Поз.
Артикул
Описание
387
SUPPORT AT CROSS MEMBER,5 317649
387
SUPPORT AT CROSS MEMBER,5 317650
396
SCREW , Replaced By: N304017008021
396
SCREW PIPE CLAMP
396
SCREW , Replaced By: N304017008034
396
SCREW BRACKET TO CROSS CONNECTION STRUT
405
NUT , Replaced By: N913004008001
405
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
405
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
405
NUT END PIECE TO EXHAUST PIPE
405
NUT BRACKET TO SIDE MEMBER
405
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
405
NUT END PIECE TO EXHAUST PIPE
405
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
405
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
675
VALVE (REDUCTION VALVE),5 359430
675
VALVE (REDUCTION VALVE)
678
BRACKET REDUCTION VALVE
679
BRACKET REDUCTION VALVE
680
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
680
SCREW , Replaced By: N304017008016
681
SCREW PIPE CLAMP
681
SCREW PIPE CLAMP
681
SCREW , Replaced By: N304017008021
682
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
682
NUT , Replaced By: N913004008001
684
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
684
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
684
SCREW PLUG , Replaced By: N000908022011
693
THRUST RING CHECK VALVE TO AIR RESERVOIR
693
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
693
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
702
O-RING CHECK VALVE TO AIR RESERVOIR
703
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
711
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
720
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
729
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
738
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
740
VALVE (RELAY VALVE) BOSCH, REPAIR IMPOSSIBLE
740
VALVE (RELAY VALVE) BOSCH, REPAIR IMPOSSIBLE
740
VALVE (RELAY VALVE) WABCO, REPAIR IMPOSSIBLE
740
VALVE (RELAY VALVE) WABCO, REPAIR IMPOSSIBLE
740
VALVE FRONT AXLE II RELAY VALVE "GRAU", NOT USED
740
VALVE (RELAY VALVE) BOSCH, REPAIR IMPOSSIBLE
740
VALVE (RELAY VALVE) WABCO, REPAIR IMPOSSIBLE
740
VALVE FRONT AXLE II RELAY VALVE "BOSCH"
740
VALVE FRONT AXLE II RELAY VALVE "GRAU", NOT USED
740
VALVE FRONT AXLE II RELAY VALVE "WABCO"
740
VALVE FRONT AXLE II RELAY VALVE "GRAU", NOT USED
740
VALVE FRONT AXLE II RELAY VALVE "BOSCH"
740
VALVE FRONT AXLE II RELAY VALVE "BOSCH"
740
VALVE FRONT AXLE II RELAY VALVE "WABCO"
740
VALVE FRONT AXLE II RELAY VALVE "WABCO"
740
VALVE , Replaced By: A0044293844
740
VALVE FRONT AXLE II RELAY VALVE "GRAU", NOT USED
740
VALVE FRONT AXLE II RELAY VALVE "BOSCH"
740
VALVE FRONT AXLE II RELAY VALVE "WABCO"
742
REPAIR KIT RELAY VALVE "GRAU"
742
REPAIR KIT RELAY VALVE BOSCH
742
REPAIR KIT RELAY VALVE TO 003 429 93 44,WABCO
742
REPAIR KIT RELAY VALVE TO 004 429 38 44,WABCO
742
REPAIR KIT RELAY VALVE TO 003 429 93 44,WABCO
742
REPAIR KIT RELAY VALVE "GRAU"
742
REPAIR KIT RELAY VALVE BOSCH
742
REPAIR KIT RELAY VALVE TO 004 429 38 44,WABCO
747
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
756
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
765
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
774
O-RING CHECK VALVE TO AIR RESERVOIR
783
THRUST RING CHECK VALVE TO AIR RESERVOIR
783
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
792
NUT CHECK VALVE TO AIR RESERVOIR
801
FITTING RELAY VALVE,CONNECTION: "40",5 359430
801
FITTING , Replaced By: A0029979572
810
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
819
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
828
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
828
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
828
TEST CONNECTION
828
TEST CONNECTION
828
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
828
TEST CONNECTION
828
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
828
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
828
TEST CONNECTION
828
TEST CONNECTION
828
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
828
TEST CONNECTION
837
BRACKET RELAY VALVE TO CROSS MEMBER
837
BRACKET RELAY VALVE TO CROSS MEMBER
837
BRACKET RELAY VALVE TO CROSS MEMBER
837
BRACKET RELAY VALVE TO CROSS MEMBER
840
BRACKET FRONT AXLE RELAY VALVE,5 585846
840
BRACKET FRONT AXLE RELAY VALVE,5 585846
843
BRACKET FRONT AXLE RELAY VALVE,5 765578
843
BRACKET FRONT AXLE RELAY VALVE,5 765578
843
BRACKET FRONT AXLE RELAY VALVE,5 765578
846
SCREW , Replaced By: N304017008018
846
SCREW SUPPORT TO FENDER
846
SCREW , Replaced By: N304017008027
