Поз.
Артикул
Описание
5
VALVE ,D 122341
5
VALVE (PARKING BRAKE VALVE) KNORR,D 196082
7
BRAKE VALVE (PARKING BRAKE VALVE) WABCO
7
BRAKE VALVE (PARKING BRAKE VALVE) KNORR
8
HANDLE RUSSET BROWN TO 382 430 70 81
8
HANDLE BLACK TO 382 430 70 81
9
REPAIR KIT PARKING BRAKE VALVE TO 382 430 70 81
10
VALVE REPAIR KIT TO 695 431 70 05
10
REPAIR KIT PARKING BRAKE VALVE TO 695 431 75 05
11
HANDLETO 693 431 71 05
11
HANDLE PARTS KIT TO 695 431 75 05
12
ELECTRIC CABLE PARTS KIT TO A 693 431 72 05
13
PLUGTO 693 431 71 05
14
BRACKET PARKING BRAKE VALVE
14
BRACKET , Replaced By: A3844307510
15
BRACKET VALVES,D 196082
16
SCREW , Replaced By: N304017010040
17
WASHER BRACKET TO BRACKET
18
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
19
HEXALOBULAR BOLT EXPANSION TANK M8X20
20
LOCK WASHER RAIL TO BATTERY SUPPORT
23
SCREW LINES TO BRACKET
23
HEXALOBULAR BOLT EXPANSION TANK M8X20
26
NUT BRACKET TO SIDE MEMBER
26
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
29
HOLLOW SCREW , Replaced By: N915036010108
32
SEAL RING FUEL LINE TO FEED PUMP
35
DISTRIBUTOR
38
SCREW BRACKET TO FRAME
41
WASHER PLUG SOCKET TO BRACKET
44
NUT , Replaced By: N910113006001
47
HOLLOW SCREW HEATING CONNECTION
47
HOLLOW SCREW COMPRESSED AIR LINE TO OPERATING CYLINDER
50
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
53
SEAL RING LINE CONNECTION
56
SCREW-IN FITTING LINE CONNECTION
59
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
62
SCREW. UNION SCREW , Replaced By: A0009973734
65
LOCK , Replaced By: A0009945448
68
SEAL RING , Replaced By: A0009940747
71
SWITCH PARKING BRAKE VALVE,CONNECTION: "11"
71
SWITCH , Replaced By: A6935457609
74
MUFFLER VALVE BLEEDING
77
T-FITTING BETWEEN THE LINES
80
SEALING CORD SUCTION LINE TO OIL PUMP
83
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
83
HOSE PARKING BRAKE VALVE,CONNECTION: "3"
84
HOSE HAND BRAKE VALVE
86
PLASTIC PIPE FRONT AXLE PNEUMATIC SUSPENSION 12X9 MM, ORDER BY THE METER
87
HOSE HAND BRAKE VALVE
88
PLASTIC PIPE8X6 MM, ORDER BY THE METER
88
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
89
LOOM TIE WIRING HARNESS FOR AIR CONDITIONING SYSTEM 205 MM
89
CABLE TIE. LOOM TIE CABLE TO ALTERNATOR
92
CLAMP , Replaced By: N000000000667
95
BRACKET , Replaced By: A3184280240
98
SCREW CLAMP TO BRACKET
101
WASHER , Replaced By: N009021006208
104
NUT , Replaced By: N910113006001
107
CLAMP
110
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
113
LOCK WASHER CABLE TO FUSE BOX
116
WASHER PLUG SOCKET TO BRACKET
119
NUT
999
SWITCH
