Поз.
Артикул
Описание
7
BEARING BRACKET ,D 047018
10
BEARING
12
BUSHING , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3529920701
17
GREASE NIPPLE
22
SCREW PLUG SOCKET TO FRAME
27
LOCK WASHER RAIL TO BATTERY SUPPORT
32
NUT LEVER TO SHIFTING SHAFT
37
SCREW , Replaced By: N304017010040
47
LOCK WASHER , Replaced By: N912004010102
52
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
57
PEDAL CLUTCH
62
PEDAL BRAKE
62
PEDAL , EXHAUST STOCK OF OLD PARTS UP TO CHASSIS, Replaced By: A3642907518
67
BUSHING
72
GREASE NIPPLE PROTECTIVE TUBE
73
ROD PISTON ROD
74
YOKE PISTON ROD
75
NUT FUEL TANK TO SUPPORT
76
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
77
PEDAL CLUTCH
77
PEDAL PLATE , Replaced By: A3642907216
80
PEDAL PLATE
82
SEAL WASHER BRAKE PEDAL
87
PAD BRAKE AND CLUTCH LEVERS
87
PAD BRAKE AND CLUTCH LEVERS
92
SCREW , Replaced By: N304017010040
97
LOCK RING SHACKLE TO CONSOLE TO 393 326 00 63,965965
102
FITTED WASHER ACCELERATOR PEDAL
107
PIN TRUCK-TRACTOR BRAKE VALVE
110
COTTER PIN
117
SPRING CLUTCH PEDAL
117
SPRING , Replaced By: A3649937310
122
SPRING
124
BRACKET
127
LEVER CLUTCH
132
SCREW COLD START SYSTEM TO BRACKET
137
NUT LEVER TO SHIFTING SHAFT
142
PULL ROD CLUTCH LINKAGE
147
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
152
YOKE PULL ROD TO LEVER
152
YOKE , Replaced By: A0009961501
157
PIN INTERMEDIATE LEVER I
167
SCREW PLUG SOCKET TO FRAME
172
LOCK WASHER RAIL TO BATTERY SUPPORT
177
NUT LEVER TO SHIFTING SHAFT
182
LEVER
187
BUSHING MANUAL CONTROL,D 249954
192
WASHER PEDAL BEARING
197
LOCK RING BELT TIGHTENER
202
GREASE NIPPLE
207
PIN , Replaced By: N000000000056
212
SPRING WASHER. LOCK RING SHIFTING ROD TO BRACKET
217
WASHER 10,5 DIN 433. WASHER , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
219
COTTER PIN
278
BRACKET PULL ROD GUIDE
280
GROMMET
281
SCREW SUPPORT TO SIDE MEMBER M 12X1.5X35
337
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
352
YOKE PULL ROD TO LEVER
352
YOKE , Replaced By: A0009961501
357
PIN , Replaced By: N000000000056
362
SPRING WASHER. LOCK RING SHIFTING ROD TO BRACKET
367
WASHER 10,5 DIN 433. WASHER , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
370
COTTER PIN
999
BALL SOCKET FROM INTERMEDIATE LEVER II TO CLUTCH ACTUATION LEVER,793543
999
PAD BRAKE PEDAL
999
WASHER PEDAL TO PEDAL LEVER
999
SNAP RING FROM INTERMEDIATE LEVER II TO CLUTCH ACTUATION LEVER,793543
999
LOCK FROM INTERMEDIATE LEVER II TO CLUTCH ACTUATION LEVER,793543
999
ROD , Replaced By: A3452957033, +001A3769960001
999
ROD , USED WITH AIR BRAKE,FROM CHASSIS 588186 NOT USED
999
ROD , Replaced By: A3762950033
999
YOKE , Replaced By: A3769960001
999
999
999
999
COTTER PIN PISTON ROD TO BRAKE PEDAL
999
SPRING WASHER CAB FLOOR
999
NUT FITTING TO CAB FLOOR
999
TURNBUCKLE
