Поз.
Артикул
Описание
8
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
8
HOSE , Replaced By: A0009872827
16
FITTING (PARTS KIT),LINE RUPTURE
16
FITTING , Replaced By: A0029906171
24
UNION NUT LINE CONNECTION
24
UNION NUT LINE CONNECTION, Replaced By: N000000006239
32
SEAL CONE LINE CONNECTION
32
GLAND , Replaced By: A0019901967
40
SLEEVE LINE CONNECTION
48
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
48
BANJO UNION , Replaced By: N915052009009
56
INSULATING HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
196
VALVE (PRESSURE LIMIT VALVE)
204
REPAIR KIT PRESSURE LIMIT VALVE
212
T-FITTING PRESSURE RELIEF VALVE,CONNECTION: "10"
220
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
228
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
236
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
244
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
252
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
260
VALVE (OVERFLOW VALVE) WABCO
260
VALVE , Replaced By: A0044293144
268
REPAIR KIT OVERFLOW VALVE TO 003 429 09 44,WABCO
276
ELBOW FITTING CHECK VALVE TO RELAY VALVE
276
ELBOW FITTING , Replaced By: A0049906471
284
FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
292
RESERVOIR20L,246 MM,12.5 BAR
300
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
308
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
316
BRAKE LINE COUPLING
324
PLUG BRAKE LINE COUPLING
332
NUT BRACKET TO SIDE MEMBER
340
FITTING BRAKE LINE COUPLING,CONNECTION: "10"
348
THRUST RING CHECK VALVE TO AIR RESERVOIR
348
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
356
O-RING CHECK VALVE TO AIR RESERVOIR
999
REPAIR KITTO 002 431 84 06, KNORR 90310
999
REPAIR KIT PRESSURE REGULATOR KNORR
999
RESERVOIR , Replaced By: A0034321401
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
T-FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
999
VALVE , Replaced By: A0044293244
999
VALVE ,5 161700, Replaced By: A0024314706
999
PRESSURE REGULATOR WITH TIRE INFLATING CONNECTION BOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
PRESSURE REGULATORKNORR 90310
999
T-FITTING PRESSURE RELIEF VALVE,CONNECTION: "10"
999
RESERVOIR ,5 563826
999
SCREW PLUG , Replaced By: N000908012009
999
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
999
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
999
NUT CHECK VALVE TO AIR RESERVOIR
