Поз.
Артикул
Описание
90
BEARING BRACKET CLUTCH PEDAL
94
STUD BOLT BRACKET TO CROSS MEMBER
95
WASHER EXHAUST MUFFLER TO STRAP
96
NUT BRACKET TO BRACKET
138
MASTER CYLINDER CLUTCH
144
SEAL RING
144
SEAL RING
145
SEAL RING
146
BOOT
147
VALVE CLUTCH SLAVE CYLINDER
156
ROD MASTER CYLINDER TO PEDAL ASSEMBLY
173
RESERVOIR EXPANSION TANK
175
RESERVOIR RESERVOIR
176
LOCKING CAP
179
SEAL RING
182
STRAINER
185
CAP RESERVOIR DE-AERATION
188
BRACKET RESERVOIR
191
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
194
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
197
WASHER , Replaced By: N009021006208
197
WASHER COMPRESSED AIR LINE TO BRACKET
200
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
203
FITTING CLUTCH MASTER CYLINDER
206
ANGLE AT CLUTCH PEDAL UNIT
209
SENDER UNIT CLUTCH OPERATION EPS, TO BE ADAPTED DURING ASSEMBLY
