Поз.
Артикул
Описание
8
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
8
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
8
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
8
LINE SUCTION LINE
8
LINE , Replaced By: A6564602424
8
LINE FROM PUMP TO HIGH PRESSURE HOSE
8
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
8
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
8
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
8
LINE , Replaced By: A0004291601
11
ELBOW FITTING SUCTION LINE TO OIL PUMP
14
THRUST RING SUCTION LINE TO OIL PUMP
17
SEALING CORD SUCTION LINE TO OIL PUMP
20
NUT SUCTION LINE TO OIL PUMP
23
BRACKET COMPRESSED AIR LINES,K 168169
26
BRACKET LINE MOUNTING
29
SCREW STRUT TO FRAME, LEFT
32
NUT EXHAUST PIPE TO SIDE MEMBER
35
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
35
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
38
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
41
NUT AT FILTER BRACKET
44
TUBE FROM HIGH PRESSURE HOSE TO STEERING
44
LINE , Replaced By: A0005516156
999
BRACKET PULL ROD TO SUPPORT,5 352764 TO BE ADAPTED DURING ASSEMBLY
999
BRACKET SUCTION LINE TO TRANSMISSION
999
HOSE , NOT USED
999
BRACKET OIL LINE ON ENGINE SIDE
999
LINE FROM 2/2-WAY VALVE TO HOSE,CIRCUIT II,5 569241
999
LINE (RETURN LINE) TO OIL HOSE,CIRCUIT II
999
LINE FROM 2/2-WAY VALVE TO HOSE,CIRCUIT II,5 569241
999
LINE (SUCTION LINE) FROM OIL TANK TO PUMP,CIRCUIT II,5 569241
999
LINE (SUCTION LINE) FROM OIL TANK TO PUMP,CIRCUIT II
999
BRACKET POWER CYLINDER DELIVERY LINE,5 525734
999
BRACKET OIL TANK, TO BE ADAPTED DURING ASSEMBLY
999
BRACKET OIL TANK
999
BRACKET OIL LINE TO ENGINE
999
BRACKET
999
BRACKET
999
LINE POWER-STEERING-PUMP-TO-STEERING-BOX DELIVERY LINE
999
LINE SUCTION LINE TO OIL PUMP
999
LINE FROM PUMP TO HIGH PRESSURE HOSE
999
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
999
LINE , Replaced By: A0005516156
999
LINE , Replaced By: A6564602224
