Поз.
Артикул
Описание
258
LINE , Replaced By: A3524209529
260
LINE BETWEEN RESERVOIR AND BRAKE MASTER CYLINDER
262
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
264
LINE385 MM,680031
266
LINE385 MM,680031
268
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
272
CLAMP
274
BRACKET FUEL LINE
274
BRACKET FUEL LINES
274
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
276
LINE FROM MASTER CYLINDER TO FRONT AXLE TEST CONNECTION 900 MM
278
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL 1700 MM,4 478329
280
HOSE
282
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
284
ANGLE LINE MOUNTING
285
BRACKET LINE MOUNTING
289
SCREW PROTECTION PLATE TO BRACKET
292
BRAKE HOSE AT REAR AXLE
294
BRACKET. LOCK , Replaced By: A6525040038
294
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
296
BRACKET BRAKE HOSE,REAR
302
CONNECTOR OIL DELIVERY LINE
306
BRACKET , Replaced By: A3184280240
306
BRACKET LINE MOUNTING
306
BRACKET BRAKE LINE MOUNTING
307
SCREW , Replaced By: N304017008021
307
SCREW PIPE CLAMP
309
SCREW PROTECTION PLATE TO BRACKET
312
BRACKET BRACKET TO RIGHT SIDE MEMBER
314
VERTEILERSTUCK. DISTRIBUTOR REAR AXLE,4 478330
314
DISTRIBUTOR REAR AXLE,4 478330
316
SCREW , Replaced By: N304017008027
316
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
318
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
320
LINE FROM TEST CONNECTION TO LEFT WHEEL CYLINDER 1350 MM,4 644237
322
CLAMP BRAKE LINE MOUNTING
324
HOSE BRAKE LINE TO REAR AXLE,4 644238
326
SCREW , Replaced By: N304017008016
326
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
327
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
329
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 650 MM
999
CLAMP ,K 147121, Replaced By: N000000000319
999
FITTING LINE CONNECTION TO FIRE WALL,5 726664
999
UNION NUT
999
NUT , Replaced By: N910113014001
999
NUT , Replaced By: N913004006001
999
NUT PUMP TO BRACKET
999
LOCK WASHER FITTING TO BRACKET
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER BRACKET TO STEERING COLUMN END
999
LOCK WASHER T-FITTING TO BRACKET
999
NUT BRACKET TO SIDE MEMBER
999
CLAMP LINE MOUNTING,4 257007
999
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
999
HEXAGON HEAD BOLT. SCREW BRACKET TO CROSS MEMBER
999
NUT BRACKET TO SIDE MEMBER,K 035196
999
NUT
999
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
999
SCREW BRACKET TO SIDE MEMBER
999
FITTING CONNECTION "2"
999
NUT CHECK VALVE TO AIR RESERVOIR
999
ELBOW FITTING LINE CONNECTION
999
AIR RESERVOIR OUTSIDE, 674067
999
SNAP RING
999
GREASE NIPPLE PROTECTIVE TUBE
999
INSULATING HOSE BLACK 10 MM, ORDER BY THE METER
999
SCREW BUSHING AND LEVER TO CAB
999
SHEET METAL SCREW , Replaced By: N000000000459
999
SHEET METAL SCREW , Replaced By: N007981004339
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SEAL RING LINE CONNECTION
999
WASHER CONSOLE TO FRAME
999
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
999
WASHER , Replaced By: N007349013005
999
RIVET
999
TOOTHED WASHER HANDLE TO RATCHET ROD
999
GROOVED PIN AT BEARING BRACKET
999
GROOVED PIN
999
PIN STRAP TO CONSOLE
999
PIN , Replaced By: N001434010009
999
FITTED WASHER DOUBLE LEVER TO CONSOLE, 698032
999
SCREW BRACKET TO CAB CONSOLE,K 035197
999
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
999
SCREW BRACKET TO FRAME
999
SCREW CONSOLE TO SIDE MEMBER
999
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
999
SCREW , Replaced By: N308676012026
999
NUT BRAKE LINE MOUNTING
999
NUT , Replaced By: N308673014001
999
NUT STRAP TO SUPPORT
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
NUT BALL PIVOT TO LEVER
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
SCREW , Replaced By: N304017010028
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW SUPPORT TO CROSS MEMBER M 10X28
999
SCREW , Replaced By: N304017010002
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW BRACKET TO BATTERY/APPARATUS SUPPORT
999
SCREW STRAP TO BRACKET
999
SCREW BRACKET TO FRAME SIDE MEMBER
999
RIVET
999
LOCK RINGTO 345 431 71 05
999
LOCK RING
999
