WITH 000 434 08 01
71
HANDLETO 000 434 24 01
72
CUP 3/2-WAY VALVE WABCO
72
PROTECTIVE CAPTO 000 434 08 01,345 434 71 01
73
SEAL RINGTO 000 434 23 01
74
REPAIR KIT 3/2-WAY VALVE WABCO
74
REPAIR KIT , Replaced By: A0034301281
74
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
74
REPAIR KIT SMALL SCOPE TO 345 434 71 01
74
REPAIR KIT , NOT USED
75
SEAL RING LINE CONNECTION
80
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
85
SPRING WASHER OPERATING VALVE TO SIDE MEMBER SHELL
90
PROTECTIVE PLATE OPERATING VALVE TO SIDE MEMBER SHELL
95
NUT , Replaced By: N080705026003
100
102
GLAND , Replaced By: A0019901667
103
UNION NUT
105
CONNECTION FITTING , Replaced By: A0039979172
110
111
GLAND , Replaced By: A0019901667
112
UNION NUT
115
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
120
SEAL RING LINE CONNECTION
125
CLAMP ,K 147121, Replaced By: N000000000319
125
CLAMP , Replaced By: N916016008200
130
CLAMP BRAKE LINE TO SIDE AND CROSS MEMBERS
135
PLATE
136
SCREW CONTACTOR
137
LOCK WASHER LINE MOUNTING
138
HEX. NUT M 5 DIN 934-5 S. NUT PLUG SOCKET TO FRAME
999
DIAPHRAGM , Replaced By: A0004290745
