Поз.
Артикул
Описание
101
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
101
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
104
ROD END HYDRAULIC RELEASE
107
SEAL RING HYDRAULIC RELEASE
110
PAWL SHIFTING ROD,5 443048
110
PAWL ,5 4430475 443048, Replaced By: A6202600087, +001A6202680150
113
BUSHING PAWL TO ROD END,5 443048
113
BUSHING PAWL TO ROD END,5 443048
113
BUSHING PAWL TO ROD END,5 443047
116
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
119
ROUND CORD RING. SEAL RING ROD END
122
SPRING ROD END
125
SPRING ROD END
128
SCREW SHIFTING ROD TO SHIFT LEVER
128
SCREW , Replaced By: N000933010192
131
NUT STRAP TO BRACKET
131
NUT , Replaced By: N910113010000
134
SHIFTING TUBE (TELESCOPIC TUBE)
137
SHIFTING CYLINDER HYDRAULIC RELEASE TECHNOMATIK
137
SHIFTING CYLINDER HYDRAULIC RELEASE WABCO
140
SEAL RING PISTON RINGS WABCO
143
SEAL RING SCREW FITTING WABCO
146
SEAL RING OUTSIDE WABCO
149
SPRING WASHER SHIFTING CYLINDER TO YOKE
152
PIN SHIFTING CYLINDER TO YOKE 8X45 MM
155
PIN SHIFTING CYLINDER TO PAWL 8X20 MM
158
COTTER PIN LEVER TO ROD
158
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
161
WASHER BETWEEN THE SHIFTING RODS
167
SHIFTING ROD REAR
167
SHIFTING ROD REAR
170
SCREW FRONT SHIFTING ROD TO REAR SHIFTING ROD
173
NUT STRAP TO BRACKET
173
NUT , Replaced By: N910113010000
176
CLAMPING PIECE SHIFTING ROD TO TRANSMISSION
179
SCREW CONNECTOR TO REAR SHIFTING ROD
182
SCREW CONNECTOR TO REAR SHIFTING ROD
182
SCREW , Replaced By: N304017010047
185
JOINT SHIFTING ROD TO TRANSMISSION
185
JOINT SHIFTING ROD TO TRANSMISSION
188
CONNECTOR , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6172680028
188
CONNECTOR , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6172680028
191
SCREW SHIFTING ROD TO TRANSMISSION
194
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
197
NUT
200
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
203
ROUND CORD RING. SEAL RING ROD END
206
SPRING WASHER SHIFTING ROD TO SHIFT LEVER
209
SCREW SHIFTING ROD TO SHIFT LEVER
212
NUT STRAP TO BRACKET
212
NUT , Replaced By: N910113010000
999
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
999
INSULATION CAB/TRANSMISSION COMPRESSED-AIR-LINE SEPARATION POINT
999
CONNECTOR REAR SHIFTING ROD TO CONNECTOR
999
BUSHING COMPRESSED AIR LINE THRU CAB FLOOR,K040603
999
PIN SHIFT LEVER BEARING,K 040604
999
BRACKET SHIFT LEVER LOWER PART,K 040604
999
BRACKET SHIFT LEVER UPPER PART,K 040604
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
EXPANSION PLUG ROD END
999
SCREW CONNECTOR TO TRANSMISSION
999
SCREW , Replaced By: N000933008337
999
SCREW , Replaced By: A0099900101
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
