Поз.
Артикул
Описание
5
TURBOCHARGER ,601414
5
TURBOCHARGER ,601415
5
TURBOCHARGER ,601414
5
TURBOCHARGER ,601415
8
STUD BOLT CONTROL BLOCK M 10X35
8
STUD BOLT P.T.O. TO TRANSMISSION
8
BOLT. STUD THROTTLE HOUSING TO EXHAUST GAS TURBOCHARGER
11
GASKET
11
GASKET CONNECTOR TO EXHAUST MANIFOLD
14
LOCK WASHER , Replaced By: N912004010102
17
NUT , Replaced By: A0009903150
17
NUT
17
NUT CONNECTING PIPE TO EXHAUST BRAKE
17
NUT END PIECE TO EXHAUST PIPE
41
ELBOW (CHARGING AIR ELBOW),601414
41
ELBOW , Replaced By: A3450980315
53
GASKET PIPE ELBOW TO INTAKE MANIFOLD
56
SCREW , Replaced By: N304017010002
59
SPRING WASHERTO 000 268 46 01
68
CONNECTING PIPE
71
SEAL RING TURBOCHARGER TO PIPE ELBOW
83
HOSE PIPE ELBOW TO AIR INTAKE PIPE
83
HOSE CHARGING AIR ELBOW TO TURBOCHARGER,601414
83
HOSE , Replaced By: A3459979082
86
LOOM TIE , Replaced By: A3459978390
86
CLAMP , Replaced By: A3459978390
86
LOOM TIE CHARGING AIR ELBOW TO PIPE ELBOW,601414
86
LOOM TIE AIR INTAKE PIPE
116
SCREENING PLATE
119
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
122
WASHER , Replaced By: N009021006208
125
SCREW BRACKET TO DISC WHEEL M 8X16,D 315831
128
LOCK WASHER RAIL TO BATTERY SUPPORT
131
WASHER TRAILER PLUG SOCKET TO BRACKET
134
GASKET , Replaced By: A4271440180
137
NUT END PIECE TO EXHAUST PIPE
137
NUT , Replaced By: A0009903150
137
NUT CONNECTING PIPE TO EXHAUST BRAKE
140
STUD BOLT , Replaced By: N000939010138
140
STUD BOLT BELL HOUSING, FROM IDENT NO. 760272 ALSO INSTALLED ON 500001-599999 10/20 UP TO IDENT NO. 922885 EXCEPT FOR 502153,502155,502162,502192-502195,502198-502204,502207-599999,918576,921744,921785,921797,922052, 922078,922195,922255,922267,922336,922675,922688,922719,922739,922763,922853. ALSO INSTALLED ON 934036,934433,934539,935068,935169,937098. 50/60 UP TO IDENT NO. 922468 ON 96 KW (130 PS/DIN) 50/60 UP TO IDENT NO. 923153 ON 124 KW (168 PS/DIN)
140
STUD EXHAUST MANIFOLD TO CYLINDER HEAD M 10X40
140
STUD BOLT EXHAUST MANIFOLD TO CYLINDER HEAD M 10X25
999
PLATE FOR COMPRESSOR HOUSING TO 345 096 77 99
999
PLATE FOR TURBINE HOUSING TO 345 096 77 99, 002 096 71 99
