Поз.
Артикул
Описание
196
PIPE SOCKET COOLING WATER LINE
200
LINE COOLING WATER LINE TO ENGINE,000562
204
GASKET COOLING WATER LINE TO OUTLET
208
SCREW BRACKET TO SIDE MEMBER
208
SCREW , Replaced By: N304017010002
212
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
216
CLAMP HOSE TO COOLING WATER PIPE
220
SCREW CAB FLOOR COVERING M 6X25
224
NUT , Replaced By: N913004006003
228
BRACKET COOLING WATER LINE TO ENGINE MOUNTING
232
HOSE FEED AND RETURN LINE CONNECTION, LENGTH AVAILABLE 1000 MM
240
CLAMP HOSE FASTENING 50-70X13 MM
240
CLAMP , Replaced By: N000000000672
244
COOLING WATER PIPE FROM HOSE TO HOSE AT OIL COOLER
244
COOLING WATER PIPE COOLING WATER LINE TO OIL COOLER
292
HOSE FEED AND RETURN LINE CONNECTION, LENGTH AVAILABLE 1000 MM
296
CLAMP HOSE FASTENING 50-70X13 MM
296
CLAMP , Replaced By: N000000000672
300
COOLING WATER PIPE FROM MOLDED HOSE TO MOLDED HOSE
300
COOLING WATER PIPE FROM HOSE TO MOLDED HOSE, NOT FOR USE WITH MERCEDES-BENZ BODY FROM IDENT NO. 030415, FOR USE WITH MERCEDES-BENZ BODY FROM IDENT NO. 030512
300
COOLING WATER PIPE FROM HOSE TO MOLDED HOSE
308
BRACKET COOLING WATER PIPE TO TRANSMISSION
308
BRACKET COMPRESSED AIR LINE
312
CLAMP SUCTION LINE TO CROSS MEMBER
316
SCREW BRACKET TO CROSS CONNECTION STRUT
316
SCREW , Replaced By: N304017008034
316
SCREW BRACKET TO FRAME SIDE MEMBER
316
SCREW CAB FLOOR COVERING M 6X25
320
WASHER , Replaced By: N000125008443
320
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
324
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
324
NUT , Replaced By: N913004008001
324
NUT , Replaced By: N913004006001
328
SCREW RADIATOR PROTECTIVE GRILLE TO ANGLE
328
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
336
CLAMP SUCTION LINE TO CROSS MEMBER
340
SCREW BRACKET TO CROSS CONNECTION STRUT
340
SCREW , Replaced By: N304017008034
344
WASHER , Replaced By: N000125008443
348
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
348
NUT , Replaced By: N913004008001
408
MOLDED HOSE ,000561
412
CLAMP HOSE FASTENING 50-70X13 MM
412
CLAMP , Replaced By: N000000000672
416
HOSE COOLING WATER LINE,021573
420
CLAMP HOSE FASTENING 50-70X13 MM
420
CLAMP , Replaced By: N000000000672
424
LINE FROM MOLDED HOSE TO MOLDED HOSE
426
VALVE (SHUT-OFF VALVE)
444
CLAMP , Replaced By: N000000001641
444
CLAMP HOSE TO COOLING WATER PIPE
448
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
448
SCREW , Replaced By: N304017008016
448
SCREW CAB FLOOR COVERING M 6X25
450
WASHER , Replaced By: N000125008443
452
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
452
NUT , Replaced By: N913004008001
452
NUT , Replaced By: N913004006001
456
HOSE RETURN, TO BE ADAPTED DURING ASSEMBLY
460
CLAMP HOSE FASTENING 50-70X13 MM
460
CLAMP , Replaced By: N000000000672
464
LINE FROM MOLDED HOSE TO WATER PUMP
468
BRACKET COOLING WATER LINE TO ENGINE
468
BRACKET COOLING WATER LINE TO ENGINE
472
CLAMP OIL LINE TO BRACKET
476
SCREW OIL LINE TO CRANKCASE
480
SCREW CAB FLOOR COVERING M 6X25
484
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
488
NUT , Replaced By: N913004006001
492
HOSE FEED
496
CLAMP HOSE FASTENING 50-70X13 MM
496
CLAMP , Replaced By: N000000000672
999
COVER , Replaced By: A0004380314
999
COVER , Replaced By: A0004380414
999
COVER (HINGED COVER), NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
MOLDED PIECE
999
SEAL RING40X47 MM
999
SENDER UNIT PRESSURE SWITCH
999
SENDER UNIT PRESSURE SWITCH
999
999
999
999
999
