Поз.
Артикул
Описание
8
FUEL TANK , 042 002002 043 012556 044 034421, Replaced By: A1074704201, +002A1074700133
8
FUEL TANK , Replaced By: A1074704501
8
FUEL TANK85L., 042 002002 043 012556 044 034421
11
GASKET , Replaced By: A1074712080
11
GASKET
14
GASKET , Replaced By: A1074712180
14
GASKET
23
GAUGE SENDER UNIT
35
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
41
FUEL STRAINER
44
SEAL RING
53
GROMMET , Replaced By: A1239973581
53
GROMMET FILLER NECK THRU FENDER RECESS
56
REINFORCEMENT FUEL TANK TO CONSOLE
62
SCREW , Replaced By: N304017008034
65
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
68
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
74
LOCKING CAP
77
FILLER CAP , Replaced By: A0004700730
83
SEAL RING
86
EXPANSION TANK , 043 003443 EXCEPT FOR 003852-003894
89
LOCK. CLIP FASTENER HOUSING UPPER PART TO LOWER PART
92
SHEET METAL SCREW WINDOW SILL GIRDER LOWER PART,4 273689
92
SHEET METAL SCREW RESERVOIR TO PARTITION PANEL
95
WASHER , Replaced By: N009021005205
95
WASHER , Replaced By: N009021005205
95
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
98
HOSE , ORDER BY THE METER
101
CLAMP CHECK VALVE,K 169122