846
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
846
SCREW SUPPORT TO FENDER
846
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
846
SCREW SUPPORT TO FENDER
850
WASHER , Replaced By: N000125008443
850
WASHER EXHAUST MUFFLER TO STRAP
855
NUT , Replaced By: N913004008001
855
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
864
SCREW , Replaced By: N304017008034
864
SCREW BRACKET TO CROSS CONNECTION STRUT
864
SCREW BRACKET TO CROSS CONNECTION STRUT
864
SCREW BRACKET TO CROSS CONNECTION STRUT
864
SCREW , Replaced By: N304017008027
864
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
873
WASHER , Replaced By: N000125008443
873
WASHER EXHAUST MUFFLER TO STRAP
873
WASHER , Replaced By: N009021008213
873
WASHER BRACKET TO LEFT SIDE MEMBER
882
NUT , Replaced By: N913004008001
882
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
885
SCREW. UNION SCREW LINE CONNECTION
885
SCREW. UNION SCREW , Replaced By: A0009973734
885
SCREW. UNION SCREW LINE CONNECTION
891
VALVE (PRESSURE RATIO VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
891
VALVE (PRESSURE RATIO VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
891
VALVE (PRESSURE RATIO VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
891
VALVE (PRESSURE RATIO VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
891
VALVE (PRESSURE RATIO VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
892
SEALING CORD38X8 MM
893
SEAL RING34.6X2.6 MM
894
SEAL RING28.4X2.6 MM
895
VALVE
896
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
897
SEAL RING56X1.7 MM
898
REPAIR KIT PRESSURE RATIO VALVE
898
REPAIR KIT PRESSURE RATIO VALVE
900
BRACKET ,8 004624
900
BRACKET ,8 004624
902
BRACKET PRESSURE RATIO VALVE,5 585846
902
BRACKET PRESSURE RATIO VALVE,5 585846
904
SCREW , Replaced By: N000933008337
904
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
904
SCREW , Replaced By: N304017008021
904
SCREW PIPE CLAMP
904
SCREW , Replaced By: A0099900101
904
SCREW PIPE CLAMP
909
SCREW , Replaced By: N304017008039
909
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
909
SCREW , Replaced By: N000933008337
909
SCREW , Replaced By: A0099900101
909
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
909
SCREW , Replaced By: N304017008021
909
SCREW PIPE CLAMP
910
NUT , Replaced By: N913004008001
910
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
910
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
911
T-FITTING PRESSURE RATIO VALVE,CONNECTION: "10",8 004623
911
FITTING AIR RESERVOIR,CONNECTION: "26", NOT USED
912
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
912
SCREW. UNION SCREW LINE CONNECTION
913
SCREW PLUG , Replaced By: N000908022011
913
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
913
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
913
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
913
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
914
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
914
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
914
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
915
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
915
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
916
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
917
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
920
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
924
SCREW , Replaced By: N304017008021
924
SCREW PIPE CLAMP
927
NUT , Replaced By: N913004008001
927
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
936
SCREW PLUG , Replaced By: N000908022011
936
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
936
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
938
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
959
LOOM TIE LINE MOUNTING 280 MM
959
LOOM TIE LINE MOUNTING
959
LOOM TIE LINE MOUNTING 280 MM
959
LOOM TIE LINE MOUNTING
960
WASHER BRACKET TO LEFT SIDE MEMBER
961
RUBBER BUFFER LINE MOUNTING
961
RUBBER BUFFER LINE MOUNTING
961
RUBBER BUFFER LINE MOUNTING
962
GROMMET ,5 585846
977
BRAKE LINE COUPLING SUPPLY, RED "BOSCH"
977
BRAKE LINE COUPLING SUPPLY, RED "GRAU"
977
BRAKE LINE COUPLING SUPPLY, RED "KNORR"
977
BRAKE LINE COUPLING SUPPLY, RED "WABCO"
977
BRAKE LINE COUPLING BRAKE,YELLOW "BOSCH"
977
BRAKE LINE COUPLING BRAKE,YELLOW "GRAU"
977
BRAKE LINE COUPLING BRAKE,YELLOW "KNORR"
977
BRAKE LINE COUPLING BRAKE,YELLOW "WABCO"
980
SEAL RING25X2 MM,BOSCH
981
SEAL RING30X2 MM,BOSCH
