Поз.
Артикул
Описание
5
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
6
HOSE LEAK LINE, ORDER BY THE METER
6
PLASTIC PIPE RISING PIPE 4X6 MM
6
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
8
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
10
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
10
FITTING (PARTS KIT),LINE RUPTURE
14
PLASTIC PIPE FUEL LINE 16X2 MM, ORDER BY THE METER
15
INSULATING HOSE FEED 11X0.7 MM, ORDER BY THE METER
16
HOSE LEAK LINE
23
GROMMET FOR PASSAGE OF LINE
26
SLEEVE FEED
26
SLEEVE LEAK LINE
29
CLIP LEAK LINE
30
CLAMP LINE MOUNTING
32
HOSE CLAMP FUEL LINE TO SENDER UNIT
32
CLAMP , Replaced By: A0059972790
33
BANJO UNION FEED
38
HOLLOW SCREW FUEL LINE TO FEED PUMP
38
HOLLOW SCREW , Replaced By: N915036010108
41
FITTING RETURN
44
UNION NUT RETURN
47
SEAL RING FUEL LINE TO FEED PUMP
53
LOOM TIE LINE MOUNTING
53
LOOM TIE LINE MOUNTING 280 MM
