Поз.
Артикул
Описание
8
PIPE
22
HOSE
29
CLAMP , Replaced By: A0009971690
29
LOOM TIE , Replaced By: N916017040000
36
CLAMP TO A0059972882
57
HOSE80 MM, OM 326,L UP TO CHASSIS 004265,LP UP TO CHASSIS 001437 ORDER BY THE METER
64
CLAMP
85
PIPE SOCKET COOLING WATER OUTLET
92
PIPE SOCKET
99
GASKET PIPE SOCKET TO CYLINDER HEAD, UP TO IDENT NO.5 448662, FROM IDENT NO. 5 448663 SEE UNIT MICROFICHE
99
GASKET , Replaced By: A3662030380
99
GASKET HEATING PIPE TO ENGINE
106
LOCK WASHERTO 001 154 49 02, 000 154 80 01
113
SCREW
113
SCREW , Replaced By: N000000000190
120
MOLDED PIECE
125
CLAMP
130
PIPE SOCKET WATER INTAKE
137
PIPE SOCKET WATER INTAKE
144
GASKET
151
NUT
151
NUT , Replaced By: N304032008006
158
SEAL RING FUEL LINE TO FEED PUMP
165
SCREW PLUG
172
GASKET COVER TO EXHAUST MANIFOLD
172
GASKET COVER TO EXHAUST MANIFOLD
179
OUTLET COOLING WATER OUTLET
186
LOCK WASHER
193
NUT
193
NUT , Replaced By: N304032008006
200
SEAL RING FUEL LINE TO FEED PUMP
207
SEAL RING VALVE TO VALVE,K 025179
214
SCREW PLUG FUEL TANK
214
SCREW PLUG , Replaced By: N007604014110
221
SCREW PLUG
228
HOSE
235
CLAMP
242
GASKET , Replaced By: A3522032680
242
GASKET , Replaced By: A3522032480
242
GASKET DE-AERATION LINE TO HEATING LINE
249
INTAKE PIPE SOCKET COOLING WATER INLET
256
LOCK WASHERTO 001 154 49 02, 000 154 80 01
263
HEXALOBULAR BOLT. SCREWM 8X45
263
SCREW , Replaced By: N000000001448
263
SCREW , Replaced By: N000912008072
270
SCREW PIPE SOCKET TO THERMOSTAT M 8X65
319
FITTING AT INJECTION PUMP
326
THERMOSTAT ELEMENT , Replaced By: A0032032875, +001A3522032280
333
COVER THERMOSTAT
342
SEAL RING LINE CONNECTION
342
SEAL RING , Replaced By: N007603012111
349
SCREW FITTING
356
GASKET1 MM
356
GASKET , Replaced By: A3522032380
363
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
363
HOSE , Replaced By: A0089979082, +002A0019977672, +002N915001006000
370
FITTING AT INJECTION PUMP
999
CLAMP LINE MOUNTING
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
CLAMP COOLING WATER LINE TO WATER PUMP
999
CLAMP , Replaced By: A0009971690
999
CLAMP TO A0009971583
999
CLAMP
999
CLAMP
999
CLAMP TO A0009971583
999
CLAMP
999
CLAMP BREATHER LINE TO FUEL TANK
999
HOSE , ORDER BY THE METER
999
HOSE FROM EXPANSION TANK TO RADIATOR
999
SCREW PLUG , Replaced By: N007604014110
999
NUT BALL PIVOT TO LEVER
999
SCREW FRONT AXLE REGULATING SOLENOID VALVE
999
SCREW COVER PLATE TO BRACKET
999
SCREW CLUTCH TO FLYWHEEL
999
SCREW , Replaced By: N000933008134
999
SCREW
999
HOSE COOLING WATER LINES
999
HOSE FROM THERMOSTAT TO RADIATOR
999
CLAMP , Replaced By: N916016022201
999
SCREW PLUG , Replaced By: A0529970130
999
LINE
999
SPACER TUBE , Replaced By: A3520320251
999
BRACKET
999
FLANGE
999
LINE
999
PIPE SOCKET COOLING WATER INLET
999
PIPE SOCKET , Replaced By: A0522000356
999
PIPE SOCKET
999
PIPE SOCKET , Replaced By: A0522000156
999
LINE
999
HOSE , Replaced By: A3405010382
999
SLEEVE
