Поз.
Артикул
Описание
172
FRONT PANEL , 715566
177
BRACING RIGHT, 715566
177
BRACING LEFT, 715566
180
BAFFLE PLATE , 715566
183
CHAIN , UP TO IDENT NO.715566 EXCEPT FOR:500001-599999
186
FASTENER FRONT PANEL,RIGHT, UP TO IDENT NO.715566 EXCEPT FOR:500001-599999
186
FASTENER FRONT PANEL,LEFT, UP TO IDENT NO.715566 EXCEPT FOR:500001-599999
190
SIDE PANEL RIGHT, 715566
190
SIDE PANEL LEFT, 715566
199
HINGE PLATE WITH LOCKING PIN,RIGHT, 715566
199
HINGE PLATE WITH LOCKING PIN,LEFT, 715566
203
HINGE PLATE WITH LOCKING PIN,LEFT AND RIGHT, 715566
207
HOOK , UP TO IDENT NO.715566 EXCEPT FOR:500001-599999
210
BRACKET TENSION CHAIN, 715566
212
CHAIN , UP TO IDENT NO.715566 EXCEPT FOR:500001-599999
214
FASTENER TENSION CHAIN, 715566
217
FASTENER RIGHT, UP TO IDENT NO.715566 EXCEPT FOR:500001-599999
217
FASTENER LEFT, UP TO IDENT NO.715566 EXCEPT FOR:500001-599999
220
HOOK , Replaced By: A3586600584
220
HOOK , Replaced By: A3586600484
223
PIN FASTENER, UP TO IDENT NO.715566 EXCEPT FOR:500001-599999
225
SPRING WASHER BELL HOUSING WITH TRANSMISSION TO INTERMEDIATE FLANGE
228
REAR PANEL , 715566
999
SCREW FASTENER TO SIDE PANEL M 8X40, UP TO IDENT NO.715566 EXCEPT FOR:500001-599999
999
WASHER DUMPER AUXILIARY FRAME TO CHASSIS, FROM DUMPER SUPORT TO PRESS SUPPORT
999
INSTRUCTION PLATE FOR OPERATION IN TILTED POSITION, UP TO IDENT NO.715566 EXCEPT FOR:500001-599999
999
WASHER , Replaced By: A1403521376
999
SPACER TUBE , Replaced By: A3833160053
999
FIXTURE , Replaced By: A3528900110
999
WASHER , Replaced By: A3149900940
999
FRAME (BINDING RAIL), 715566
999
SPACER TUBE AUXILIARY FRAME TO CHASSIS, WITH COMPLETE VEHICLES
999
SCREWM 5X16
999
COTTER PINROCKINGER TYP 260 G140
999
WASHER HIGH PRESSURE HOSE TO BRACKET
999
SCREW COVERING
999
SCREW , 032,033,040,041,132,133,140,141 UP TO ENGINE 031699
999
SCREW PLATFORM MOUNTING M 8X35
999
SCREW BRACKET TO BODY M8X40
999
SCREW FIXTURE TO PLATFORM M8X45
999
SCREW AT SIDE MEMBER
999
SCREW BINDING RAIL TO PLATFORM SIDE PANEL, UP TO CHASSIS 715566 ALSO INSTALLED ON,500001-599999
999
SCREW , Replaced By: A0009841229
999
SCREW HOOK TO PLATFORM SIDE PANEL M 8X45, UP TO CHASSIS 715566 ALSO INSTALLED ON,500001-599999
999
SCREW VALVE TO BRACKET
999
SCREWM 8X40
999
SCREW BRACKET TO FRAME
999
SCREW , Replaced By: N304017008021
999
NUT BALL PIVOT TO LEVER
999
WIRE NAIL TO MOUNT INSTRUCTION PLATE, UP TO IDENT NO.715566 EXCEPT FOR:500001-599999
999
PIN RETAINING ROPE TO PLATFORM
999
PIN SIDE PANEL TO SUBSTRUCTURE, 715566
999
DISC SPRING DUMPING PLATFORM MOUNTING
999
SCREW PIPE CLAMP
999
NUT
999
NUT END PIECE TO EXHAUST PIPE