LOCK RING , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
WIRE120 MM, UP TO IDENT NO. 4 477510 FROM IDENT NO. SEE UNIT MICROFICHE MODEL 750.5 ORDER BY THE METER
999
LOCK WASHER BRACKET TO SIDE MEMBER,929799
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER , Replaced By: N000125010532
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PIN STRAP TO CONSOLE
999
COTTER PIN CYLINDER TO BRACKET
999
COTTER PIN VIBRATION ABSORBER TO BRACKET,5 117575
999
COTTER PIN
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
COTTER PIN
999
SCREW , UP TO IDENT NO. 674067 EXCEPT FOR 500001-599999, 673432, 673497, 673628,673629,673921
999
SCREW LICENSE PLATE TO BRACKET M 6X18,4 707518
999
SCREW BRAKE LINE MOUNTING
999
SCREW CLAMP MOUNTING
999
SCREW ,374026
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
SHEET METAL SCREW FUEL STRAINER SCREEN TO FUEL TANK
999
GROMMET LINE MOUNTING 19/13 MM
999
BRACKET , Replaced By: A3812711640
999
GROMMET TEMPERATURE GAUGE SENDER UNIT
999
BRACKET DELIVERY AND SUCTION LINES
999
CLAMP FEED LINE TO THERMOSTAT
999
WASHER WATER SEPARATOR
999
WASHER BRACKET TO SIDE MEMBER
999
CONSOLE
999
CONSOLE , Replaced By: A3164300111
999
CLAMP , Replaced By: N916016008200
999
LEVER RIGHT,2 068748
999
LEVER , Replaced By: A3604260711
999
LEVER , Replaced By: A3604260611
999
BRAKE INTERMEDIATE SHAFT , FROM CHASSIS 734560 ALSO INSTALLED ON, 500001-599999
999
LEVER AT BRACKET, 674067
999
BEARING BRACKET
999
BRAKE INTERMEDIATE SHAFT , 674067
999
BRAKE LEVER
999
BRAKE LEVER , 715475
999
BRAKE ANCHOR PLATE RIGHT, UP TO CHASSIS 910369 ALSO INSTALLED ON 500000-501414 FROM CHASSIS 501456-599999 AND FROM CHASSIS 910370 SEE UNIT MICROFICHE 744.300
999
BEARING BRACKET BRAKE CABLE, 674067
999
RATCHET ROD
999
BRAKE ANCHOR PLATE , Replaced By: A3584200917
999
BEARING BRACKET , Replaced By: A3584201078
999
BRAKE ANCHOR PLATE , Replaced By: A3584200517
999
BRAKE ANCHOR PLATE , Replaced By: A3584200417
999
SCREW , Replaced By: N900170012019, +001N913001012000
999
SCREW , Replaced By: A3029900804
999
REPAIR KIT , Replaced By: A3124201178
999
SPRING , Replaced By: A3609930210
999
ELECTRIC CABLE , Replaced By: A0089976082, +002A0019973472, +002A0019975072, +001N040621010200, +002N915001004003
999
BRACKET BRAKE MASTER CYLINDER
999
PIN , UP TO CHASSIS 698032 EXCEPT 500001-599999
999
RESERVOIR FRONT AXLE, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
999
LEVER
999
LEVER , Replaced By: A3524301423
999
CONSOLE , 698032
999
LEVER , Replaced By: A3524301323
999
CONSOLE , 698032
999
PIN
999
PAWL ROD , Replaced By: A3524200288
999
BRACKET INTERMEDIATE LEVER
999
PAWL ROD , 602848
999
STOP , 000134
999
LEVER , Replaced By: A3604260711
999
LEVER , Replaced By: A3604260611
999
LINE , Replaced By: A3404201529
999
BRAKE LEVER
999
ROD , Replaced By: A3604200474, +001A3534200074, +001A3859900551, +001A3859960034, +001N000934012002
999
BRAKE INTERMEDIATE SHAFT , 670068-734559
999
BRAKE LEVER , 602849 UP TO CHASSIS 600703 RANGE OF DELIVERY INCLUDES: 1X352 427 08 41
999
BRAKE INTERMEDIATE SHAFT REAR
999
BRAKE LEVER , 602848, Replaced By: A3524201212, +001A3524200288
999
LEVER
999
BEARING BRACKET , 600704
999
RATCHET ROD , 602849
999
BRAKE INTERMEDIATE SHAFT , Replaced By: A3524201080
999
BRAKE CABLE
999
BRACKET
999
REPAIR KIT , Replaced By: A3585860242
999
PROTECTIVE PLATE WHEEL CYLINDER, 003861
999
BRAKE SHOE , Replaced By: A3414200319
999
BRAKE SHOE , Replaced By: A3414200319
999
BRAKE SHOE , Replaced By: A3414200319
999
SCREW FRONT WHEEL BRAKE TO STEERING KNUCKLE, 10/20 UP TO CHASSIS 796990, 50/60 UP TO CHASSIS 790758 EXCEPT FOR, 500001-599999 NOT FOR USE WITH 360 338 05 07, 360 338 05 08, 360 338 07 06, 360 338 08 05
999
PIN
999
LINE FROM DISTRIBUTOR TO CONTROL VALVE
999
LINE FROM DISTRIBUTOR TO VALVE 4800 MM
999
LINE FROM DISTRIBUTOR TO VALVE 3200 MM
999
LINE FROM MASTER CYLINDER TO BRAKE PRESSURE REGULATOR, 734559
999
LINE FROM CONNECTOR TO BRAKE HOSE AT REAR AXLE 800 MM,4 478330
999
BEARING BRACKET INTERMEDIATE LEVER TO BEARING BRACKET
999
REPAIR KIT , Replaced By: A3384200289
