Поз.
Артикул
Описание
5
RESERVOIR WATER SEPARATOR
8
RESERVOIR COMPRESSED AIR 10 L.
8
RESERVOIR , Replaced By: A0034320801
8
RESERVOIR COMPRESSED AIR 10 L.
8
RESERVOIR E P S AND CLUTCH BOOSTER 10 L, Replaced By: A0034320801
8
RESERVOIR STEEL 20L, D246MM
8
RESERVOIR STEEL 20L, D246MM
8
RESERVOIR STEEL 20L, D246MM
8
RESERVOIR STEEL 20L, D246MM
8
RESERVOIR , Replaced By: A0034321201
8
RESERVOIR STEEL 20L, D246MM
8
RESERVOIR STEEL 20L, D246MM
8
RESERVOIR STEEL 20L, D246MM
8
RESERVOIR STEEL 20L, D246MM
8
RESERVOIR COMPRESSED AIR,5 295503
8
RESERVOIR , Replaced By: A0034321201
8
RESERVOIR , Replaced By: A0004323401
11
RESERVOIR6 L
11
RESERVOIR , Replaced By: A0034320701
11
RESERVOIR ,070219, Replaced By: A0034320701
14
BRACKET AIR RESERVOIR 6 L
17
BRACKET AIR RESERVOIR 6 L
20
SCREW BRACKET TO SIDE MEMBER
23
NUT STRAP TO BRACKET
23
NUT , Replaced By: N910113010000
26
SCREW BRACKET TO RIGHT SIDE MEMBER,5 434014
26
SCREW , Replaced By: N304017008067
29
WASHER BRACKET TO LEFT SIDE MEMBER
29
WASHER , Replaced By: N009021008213
32
NUT , Replaced By: N913004008001
35
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
38
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
41
SCREW RESERVOIR TO BRACKET M 22X1.5X50
44
FITTING LINE CONNECTION
47
ELBOW FITTING TWO-WAY VALVE,CONNECTION "1.2"
50
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
53
SCREW. UNION SCREW LINE CONNECTION
56
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
59
O-RING CHECK VALVE TO AIR RESERVOIR
62
NUT CHECK VALVE TO AIR RESERVOIR
65
VALVE AUTOMATIC DRAIN
68
VALVE DRAIN, Replaced By: A0004322107
68
VALVE. DRAIN VALVE DRAIN
68
VALVE DRAIN, Replaced By: A0004322407
71
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
74
O-RING CHECK VALVE TO AIR RESERVOIR
77
SEAL RING LINE CONNECTION
999
VALVE (DRAIN VALVE) HALDEX
999
REPAIR KIT (DRAIN VALVE)
